Read this manual carefully before operating this vehicle.
OWNER'S MANUAL
FZ09G
B87-28199-7S

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FZ-09 2015 and is the answer not in the manual?

Questions and answers

Related Manuals for Yamaha FZ-09 2015

Summary of Contents for Yamaha FZ-09 2015

  • Page 1 Read this manual carefully before operating this vehicle. OWNER’S MANUAL FZ09G B87-28199-7S...
  • Page 2 EAU46091 Read this manual carefully before operating this vehicle. This manual should stay with this vehicle if it is sold.
  • Page 3 Introduction EAU45931 Congratulations on your purchase of the Yamaha FZ09G. This model is the result of Yamaha’s vast experience in the pro- duction of fine sporting, touring, and pacesetting racing machines. It represents the high degree of craftsmanship and re- liability that have made Yamaha a leader in these fields.

  • Page 4: Important Manual Information

    Important manual information EAU10134 Particularly important information is distinguished in this manual by the following notations: This is the safety alert symbol. It is used to alert you to potential personal injury hazards. Obey all safety messages that follow this symbol to avoid possible injury or death.
  • Page 5 Important manual information EAU10201 FZ09G OWNER’S MANUAL ©2015 by Yamaha Motor Co., Ltd. 1st edition, July 2015 All rights reserved. Any reprinting or unauthorized use without the written permission of Yamaha Motor Co., Ltd. is expressly prohibited. Printed in Japan.

  • Page 6: Table Of Contents

    Table of contents Location of important labels... 1-1 Sidestand ........4-21 Cast wheels ........7-19 Ignition circuit cut-off system ..4-22 Adjusting the clutch lever free Safety information......2-1 Auxiliary DC connector ....4-24 play..........7-19 Checking the brake lever free Description ........3-1 For your safety –...
  • Page 7 Front wheel........7-39 Rear wheel........7-40 Troubleshooting ......7-42 Troubleshooting charts ....7-43 Motorcycle care and storage ..8-1 Matte color caution ......8-1 Care ..........8-1 Storage ..........8-3 Specifications........9-1 Consumer information ....10-1 Identification numbers....10-1 Maintenance record ......10-3 YAMAHA MOTOR CANADA LTD. MOTORCYCLE WARRANTY GUIDE ........10-5 Index ..........11-1...

  • Page 8: Location Of Important Labels

    Read and understand all of the labels on your vehicle. They contain important information for safe and proper operation of your vehicle. Never remove any labels from your vehicle. If a label becomes difficult to read or comes off, a replacement label is available from your Yamaha dealer. 4,5,6,7...
  • Page 9 Location of important labels This spark ignition system meets all requirements of the Canadian Interference Causing Equipment Regulations. Ce système d’allumage par étincelle de véhicule respecte toutes les exigences du Règlement sur le matériel brouilleur du Canada. 3JK-82377-30 TIRE INFORMATION INFORMATION SUR LES PNEUS Cold tire normal pressure should be set La pression des pneus à...

  • Page 10: Load Limit

    Location of important labels LOAD LIMIT CHARGE LIMITE 3 kg {7 lbs} 3 kg (7 lb) 3TB-24877-A0 3TB-24877-B1 WARNING BEFORE YOU OPERATE THIS VEHICLE, READ THE OWNER’S MANUAL AND ALL LABELS. ALWAYS WEAR AN APPROVED MOTORCYCLE HELMET, eye protection, and protective clothing. AVERTISSEMENT LIRE LE MANUEL DU PROPRIETAIRE AINSI QUE TOUTES LES ETIQUETTES AVANT D’UTILISER CE VEHICULE.

