4K UHD Monitor
Instructions for Use
FM-A2701D
FM-A2701DS
FM-B2702D
FM-B2702DG
FM-E2701D
FM-E2701DG
FM-E2701DT
FM-E2701DGT
FM-F2701D
FM-F2701DG
Before connecting, operating or adjusting this product, please
read this instruction booklet carefully and completely.
English
FM-F3101D
FM-F3101DG
FS-P3102D
FS-P3102DS
FS-P3102DG
FM-E3203D
FM-E3203DG

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FM-F3101D and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for FSN FM-F3101D

Summary of Contents for FSN FM-F3101D

  • Page 1 4K UHD Monitor Instructions for Use FM-A2701D FM-F3101D FM-A2701DS FM-F3101DG FM-B2702D FS-P3102D FM-B2702DG FS-P3102DS FM-E2701D FS-P3102DG FM-E2701DG FM-E3203D FM-E2701DT FM-E3203DG FM-E2701DGT FM-F2701D FM-F2701DG Before connecting, operating or adjusting this product, please read this instruction booklet carefully and completely. English...

  • Page 2: Table Of Contents

    Table of Contents Product Description / Intended Use ....3 Symbol Defi nitions ......4 Warnings and Precautions .

  • Page 3: Product Description / Intended Use

    Product Description / Intended Use This product from FSN Medical Technologies is a high-end surgical display monitor designed for advanced digital OR applications. This medical display is uniquely equipped to handle tasks in the demanding operating room environment. Performance characteristics include: •...

  • Page 4: Symbol Defi Nitions

    Symbol Defi nitions The following symbols appear on the product, its labeling, or the product packing. Each symbol carries a special defi nition, as defi ned below: Dangerous : High Consult accompanying Power adapter Voltage documents lndicates equipotential Direct current Unique Device Identifi er earth ground Indicates protective...

  • Page 5: Warnings And Precautions

    Warnings and Precautions Caution Information CAUTION RISK OF ELECTRICAL SHOCK DO NOT OPEN This symbol alerts the user that important literature concerning the operation of this unit has been included. Therefore, it should be read carefully in order to avoid potential problems. This symbol warns users that un-insulated voltage within the unit may have suffi cient magnitude to cause electrical shock.
  • Page 6 Use the proper power cord with correct attachment plug type. If the power source is 120 V AC, use a power cord which is a Hospital Grade Power Cord with NEMA 5-15 style plug, labeled for 125 volts AC with UL and C-UL approvals. If the power source is a 240 V AC supply, use the tan- dem (T blade) type attachment plug with ground conductor power cord that meets the respec- tive European country’s safety regulations.

  • Page 7: Safety Instructions

    Safety Instructions On Safety 1. Before connecting the AC power cord to the DC adapter outlet make sure the voltage desig- nation of the DC adapter corresponds to the local electrical supply. 2. Never insert anything metallic into the cabinet openings of the medical monitor. Doing so may create the danger of electric shock.

  • Page 8: Environmental Conditions For Operation And Storage

    Environmental Conditions for Operation and Storage Temperature range within 0°C to 40°C(operation), -20°C to 60°C (storage) Relative humidity range 10% to 85% Atmospheric pressure range within 500 to 1060hPa. On Installation 1. Openings in the medical monitor cabinet are provided for ventilation. To prevent overheat- ing, these openings should not be blocked or covered.
  • Page 9 Returned Product After troubleshooting, if problems persist, disinfect the monitor and return it to FSN using the original packaging. Include the accessories that came with the monitor in the return shipment. Please enclose a brief explanation of the malfunction.

  • Page 10: Electromagnetic Compatibility

    Electromagnetic Compatibility This medical monitor unit has been designed and tested to comply with IEC 60601-1-2:2014/ AMD1:2020 requirements for EMC with other devices. To ensure electromagnetic compatibility (EMC), the monitor must be installed and operated according to the EMC information provided in this Instructions for Use.
  • Page 11 1. Guidance and manufacturer’s declaration - electromagnetic emission The medical monitor is intended for use in the electromagnetic environment specifi ed below. The user of the device should make sure that the medical monitor is operated in such an environment. Interference emission measurements Conformity level Electromagnetic environment -guidance...
  • Page 12 3. For the use of ME devices in professional healthcare facilities. Test specifi cation for ENCLOSURE PORT IMMUNITY to RF wireless communica- tions equipment (according to IEC 60601-1-2:2014) The medical monitor is intended for use in the electromagnetic environment specifi ed below. The user of the medical monitor should make sure that it is used in such an environment.
  • Page 13 4. Guidance and manufacturer’s declaration – electromagnetic immunity – for equipment and systems that are not life-supporting The medical monitor is intended for use in the electromagnetic environment specifi ed below. The user of the medical monitor should make sure that it is used in such an environment. Interference IEC 60601-1- Conformity...

