4K UHD Monitor
Instructions for Use
FM-E3203DC
FM-E3204DGC
FM-A5502DC
FM-A5503DC
FM-A5505DGC
Before connecting, operating or adjusting this product, please
read this instruction booklet carefully and completely.
English

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FM-E3203DC and is the answer not in the manual?

Questions and answers

Related Manuals for FSN FM-E3203DC

Summary of Contents for FSN FM-E3203DC

  • Page 1 4K UHD Monitor Instructions for Use FM-E3203DC FM-E3204DGC FM-A5502DC FM-A5503DC FM-A5505DGC Before connecting, operating or adjusting this product, please read this instruction booklet carefully and completely. English...

  • Page 2: Table Of Contents

    Table of Contents Product Description / Intended Use ....3 Symbol Defi nitions ......4 Safety Instructions .

  • Page 3: Product Description / Intended Use

    Product Description / Intended Use This product from FSN Medical Technologies is a high-end surgical display monitor designed for advanced digital OR applications. This medical display is uniquely equipped to handle tasks in the demanding operating room environment. Performance characteristics include: •...

  • Page 4: Symbol Defi Nitions

    Symbol Defi nitions The following symbols appear on the product, its labeling, or the product packing. Each symbol carries a special defi nition, as defi ned below: Dangerous : High Consult accompanying Power adapter Voltage documents lndicates equipotential Direct current Unique Device Identifi er earth ground Indicates protective...

  • Page 5: Safety Instructions

    EU Medical Devices Regulation (MDR 2017/745). CE class I medical device accessory. This medical monitor complies to the above standards only when used with the supplied medi- cal grade power supply (FM-E3203DC, FM-E3204DGC). Use 120V rating 5-15P type plug only in the U.S.
  • Page 6 Use the proper power cord with correct attachment plug type. If the power source is 120 V AC, use a power cord which is a Hospital Grade Power Cord with NEMA 5-15 style plug, labeled for 125 volts AC with UL and C-UL approvals. If the power source is a 240 V AC supply, use the tan- dem (T blade) type attachment plug with ground conductor power cord that meets the respec- tive European country’s safety regulations.
  • Page 7 Safety Instructions On Safety 1. Before connecting the AC power cord to the DC adapter outlet make sure the voltage desig- nation of the DC adapter corresponds to the local electrical supply. 2. Never insert anything metallic into the cabinet openings of the medical monitor. Doing so may create the danger of electric shock.
  • Page 8 Environmental Conditions for Operation and Storage Temperature range within 0°C to 40°C(operation), -20°C to 60°C (storage) Relative humidity range 10% to 85% Atmospheric pressure range within 500 to 1060hPa. On Installation 1. Openings in the medical monitor cabinet are provided for ventilation. To prevent overheat- ing, these openings should not be blocked or covered.
  • Page 9 Returned Product After troubleshooting, if problems persist, disinfect the monitor and return it to FSN using the original packaging. Include the accessories that came with the monitor in the return shipment. Please enclose a brief explanation of the malfunction.

  • Page 10: Electromagnetic Compatibility

    Electromagnetic Compatibility This medical monitor unit has been designed and tested to comply with IEC 60601-1-2:2014/ AMD1:2020 requirements for EMC with other devices. To ensure electromagnetic compatibility (EMC), the monitor must be installed and operated according to the EMC information provided in this Instructions for Use.
  • Page 11 1. Guidance and manufacturer’s declaration - electromagnetic emission The medical monitor is intended for use in the electromagnetic environment specifi ed below. The user of the device should make sure that the medical monitor is operated in such an environment. Interference emission measurements Conformity level Electromagnetic environment -guidance...
  • Page 12 3. For the use of ME devices in professional healthcare facilities. Test specifi cation for ENCLOSURE PORT IMMUNITY to RF wireless communica- tions equipment (according to IEC 60601-1-2:2014) The medical monitor is intended for use in the electromagnetic environment specifi ed below. The user of the medical monitor should make sure that it is used in such an environment.
  • Page 13 4. Guidance and manufacturer’s declaration – electromagnetic immunity – for equipment and systems that are not life-supporting The medical monitor is intended for use in the electromagnetic environment specifi ed below. The user of the medical monitor should make sure that it is used in such an environment. Interference IEC 60601-1- Conformity...
  • Page 14 (m) can be estimated using the equation applicable to the frequency of the transmitter, where is the maximum output power rating of the transmitter in watts (W) according to the transmitter manufacturer. Connecting the Power Supply FM-E3203DC, FM-E3204DGC Power input on AC power. AC-DC back of monitor.