  • Page 11: Safety Information

    Safety information  Never operate a motorcycle with- pears to be very effective in reduc- EAU1028B out proper training or instruction. ing the chance of this type of Take a training course. Beginners accident. Be a Responsible Owner should receive training from a cer- Therefore: As the vehicle’s owner, you are re- tified instructor.
  • Page 12 Safety information  Many accidents involve inexperi- • Always signal before turning or Protective Apparel enced operators. In fact, many op- changing lanes. Make sure that The majority of fatalities from motorcy- erators who have been involved in other motorists can see you. cle accidents are the result of head in- ...
  • Page 13 Safety information  Do not run engine outdoors where Avoid Carbon Monoxide Poisoning When loading within this weight limit, All engine exhaust contains carbon engine exhaust can be drawn into keep the following in mind:  Cargo and accessory weight monoxide, a deadly gas.
  • Page 14 Yamaha accessories, which are avail- performed to your vehicle that change able only from a Yamaha dealer, have any of the vehicle’s design or operation should be kept to a minimum. been designed, tested, and approved characteristics can put you and others •...
  • Page 15 Safety information  Check that the fuel cock (if operator and may limit control ability, therefore, such accesso- equipped) is in the “OFF” position ries are not recommended. and that there are no fuel leaks.  Use caution when adding electri- ...

  • Page 16: Description

    Description EAU10411 Left view 3 4,5,6 11 10 1. Front fork spring preload adjusting bolt (page 4-18) 9. Shift pedal (page 4-13) 2. Shock absorber assembly rebound damping force adjusting screw 10.Engine oil drain bolt (page 7-10) (page 4-19) 11.Coolant drain bolt (page 7-13) 3.

  • Page 17: Right View

    Description EAU10421 Right view 1. Fuel tank cap (page 4-14) 9. Rear brake light switch (page 7-21) 2. Front fork rebound damping force adjusting screw (page 4-18) 10.Rear brake fluid reservoir (page 7-22) 3. Headlight (page 7-33) 4. Fuse box 1 (page 7-31) 5.

  • Page 18: Controls And Instruments

    Description EAU10431 Controls and instruments 1. Clutch lever (page 4-13) 2. Left handlebar switches (page 4-11) 3. Main switch/steering lock (page 4-1) 4. Multi-function meter unit (page 4-4) 5. Front brake fluid reservoir (page 7-22) 6. Right handlebar switches (page 4-11) 7.

  • Page 19: Instrument And Control Functions

    Instrument and control functions To lock the steering EAU10462 Main switch/steering lock The headlight comes on automatically when the engine is started and stays on until the key is turned to “OFF”, even if the engine stalls. EAU10662 All electrical systems are off. The key LOCK can be removed.

  • Page 20: Indicator Lights And Warning Lights

    Instrument and control functions To unlock the steering ECA20760 EAU49398 Indicator lights and warning NOTICE lights Using the hazard or turn signal lights for an extended length of time may 1 2 3 4 5 6 cause the battery to discharge. 1.
  • Page 21 “ON”. The warning light should monitoring the engine. If this occurs, (see page 7-10), have a Yamaha dealer come on for a few seconds, and then have a Yamaha dealer check the self- check the vehicle.

  • Page 22: Multi-Function Meter Unit

    Multi-function meter unit initially when the key is turned to “ON”, or if the warning light remains on, have a Yamaha dealer check the electrical circuit. This warning light will come on when the key is turned to “ON” and the start switch is pushed, but this does not in- 1.
  • Page 23 Instrument and control functions  tachometer The speedometer shows the vehicle’s Clock  clock traveling speed.  fuel meter  eco indicator Tachometer  transmission gear display  drive mode display  multi-function display Except when accessing the brightness control mode or when displaying the 1.
  • Page 24 Fuel meter  Travel at a constant speed. warning indicator “ ” will flash repeat-  Select the transmission gear that edly. If this occurs, have a Yamaha dealer check the vehicle. is appropriate for the vehicle speed. Eco indicator Transmission gear display 1.
  • Page 25 Instrument and control functions Drive mode display Multi-function display “L/100 km”, average fuel consumption mode “AVE_ _._ km/L” or “AVE_ _._ L/100 km”, coolant temperature mode “°C”, air intake temperature mode “Air_ _ °C”, odometer mode “ODO”, and tripmeter modes “TRIP 1” and “TRIP 2” in the following order: km/L or L/100 km →...
  • Page 26 Instrument and control functions  You can manually reset the fuel re-  “L/100 km”: The amount of fuel To reset a tripmeter, use the “SELECT” button to display the tripmeter you serve tripmeter, or after refueling necessary to travel 100 km under want to reset, and then push the “RE- and traveling 5 km (3 mi), it will re- the current riding conditions is...
  • Page 27 Instrument and control functions The average fuel consumption display Coolant temperature Air intake temperature can be set to either “AVE_ _._ km/L” or “AVE_ _._ L/100 km”.  “AVE_ _._ km/L”: The average dis- tance that can be traveled on 1.0 L of fuel is shown.