  • Page 14: Connecting The Power Supply

    Maximum DC Extension Cable Length* (feet) FM-A2701D, FM-A2701DS, FM-B2702D, FM-B2702DG, FM-E2701D, FM-E2701DG, FM-E2701DT, FM-E2701DGT, FS-P3102D, FS-P3102DS, FS-P3102DG, FM-E3203D, FM-E3203DG FM-F2701D, FM-F2701DG, , FM-F3101D, FM-F3101DG * If longer extension is used, there is a risk of abnormal operation of the product. 10/2023...

  • Page 15: Accessories

    Accessories Display- SDI BNC AC Power AC-DC HDMI DVI-D Mounting Item Port Cable Cord Adaptor Cable Cable Screws 6.23ft/1.9m 6ft/1.8m* Cable        27” FM-A2701D         27” FM-A2701DS ...
  • Page 16  27” FM-F2701D       x1  27” FM-F2701DG       31” FM-F3101D       x1  31” FM-F3101DG        31” FS-P3102D ...

  • Page 17: Mechanical Drawings

    FM-A2701D 60 / 2.36 658.8 mm / 25.94 in. 8-M4 200 / 7.87 VESA 100 / 3.94 3.94 16.77 DISPLAY DC ON/OFF DISPLAY PORT 1 GROUND SWITCH (SVC) PORT 2 IN OUT IN OUT 2 DC IN RS232C GPIO HDMI OUT 1 FM-A2701DS DISPLAY...
  • Page 18 FM-B2702D 673 mm / 26.5 in. 7.87 8-M4 3.94 VESA 3.94 16.73 187.3 7.37 44.6 1.76 75.2 2.96 DISPLAY DISPLAY PORT 2 IN PORT 1 GROUND RS232C (SVC) OUT IN OUT 2 DC IN GPIO HDMI OUT 1 FM-B2702DG DISPLAY SDI 4 SDI 3 SDI 2...
  • Page 19 FM-E2701D GPIO USB IN HDMI 1 HDMI 1 HDMI DISPLAY 5V DC 12V DC GROUND DC IN (SVC) 2 IN PORT 1 IN RS232C FM-E2701DG SDI 1 SDI 2 GPIO 12G/3G 12G/3G USB IN HDMI 1 HDMI 1 HDMI DISPLAY 5V DC 12V DC GROUND...
  • Page 20 FM-F2701D 54.9 2.16 654.8 mm / 25.78 in. 1.77 401.2 15.80 7.87 3.94 8-M4 VESA mount 3.94 holes (cover plate) GPIO HDMI 2 DC OUT GROUND HDMI 1 DISPLAY 5V 12V INLET (SVC) OUT IN PORT IN RS232C FM-F2701DG SDI 1 SDI 2 GPIO HDMI 2...
  • Page 21 FM-F3101D 54.7 2.15 757 mm / 29.8 in. 44.8 1.76 18.27 7.87 3.94 16-M4 1.97 5.91 VESA mount holes (cover plate) DISPLAY HDMI 1 HDMI 2 PORT DC OUT GROUND INLET (SVC) GPIO OUT IN 5V 12V RS232C FM-F3101DG SDI 1...
  • Page 22 FS-P3102D 75.5 / 2.97 773.1 mm / 30.44 in. 1.77 453.6 17.86 7.87 3.94 8-M4 3.94 VESA MOUNT HOLES 176.8 6.96 DISPLAY DISPLAY PORT 1 GROUND RS232C (SVC) OUT 2 PORT 2 IN OUT IN DC IN GPIO HDMI OUT 1 FS-P3102DS SDI 4 SDI 3...
  • Page 23 FM-E3203D 773 mm / 30.43 in. 18.82 44.6 1.76 75.2 7.87 2.96 3.94 1.97 8-M4 3.94 VESA MOUNT HOLES 188.8 DISPLAY DISPLAY PORT 1 GROUND RS232C (SVC) PORT 2 IN OUT 2 OUT IN DC IN GPIO HDMI OUT 1 FM-E3203D DISPLAY SDI 4...