  • Page 15: Accessories

    Cable Port Cable 3D Glasses Cable Control Screws 6.23ft/1.9m 6ft/1.8m* 6.56ft/2m Cable         FM-E3203DC          FM-E3204DGC        FM-A5502DC ...

  • Page 16: Mechanical Drawings

    FM-E3203DC 760 mm / 29.92 in. 7.87 3.94 1.97 8-M4 18.31 3.94 VESA MOUNT HOLES 182.3 7.18 35.6 1.40 70.4 2.77 DISPLAY DISPLAY PORT 1 GROUND RS232C (SVC) PORT 2 IN OUT IN OUT 2 DC IN GPIO HDMI OUT 1...
  • Page 17 FM-A5502DC 84 / 3.31 1268.5 mm / 49.94 in. 33.5 1.32 RS232C DVI IN 753.3 29.66 DVI OUT USB (SVC) GPIO HDMI DISPLAY PORT 2 IN DISPLAY PORT 1 OUT DISPLAY PORT 1 IN 800 / 31.5 400 / 15.75 ON/OFF SWITCH AC INLET...
  • Page 18 FM-A5505DGC 85 / 3.35 1268.5 mm / 49.94 in. 1.30 600 / 23.62 621.5 24.47 15.75 753.3 29.66 SDI 4 SDI 3 SDI 2 SDI 1 ON/OFF 12G/3G 12G/3G DISPLAY 5V OUT GROUND INLET SWITCH IN OUT IN OUT IN OUT IN OUT RS232C PORT 2 IN...

  • Page 19: Controls

    Controls On Screen Display (OSD) FM-E3203DC , FM-A5502DC, FM-A5503DC When the OSD menu is When the OSD menu is Press to enable PIP (Pic- Press to turn power on/ activated, press to de- activated, press to move ture in Picture) function.

  • Page 20: On Screen Display (Osd)