  • Page 28: D-Mode (Drive Mode)

    If the display indicates any error ton, turn the key to “ON” and con- codes, note the code number and have tinue pushing the button until the a Yamaha dealer check the vehicle. display switches to the brightness Before using D-mode, make sure you ECA11591 control mode.

  • Page 29: Handlebar Switches

    Instrument and control functions This mode allows the rider to enjoy Right EAU1234H Handlebar switches smooth and sporty drivability from the low-speed range to the high-speed Left range. Mode “A” Mode “A” offers a sportier engine re- sponse in the low- to mid-speed range compared to mode “STD”.
  • Page 30 Instrument and control functions ter position. To cancel the turn signal The throttle grip must be completely EAU12735 Hazard switch “ ” lights, push the switch in after it has re- closed in order to change the drive mo- With the key in the “ON” or “ ”...

  • Page 31: Clutch Lever

    Instrument and control functions EAU12822 EAU12872 EAU26825 Clutch lever Shift pedal Brake lever The brake lever is located on the right side of the handlebar. To apply the front brake, pull the lever toward the throttle grip. 1. Clutch lever 1.

  • Page 32: Brake Pedal

    Instrument and control functions EAU12944 EAU13075 Brake pedal Fuel tank cap The fuel tank cap cannot be closed un- less the key is in the lock. In addition, the key cannot be removed if the cap is not properly closed and locked. EWA11092 WARNING Make sure that the fuel tank cap is...

  • Page 33: Fuel

    WARNING pump nozzle into the fuel tank filler Gasoline is poisonous and can cau- Your Yamaha engine has been de- hole. Stop filling when the fuel se injury or death. Handle gasoline signed to use premium unleaded gas- reaches the bottom of the filler with care.

  • Page 34: Fuel Tank Breather Hose And Overflow Hose

    10% (E10). Gas-  Do not park the vehicle near ohol containing methanol is possible fire hazards such as recommended by Yamaha because it grass or other materials that can cause damage to the fuel system easily burn. or vehicle performance problems.

  • Page 35: Seat

    Instrument and control functions ECA10702 EAU57991 Seat NOTICE Use only unleaded gasoline. The use To remove the seat of leaded gasoline will cause unre- 1. Open the seat lock cover, insert pairable damage to the catalytic the key into the seat lock, and then converter.

  • Page 36: Storage Compartment

    Instrument and control functions EAU58200 EAU62450 Storage compartment Adjusting the front fork EWA14671 WARNING Always adjust the spring preload on both fork legs equally, otherwise poor handling and loss of stability may result. Each front fork leg is equipped with a spring preload adjusting bolt.

  • Page 37: Adjusting The Shock Absorber Assembly

    Instrument and control functions EAU57940 Spring preload setting: Rebound damping setting: Adjusting the shock absorber Minimum (soft): Minimum (soft): assembly Distance A = 19.0 mm (0.75 in) 11 click(s) in direction (b)* This shock absorber assembly is Standard: Standard: Distance A = 16.0 mm (0.63 in) 8 click(s) in direction (b)* equipped with a spring preload adjust- Maximum (hard):...
  • Page 38 Instrument and control functions Rebound damping force 3 2 1 To increase the rebound damping for- 7 6 5 4 To obtain a precise adjustment, it is ce and thereby harden the rebound advisable to check the actual total damping, turn the adjusting screw in number of turns of the damping force direction (a).