  • Page 24: Controls

    Controls On Screen Display (OSD) FM-A2701D, FM-A2701DS, FM-B2702D, FM-B2702DG, FM-E2701D, FM-E2701DG, FM-E2701DT, FM-E2701DGT, FS-P3102D, FS-P3102DS, FS-P3102DG, FM-E3203D, FM-E3203DG When the OSD menu is When the OSD menu is Press to enable PIP (Pic- Press to turn power on/ activated, press to de- activated, press to move ture in Picture) function.
  • Page 25 Controls On Screen Display (OSD) FM-F2701D, FM-F2701DG, FM-F3101D, FM-F3101DG Press to turn power on/ When the OSD menu When the OSD menu is Press to enable PIP (Pic- off to the display’s front is activated, press to activated, press to move ture in Picture) function.

  • Page 26: On Screen Display (Osd)

    FM-A2701D, FM-A2701DS, FM-B2702D, FM-B2702DG, FS-P3102D, FS-P3102DS, FS-P3102DG, FM-E3203D, FM-E3203DG FSN display monitors come equipped with a rich set of features for system set-up, image adjustments, and screen layout control. These features are managed through the On Screen Display, or OSD. Some options presented in the OSD are contextual and vary depending on the active input signal.
  • Page 27 On Screen Display (OSD) Menus Submenus under the COLOR menu 1. GAMMA Select the appropriate gamma. (BYPASS,1.8, 2.0, 2.2, 2.4, 2.6, DICOM). Gamma cannot be changed when color space is BT.709. 2. COLOR SPACE Select the color space setting. (NATIVE, BT.709, BT.2020, or AUTO) NATIVE: for native color setting.
  • Page 28 FM-E2701D, FM-E2701DG, FM-E2701DT, FM-E2701DGT, FM-F2701D, FM-F2701DG, FM-F3101D, FM-F3101DG FSN display monitors come equipped with a rich set of features for system set-up, image adjustments, and screen layout control. These features are managed through the On Screen Display, or OSD. Some options presented in the OSD are contextual and vary depending on the active input signal.
  • Page 29 On Screen Display (OSD) Menus Submenus under the COLOR menu 1. GAMMA Select the appropriate gamma. (1.8, 2.0, 2.2, 2.4, 2.6, DICOM,BYPASS, PQ(EOTF), HLG). User can only select from 1.8 to BYPASS. According to the HDR mode appropriate gamma (PQ or HLG) is set. 2.

  • Page 30: Window Layout

    Window Layout FM-A2701D, FM-A2701DS, FM-B2702D, FM-B2702DG, FS-P3102D, FS-P3102DS, FS-P3102DG, FM-E3203D, FM-E3203DG Single Window Picture in Picture (PIP) Picture by Picture (PBP) Window 2 Window 1 Window 1 Window 2 SDI Source Compatibility 3G-SDI Single 3G-SDI 2-SI 3G-SDI Quad (1080p 60Hz) 1 2 3 4…...
  • Page 31 Window Layout FM-E2701D, FM-E2701DG, FM-E2701DT, FM-E2701DGT, FM-F2701D, FM-F2701DG, FM-F3101D, FM-F3101DG Single Window Picture in Picture (PIP) Picture by Picture (PBP) Mode 1 Mode 2 Mode 3 Triple Mode 1 Mode 2 Mode 3 Mode 4 10/2023...
  • Page 32 Window Layout FM-E2701D, FM-E2701DG, FM-E2701DT, FM-E2701DGT, FM-F2701D, FM-F2701DG, FM-F3101D, FM-F3101DG Quad Mode 1 Mode 2 Mode 3 Mode 4 Mode 5 10/2023...

  • Page 33: Standard Signal Table

    Standard Signal Table FM-A2701D, FM-A2701DS, FM-B2702D, FM-B2702DG, FS-P3102D, FS-P3102DS, FS-P3102DG, FM-E3203D, FM-E3203DG Timing Information Signal Source Resolution H-Freq (KHz) V-Freq (Hz) Clock (MHz) HDMI • • • 800 x 600 @56Hz 35.16 56.25 36.00 • • • 800 x 600 @60Hz 37.88 60.32 40.00...
  • Page 34 Standard Signal Table FM-E2701D, FM-E2701DG, FM-E2701DT, FM-E2701DGT, FM-F2701D, FM-F2701DG, FM-F3101D, FM-F3101DG Timing Information Signal Source Resolution H-Freq (KHz) V-Freq (Hz) Clock (MHz) HDMI • • 800 x 600 @56Hz 35.16 56.25 36.00 • • 800 x 600 @60Hz 37.88 60.32 40.00...