    On Screen Display (OSD) Menus FSN display monitors come equipped with a rich set of features for system set-up, image adjustments, and screen layout control. These features are managed through the On Screen Display, or OSD. Some options presented in the OSD are contextual and vary depending on the active input signal.
  • Page 21 On Screen Display (OSD) Menus FM-E3203DC Submenus under the COLOR menu 1. GAMMA Select the appropriate gamma. (BYPASS,1.8, 2.0, 2.2, 2.4, 2.6, DICOM). Gamma cannot be changed when color space is BT.709. 2. COLOR SPACE Select the color space setting. (NATIVE, BT.709, BT.2020, or AUTO) NATIVE: for native color setting.
  • Page 22 On Screen Display (OSD) Menus FM-E3204DGC Video Source Information Main Menu Sub Menu Value Categories or Setting Sub Menu Categories Submenus under the PICTURE menu 1. BRIGHTNESS Increases or decrease the brightness. (Range : 0~100) 2. CONTRAST Increases or decreases the contrast. (Range : 0~100) 3.
  • Page 23 On Screen Display (OSD) Menus FM-E3204DGC Submenus under the SETUP menu 1. LANGUAGE Changes the OSD language. (10 languages) 2. OSD OVERLAY Adjusts the OSD transparency. 3. OSD POSITION Changes the OSD position. (9 Positions) 4. OSD MENU TIME Adjusts the length of time the OSD Menu is present on the screen. (range: 10~60 seconds) 5.
  • Page 24 On Screen Display (OSD) Menus FM-A5502DC Sub Menu Categories Main Menu Sub Menu Categories Value or Setting Video Source Information Submenus under the COLOR ADJUSTMENT menu 1. BRIGHTNESS Increases or decrease the brightness. (Range : 0~100) 2. CONTRAST Increases or decreases the contrast. (Range : 0~100) 3.
  • Page 25 On Screen Display (OSD) Menus FM-A5502DC Submenus under the OSD SETTING menu 1. LANGUAGE Changes the OSD language. (10 languages) 2. OSD TRANS Adjusts the OSD transparency. 3. OSD POSITION Changes the OSD position. (9 Positions) 4. OSD MENU TIME Adjusts the length of time the OSD Menu is present on the screen. (range: 10~60 seconds) 5.
  • Page 26 On Screen Display (OSD) Menus FM-A5503DC Submenus under the COLOR menu 1. GAMMA Select the appropriate gamma. (BYPASS,1.8, 2.0, 2.2, 2.4, 2.6, DICOM). 2. COLOR SPACE Select the color space setting. (NATIVE, sRGB, BT.2020, or AUTO) 3. COLOR MODE Changes the image color setting. (C1, C2, C3, USER) 4.
  • Page 27 On Screen Display (OSD) Menus FM-A5503DC Submenus under the LAYOUT menu - Single 1. LAYOUT Changes the image layout. (Single, PIP, PBP) Submenus under the LAYOUT menu - PIP 1. LAYOUT Changes the image layout. (Single, PIP, PBP) 2. MODE Changes the sub layout mode of multi window layout. Refer to Window Layout examples.
  • Page 28 On Screen Display (OSD) Menus FM-A5505DGC Submenus under the COLOR menu 1. GAMMA Select the appropriate gamma. (BYPASS,1.8, 2.0, 2.2, 2.4, 2.6, DICOM). 2. COLOR SPACE Select the color space setting. (NATIVE, sRGB, BT.2020, or AUTO) 3. COLOR MODE Changes the image color setting. (C1, C2, C3, USER) 4.
  • Page 29 On Screen Display (OSD) Menus FM-A5505DGC Submenus under the LAYOUT menu - Single 1. LAYOUT Changes the image layout. (Single, PIP, PBP, Triple, Quad) Submenus under the LAYOUT menu - PIP 1. LAYOUT Changes the image layout. (Single, PIP, PBP, Triple, Quad) 2.

  • Page 30: Window Layouts, 3D Formats

    Window Layout FM-E3203DC, FM-A5502DC Single Window Picture in Picture (PiP) Picture by Picture (PBP) Window 2 Window 1 Window 2 Window 1 Window Layout FM-E3204DGC, FM-A5505DGC Single Window Picture in Picture (PIP) Window 2 Window 1 Picture by Picture (PBP)
  • Page 31 Window Layout FM-E3204DGC, FM-A5505DGC Quad Mode 1 Mode 2 Mode 3 Mode 4 Mode 5 3G-SDI Single 3G-SDI 2-SI 3G-SDI Quad (1080p 60Hz) 1 2 3 4… 1 2 3 4… SDI-1 SDI-1 SDI-2 SDI-2 1 2 3 4… 1 2 3 4… SDI-3 SDI-3 SDI-4...
  • Page 32 Window Layout FM-A5503DC Single Window Picture in Picture (PIP) Window 2 Window 1 Picture by Picture (PBP) Mode 1 Mode 2 Mode 3...
  • Page 33 3D Formats FM-E3204DGC, FM-A5505DGC Side by Side Line by Line Half is left eye image and half is right eye Line interleave format. For example, even lines image. are left eye and odd lines are right eye. Top Bottom SDI Level B-Dual Stream Top is left eye image and bottom is right eye 3G SDI Level B format has an internal dual image.
  • Page 34 Parallax FM-E3204DGC, FM-A5505DGC Parallax controls the distance between corresponding points in the left and right eye image of a stereoscopic image. Negative Parallax Zero Parallax Positive Parallax Parallax Control - Both Parallax Control - Left Parallax Control - Right Adjusts the left and Adjusts the left eye image.