  • Page 39: Luggage Strap Holders

    The sidestand is located on the left sembly yourself. Take the shock side of the frame. Raise the sidestand absorber assembly to a Yamaha or lower it with your foot while holding dealer for any service. the vehicle upright.

  • Page 40: Ignition Circuit Cut-Off System

    Instrument and control functions this system regularly and have a EAU68280 Ignition circuit cut-off system Yamaha dealer repair it if it does not The ignition circuit cut-off system function properly. (comprising the sidestand switch, clutch switch and neutral switch) has the following functions.
  • Page 41 Instrument and control functions WARNING With the engine turned off: 1. Move the sidestand down. If a malfunction is noted, have a Yamaha 2. Make sure that the start/engine stop switch is set to “ ”. dealer check the system before riding.

  • Page 42: Auxiliary Dc Connector

    Instrument and control functions EAU70640 Auxiliary DC connector This vehicle is equipped with an auxil- iary DC connector. Consult your Yamaha dealer before installing any accessories. 4-24...

  • Page 43: For Your Safety - Pre-Operation Checks

    • If necessary, add recommended coolant to specified level. 7-12 • Check cooling system for leakage. • Check operation. • If soft or spongy, have Yamaha dealer bleed hydraulic system. • Check brake pads for wear. Front brake • Replace if necessary.
  • Page 44 • Make sure that operation is smooth. • Check throttle grip free play. Throttle grip 7-16, 7-26 • If necessary, have Yamaha dealer adjust throttle grip free play and lubricate ca- ble and grip housing. • Make sure that operation is smooth. Control cables 7-26 •...
  • Page 45 • Tighten if necessary. Instruments, lights, signals • Check operation. — and switches • Correct if necessary. • Check operation of ignition circuit cut-off system. Sidestand switch 4-21 • If system is not working correctly, have Yamaha dealer check vehicle.

  • Page 46: Operation And Important Riding Points

     a lean angle sensor to stop the en-  The transmission is in the neutral understand, ask your Yamaha dealer. gine in case of a turnover. In this EWA10272 position.

  • Page 47: Shifting

    NOTICE neutral position. The neutral indi-  Even with the transmission in cator light should come on. If not, ask a Yamaha dealer to check the the neutral position, do not electrical circuit. coast for long periods of time 3. Start the engine by sliding the “...
  • Page 48 Operation and important riding points 4. At the recommended shift points clutch lever in, use the brakes to EAU64150 Recommended shift points shown in the following table, close slow the motorcycle, and continue The recommended shift points during the throttle, and at the same time, to downshift as necessary.

  • Page 49: Engine Break-In

    Yamaha dealer check the vehi- to the correct operating clearances. touch them and be burned. cle.  Do not park on a slope or on soft...
  • Page 50 To avoid possible burns, let tivities incorrectly may increase brake components cool before your risk of injury or death during touching them. service or while using the vehicle. If you are not familiar with vehicle ser- vice, have a Yamaha dealer perform service.

  • Page 51: Owner's Tool Kit

    If you do not have the tools or experi- ence required for a particular job, have a Yamaha dealer perform it for you.

  • Page 52: Periodic Maintenance Chart For The Emission Control System

     From 37000 km (24000 mi) or 36 months, repeat the maintenance intervals starting from 13000 km (8000 mi) or 12 months.  Items marked with an asterisk require special tools, data and technical skills, have a Yamaha dealer perform the ser- vice.
  • Page 53 Periodic maintenance and adjustment INITIAL ODOMETER READINGS 1000 km 7000 km 13000 km 19000 km 25000 km 31000 km ITEM ROUTINE (600 mi) (4000 mi) (8000 mi) (12000 mi) (16000 mi) (20000 mi) 1 month 6 months 12 months 18 months 24 months 30 months •...