  • Page 35: General Specifi Cations

    Specifi cation FM-A2701D, FM-A2701DS Item Description Panel 27 inch TFT LCD (LED) Resolution 3840 x 2160 pixels Aspect Ratio 16 : 9 Active Area 596.74 (H)mm x 335.66 (V)mm Pixel Pitch (mm) 0.1554 x 0.1554 Response Time (typical) 14 ms (gray to gray) Number of Colors 1.07 Billion Brightness (typical)
  • Page 36 Specifi cation FM-B2702D, FM-B2702DG Item Description Panel 27 inch TFT LCD (LED) Resolution 3840 x 2160 pixels Aspect Ratio 16 : 9 Active Area 596.74 (H)mm x 335.66 (V)mm Pixel Pitch (mm) 0.1554 x 0.1554 Response Time (typical) 11 ms (rise time) Number of Colors 1.07 Billion Brightness (typical)
  • Page 37 Specifi cation FM-E2701D, FM-E2701DG, FM-E2701DT, FM-E2701DGT Item Description Panel 27 inch LCD (LED) Resolution 3840 x 2160 pixels Active Area 596.16 (H)mm x 335.34 (V)mm Touchscreen (FM-E2701DT, DGT) Projected Capacitive USB Pixel Pitch (mm) 0.15525 x 0.15525 Response Time (typical) <...
  • Page 38 Specifi cation Touchscreen Item Description Type ITO Projected Capacitive touch screen Operating Voltage Transparency > 85% Interface USB (1.1) Touch Point 10 points Touchscreen OS Support Version Windows 10 IOT / Windows 10 / Windows 8 / Windows 7 / Windows Vista / Windows Windows 2000 / Windows XP Win Embedded Compact 2013 / Win Embedded Compact 7 / Win CE 6 /...
  • Page 39 Specifi cation FM-F2701D, FM-F2701DG Item Description Panel 27 inch OLED Resolution 3840 x 2160 pixels Active Area 596.16 (H)mm x 335.34 (V)mm Pixel Pitch (mm) 0.15525 x 0.15525 Response Time (typical) < 0.1 ms (rise + fall time) Pixels Arrangement RGB vertical stripes Number of Colors 1.07 Billion...
  • Page 40 2 x SDI (3G, 12G) available on FM-F3101DG Power Input AC/DC Adaptor (AC 100~240V, DC 24V/6.6A) Power Output DC Output (1 x 12V/2A, 1 x 5V/2A) 140W max (FM-F3101D) Power Consumption 155W max (FM-F3101DG) Latency (typical) 1 ms 757(W) x 464(H) x 54.7(D) mm Unit Dimension 29.8(W) x 18.27(H) x 2.15(D) inch...
  • Page 41 Specifi cation FS-P3102D, FS-P3102DS, FS-P3102DG Item Description Panel 31 inch TFT LCD (LED) Resolution 4096 x 2160 pixels Aspect Ratio 17 : 9 Active Area 697.958 (H)mm x 368.064 (V)mm Pixel Pitch (mm) 0.1704 x 0.1704 Response Time (typical) 11 ms (rise time) Number of Colors 1.07 Billion Brightness (typical)
  • Page 42 Specifi cation FM-E3203D, FM-E3203DG Item Description Panel 32 inch TFT LCD (LED) Resolution 3840 x 2160 pixels Aspect Ratio 16 : 9 Active Area 708.48 (H)mm x 398.82 (V)mm Pixel Pitch (mm) 0.1845 x 0.1845 Response Time (typical) 8 ms (rise time) Number of Colors 1.07 Billion Brightness (typical)

  • Page 43: Cleaning Instructions

    Cleaning Instructions Follow your hospital protocol for the handling of blood and body fl uids. Clean the display with a diluted mixture of mild detergent and water. Use a soft cotton towel or swab. Use of certain detergents may cause degradation to the labels and plastic components of the product. Consult cleanser manufacturer to see if agent is compatible.
  • Page 44 Thank you for choosing our product. Service Contact the appropriate customer service listed below for product information or assistance. Warranty One year, parts and labor. EC Representative KTR Europe GmbH Mergenthalerallee 77, Eschborn 65760, Germany Tel : +49(0)6196-887170 FORESEESON GmbH Industriestrasse 38a, 63150 Heusenstamm, Germany Tel.