  • Page 54: General Maintenance And Lubrication Chart

    Periodic maintenance and adjustment EAU67560 General maintenance and lubrication chart INITIAL ODOMETER READINGS 1000 km 7000 km 13000 km 19000 km 25000 km 31000 km ITEM ROUTINE (600 mi) (4000 mi) (8000 mi) (12000 mi) (16000 mi) (20000 mi) 1 month 6 months 12 months 18 months...
  • Page 55 Periodic maintenance and adjustment INITIAL ODOMETER READINGS 1000 km 7000 km 13000 km 19000 km 25000 km 31000 km ITEM ROUTINE (600 mi) (4000 mi) (8000 mi) (12000 mi) (16000 mi) (20000 mi) 1 month 6 months 12 months 18 months 24 months 30 months •...
  • Page 56 • Change coolant. Front and rear √ √ √ √ √ √ 26 * • Check operation. brake switches • Apply Yamaha cable lubricant or √ √ √ √ √ √ 27 * Control cables other suitable cable lubricant thoroughly.
  • Page 57 Periodic maintenance and adjustment INITIAL ODOMETER READINGS 1000 km 7000 km 13000 km 19000 km 25000 km 31000 km ITEM ROUTINE (600 mi) (4000 mi) (8000 mi) (12000 mi) (16000 mi) (20000 mi) 1 month 6 months 12 months 18 months 24 months 30 months •...

  • Page 58: Checking The Spark Plugs

    1/2 turn past finger tight. However, the Yamaha dealer. Since heat and depos- with a wire thickness gauge and, if spark plug should be tightened to the its will cause any spark plug to slowly necessary, adjusted to specification.

  • Page 59: Engine Oil And Oil Filter Cartridge

    Periodic maintenance and adjustment 4. Remove the engine oil filler cap, EAU1990A Engine oil and oil filter car- the engine oil drain bolt and its tridge gasket to drain the oil from the The engine oil level should be checked crankcase.
  • Page 60 Make sure that the O-ring is properly 17 Nm (1.7 m·kgf, 12 ft·lbf) An oil filter wrench is available at a seated. Yamaha dealer. 8. Install the engine oil drain bolt and 7. Install the new oil filter cartridge its new gasket, and then tighten 6.

  • Page 61: Coolant

     In order to prevent clutch slip- correct, immediately turn the engine checked on a cold engine since off and have a Yamaha dealer check page (since the engine oil also the level varies with engine tem- the vehicle.
  • Page 62 If water has been added to the coolant, have a Yamaha dealer check the anti- freeze content of the coolant as 7-13...
  • Page 63 Periodic maintenance and adjustment 5. Remove the coolant reservoir cap. 1. Radiator cap 1. Coolant drain bolt 2. Radiator cap retaining bolt 2. Gasket 1. Coolant reservoir cap 3. Radiator cap retainer 9. After the coolant is completely 6. Drain the coolant from the coolant 4.

  • Page 64: Air Filter Element

    High-quality ethylene glycol anti- dealer check the cooling system. maintenance and lubrication chart. freeze containing corrosion inhibi- tors for aluminum engines Have a Yamaha dealer replace the air Coolant quantity: filter element. Radiator (including all routes): 1.93 L (2.04 US qt, 1.70 Imp.qt)

  • Page 65: Checking The Engine Idling Speed

    To prevent this necessary, have it corrected by a from occurring, the valve clearance Yamaha dealer. must be adjusted by a Yamaha dealer at the intervals specified in the periodic Engine idling speed: 1100–1300 r/min maintenance and lubrication chart.

  • Page 66: Tires

    * Total weight of rider, passenger, car- or glass fragments in it, or if the side- go and accessories Operation of this vehicle with im- wall is cracked, have a Yamaha dealer proper tire pressure may cause se- replace the tire immediately. EWA10512...
  • Page 67 Tire information characteristics of the motorcy- EWA10472 WARNING cle may be different, which  Have a Yamaha dealer replace could lead to an accident.  Always make sure that the valve excessively worn tires. Besides being illegal, operating the vehi-...

  • Page 68: Cast Wheels

    If any damage is found, have high speeds. a Yamaha dealer replace the  Brand-new tires can have a rel- wheel. Do not attempt even the atively poor grip on certain road smallest repair to the wheel.

  • Page 69: Checking The Brake Lever Free Play

    Yamaha dealer check the internal clutch mechanism. 1. No brake lever free play There should be no free play at the brake lever end. If there is free play, have a Yamaha dealer inspect the brake system.

  • Page 70: Brake Light Switches

    EAU22274 EAU22393 Brake light switches Checking the front and rear Yamaha dealer replace the brake pads brake pads as a set. The front and rear brake pads must be checked for wear at the intervals spec-...

  • Page 71: Checking The Brake Fluid Level

    Periodic maintenance and adjustment  Use only the specified brake flu- Rear brake EAU22582 Checking the brake fluid level id; otherwise, the rubber seals Before riding, check that the brake fluid may deteriorate, causing leak- is above the minimum level mark. age.

  • Page 72: Changing The Brake Fluid

    EAU22733 EAU22762 Changing the brake fluid Drive chain slack Yamaha dealer check the cause before Have a Yamaha dealer change the The drive chain slack should be further riding. brake fluid at the intervals specified in...
  • Page 73 EAU57970 To adjust the drive chain slack rection (a). To loosen the drive Consult a Yamaha dealer before ad- Using the alignment marks and notch chain, turn the adjusting bolt on justing the drive chain slack.

  • Page 74: Cleaning And Lubricating The Drive Chain

    Periodic maintenance and adjustment may contain substances that EAU23026 Cleaning and lubricating the could damage O-rings. drive chain [ECA11112] The drive chain must be cleaned and lubricated at the intervals specified in the periodic maintenance and lubrica- tion chart, otherwise it will quickly wear out, especially when riding in dusty or wet areas.

  • Page 75: Checking And Lubricating The Cables

    Yamaha dealer at the intervals bricated if necessary. cated if necessary. If a cable is specified in the periodic maintenance...

  • Page 76: Checking And Lubricating The Brake And Clutch Levers

    Periodic maintenance and adjustment EAU23144 Recommended lubricant: Recommended lubricants: Checking and lubricating the Lithium-soap-based grease Brake lever: brake and clutch levers Silicone grease The operation of the brake and clutch Clutch lever: Lithium-soap-based grease levers should be checked before each ride, and the lever pivots should be lu- bricated if necessary.

  • Page 77: Checking And Lubricating The Sidestand

    The swingarm pivots must be lubricat- ce and hold it in an upright posi- be checked before each ride, and the ed by a Yamaha dealer at the intervals tion. WARNING! To avoid injury, sidestand pivot and metal-to-metal specified in the periodic maintenance...

  • Page 78: Checking The Steering

    [EWA10752] the periodic maintenance and lubrica- 2. Hold the lower ends of the front have a Yamaha dealer check or re- tion chart. If there is play in the wheel fork legs and try to move them for- pair it.

  • Page 79: Battery

    To charge the battery  Electrolyte is poisonous and ge it if necessary. Have a Yamaha dealer charge the bat- 3. Fully charge the battery before dangerous since it contains sul- installation. NOTICE: When in-...

  • Page 80: Replacing The Fuses

    Periodic maintenance and adjustment key is turned to “OFF”, then EAU57985 Replacing the fuses connect the positive lead before Fuse box 1 is located behind the right connecting the negative lead. side panel. [ECA16841] To access fuse box 1, remove and in- 4.
  • Page 81 Periodic maintenance and adjustment To access the fuel injection system fuse, remove the starter relay cover by pulling it upward. 1. Ignition fuse 1. Fuse box 2 2. Parking lighting fuse 2. Main fuse 3. Auxiliary fuse 3. Fuel injection system fuse 4.

  • Page 82: Replacing The Headlight Bulb

    4. If the fuse immediately blows lens. again, have a Yamaha dealer 1. Bolt Do not use a headlight bulb of a check the electrical system. wattage higher than specified.
  • Page 83 Periodic maintenance and adjustment 1. Bolt 1. Grommet 1. Headlight coupler 2. Headlight unit side cover 4. Disconnect the auxiliary light cou- 6. Remove the headlight bulb cover. 2. Pull up the headlight unit cover to pler. separate it from the headlight unit. 1.

  • Page 84: Replacing An Auxiliary Light Bulb

    13. Install the grommets. coupler. 14. Place the headlight unit side cov- 1. Bolt ers in their original position, and then install the bolts. 15. Have a Yamaha dealer adjust the headlight beam if necessary. 7-35...

  • Page 85: Brake/Tail Light

    Brake/tail light This model is equipped with an LED- type brake/tail light. If the brake/tail light does not come on, have a Yamaha dealer check it. 1. Bolt 1. Auxiliary light bulb 2. Headlight unit side cover 4. Insert a new bulb into the socket.

  • Page 86: Replacing A Turn Signal Light Bulb

    Periodic maintenance and adjustment 6. Install the turn signal light unit by EAU43006 Replacing a turn signal light installing the screw. NOTICE: Do bulb not overtighten the screw, oth- 1. Remove the turn signal light unit erwise the lens may break. by removing the screw.

  • Page 87: Replacing The License Plate Light Bulb

    Periodic maintenance and adjustment EAU58010 EAU24351 Replacing the license plate Supporting the motorcycle light bulb Since this model is not equipped with a centerstand, follow these precautions 1. Remove the license plate light unit when removing the front and rear by removing the nuts and collars, wheel or performing other mainte- and then remove the license plate...

  • Page 88: Front Wheel

    Periodic maintenance and adjustment a jack either under each side of the 2. Lift the front wheel off the ground EAU24361 Front wheel frame in front of the rear wheel or under according to the procedure in the each side of the swingarm. previous section “Supporting the EAU56270 motorcycle”.

  • Page 89: Rear Wheel

    Periodic maintenance and adjustment 2. Insert the wheel axle. 4. Fully loosen the locknut on each EAU25081 Rear wheel 3. Install the brake calipers by install- side of the swingarm. ing the bolts. 5. Turn the drive chain slack adjust- EAU56701 ing bolts fully in direction (a) and push the wheel forward.
  • Page 90 Periodic maintenance and adjustment  Make sure that there is enough 7. While supporting the brake caliper Tightening torques: bracket, pull the wheel axle out, space between the brake pads Axle nut: and then remove the wheel. before installing the wheel. 150 Nm (15 m·kgf, 108 ft·lbf) NOTICE: Do not apply the brake Locknut:...

  • Page 91: Troubleshooting

    The following troubleshooting charts represent quick and easy procedures for checking these vital systems your- self. However, should your motorcycle require any repair, take it to a Yamaha dealer, whose skilled technicians have the necessary tools, experience, and know-how to service the motorcycle properly.

  • Page 92: Troubleshooting Charts

    Remove the spark plugs and check the electrodes. The engine does not start. Have a Yamaha dealer check the vehicle. Check the compression. 4. Compression The engine does not start. There is compression.
  • Page 93 Start the engine. If the engine overheats again, have a The coolant level Yamaha dealer check and repair the cooling system. is OK. If coolant is not available, tap water can be temporarily used instead, provided that it is changed to the recommended cool- ant as soon as possible.

  • Page 94: Motorcycle Care And Storage

    Some models are equipped with matte colored finished parts. Be ble. Rust and corrosion can develop Cleaning sure to consult a Yamaha dealer for even if high-quality components are ECA10773 NOTICE used. A rusty exhaust pipe may go un-...
  • Page 95 Motorcycle care and storage off any detergent residue using shield. Test the product on a plenty of water, as it is harmful small hidden part of the wind- Salt sprayed on roads in the winter to plastic parts. shield to make sure that it does may remain well into spring.

  • Page 96: Storage

    EWA11132 poorly ventilated room or cover- WARNING ing it with a tarp, while it is still  Consult a Yamaha dealer for ad- Contaminants on the brakes or tires wet, will allow water and humid- can cause loss of control.
  • Page 97 Motorcycle care and storage 2. Fill up the fuel tank and add fuel e. Remove the spark plug caps stabilizer (if available) to prevent from the spark plugs, and then Make any necessary repairs before the fuel tank from rusting and the install the spark plugs and the storing the motorcycle.

  • Page 98: Specifications

    Specifications Dimensions: Compression ratio: Coolant quantity: 11.5 : 1 Overall length: Coolant reservoir (up to the maximum level Starting system: 2075 mm (81.7 in) mark): Electric starter Overall width: 0.25 L (0.26 US qt, 0.22 Imp.qt) Lubrication system: 815 mm (32.1 in) Radiator (including all routes): Wet sump Overall height:...
  • Page 99 Specifications Secondary reduction ratio: Rear tire: Rim size: 2.813 (45/16) 17M/C x MT5.50 Type: Transmission type: Front brake: Tubeless Constant mesh 6-speed Size: Type: Gear ratio: 180/55 ZR17 M/C (73W) Hydraulic dual disc brake 1st: Manufacturer/model: Specified brake fluid: 2.667 (40/15) BRIDGESTONE/S20R DOT 4 2nd:...
  • Page 100 Specifications Voltage, capacity: Fuse(s): 12 V, 8.6 Ah (10 HR) Main fuse: Headlight: 50.0 A Bulb type: Auxiliary fuse: Halogen bulb 2.0 A Bulb wattage × quantity: Headlight fuse: 15.0 A Headlight: Signaling system fuse: H4, 60.0 W/55.0 W x 1 7.5 A Brake/tail light: Ignition fuse:...

  • Page 101: Consumer Information

    Vehicle identification number ed when registering the vehicle with the authorities in your area and when EAU26442 Engine serial number ordering spare parts from a Yamaha dealer. VEHICLE IDENTIFICATION NUMBER: 1. Vehicle identification number ENGINE SERIAL NUMBER: The vehicle identification number is 1.
  • Page 102 This information will it for reference when ordering a new illustration. This label shows specifica- be needed when ordering spare parts key. tions related to exhaust emissions as from a Yamaha dealer. required by federal law, state law and Environment Canada. 10-2...

  • Page 103: Maintenance Record

    Consumer information EAU26643 Maintenance record Copies of work orders and/or receipts for parts purchased and installed on your vehicle will be required to document that maintenance has been completed in accordance with the emissions warranty. The chart below is printed only as a reminder that maintenance work is required.
  • Page 104 Consumer information Maintenance Date of Servicing dealer Mileage Remarks interval service name and address 55000 km (36000 mi) or 54 months 61000 km (40000 mi) or 60 months 10-4...

  • Page 105: Yamaha Motor Canada Ltd

    In this warranty, the term ‘MOTORCYCLE’ shall refer to a new or YZ, with the exception of WR25R, WR25X and YZ85 change of registration is sent to YAMAHA at the time of such motorcycle manufactured by YAMAHA MOTOR COMPANY, LTD.
  • Page 106 CUSTOMER at the time of DELIVERY. fitness for a particular purpose on the part of YAMAHA, and any other obligation or liability on behalf of YAMAHA, and the above...

  • Page 107: Index

    Index Engine serial number ......10-1 Model label ........... 10-2 Engine trouble warning light ....4-3 Multi-function meter unit ......4-4 Air filter element........7-15 Auxiliary DC connector......4-24 Auxiliary light bulb, replacing ....7-35 Front and rear brake pads, checking ... 7-21 Neutral indicator light ......
  • Page 108 Index Troubleshooting charts......7-43 Turn signal indicator light .......4-2 Turn signal light bulb, replacing....7-37 Turn signal switch .........4-11 Valve clearance........7-16 Vehicle Emission Control Information label ............10-2 Vehicle identification number ....10-1 Warranty ..........10-5 Wheel bearings, checking.....7-29 Wheel (front)..........7-39 Wheel (rear)...........7-40 Wheels ..........7-19 11-2...
  • Page 109 Yamalube – Take care of your Yamaha with legendary Yamalube oils, lubricants, and care products. They’re formulated and approved by the toughest judges we know: the Yamaha engineering teams that know your Yamaha from the inside out.
  • Page 110 PRINTED ON RECYCLED PAPER PRINTED IN JAPAN 2015.08-0.3×1 CR...