  • Page 35: Standard Signal Tables

    Standard Signal Table FM-E3203DC Timing Information Signal Source Resolution H-Freq (KHz) V-Freq (Hz) Clock (MHz) HDMI • • • 800 x 600 @56Hz 35.16 56.25 36.00 • • • 800 x 600 @60Hz 37.88 60.32 40.00 • • • 800 x 600 @72Hz 48.08...
  • Page 36 Standard Signal Table FM-E3204DGC, FM-A5505DGC Timing Information Signal Source Resolution H-Freq V-Freq Clock HDMI (KHz) (Hz) (MHz) (3G) (12G) • • • 800 x 600 @56Hz 35.16 56.25 36.00 • • • 800 x 600 @60Hz 37.88 60.32 40.00 • •...
  • Page 37 Standard Signal Table FM-A5502DC Timing Information Signal Source Resolution H-Freq V-Freq Clock HDMI (KHz) (Hz) (MHz) • • • 800 x 600 @56Hz 35.16 56.25 36.00 • • • 800 x 600 @60Hz 37.88 60.32 40.00 • • • 800 x 600 @72Hz 48.08 72.19 50.00...
  • Page 38 Standard Signal Table FM-A5503DC Timing Information Signal Source Resolution H-Freq V-Freq Clock HDMI (KHz) (Hz) (MHz) • • • 800 x 600 @56Hz 35.16 56.25 36.00 • • • 800 x 600 @60Hz 37.88 60.32 40.00 • • • 800 x 600 @72Hz 48.08 72.19 50.00...

  • Page 39: General Specifi Cations

    Specifi cation FM-E3203DC Item Description Panel 32 inch TFT LCD (LED) Resolution 3840 x 2160 pixel Aspect Ratio 16 : 9 Active Area 708.48 (H)mm x 398.82 (V)mm Pixel Pitch (mm) 0.1845 x 0.1845 Response Time (typical) 8 ms (rise time) Number of Colors 1.07 Billion...
  • Page 40 Specifi cation FM-E3204DGC Item Description Panel 32 inch TFT LCD (LED) Resolution 3840 x 2160 pixel Aspect Ratio 16 : 9 Active Area 708.48 (H)mm x 398.82 (V)mm Pixel Pitch (mm) 0.1845 x 0.1845 Response Time (typical) 8 ms (rise time) Number of Colors 1.07 Billion Side-by-side, line-by-line, top bottom,...
  • Page 41 Specifi cation FM-A5502DC Item Description Panel 55 inch OLED Resolution 3840 x 2160 pixel Aspect Ratio 16 : 9 Active Area 1209.6 (H)mm x 680.4 (V)mm Pixel Pitch (mm) 0.315 x 0.315 Response Time (typical) 1 ms (gray to gray) Number of Colors 1.07 Billion 430 cd/m²...
  • Page 42 Specifi cation FM-A5503DC Item Description Panel 55 inch OLED Resolution 3840 x 2160 pixels Aspect Ratio 16 : 9 Active Area 1209.6 (H)mm x 680.4 (V)mm Response Time (typical) 0.5 ms (gray to gray) Number of Colors 1.07 Billion (2D) 150 cd/m² (220 cd/m² peak) Brightness (typical) (3D) 90 cd/m²...
  • Page 43 Specifi cation FM-A5505DGC Item Description Panel 55 inch OLED Resolution 3840 x 2160 pixel Aspect Ratio 16 : 9 Active Area 1209.6 (H)mm x 680.4 (V)mm Response Time (typical) 0.5 ms (gray to gray) Number of Colors 1.07 Billion Side-by-side, line-by-line, top bottom, 3D Type SDI level B-DS, SDI dual input.

  • Page 44: Cleaning Instructions

    Cleaning Instructions Follow your hospital protocol for the handling of blood and body fl uids. Clean the display with a diluted mixture of mild detergent and water. Use a soft cotton towel or swab. Use of certain detergents may cause degradation to the labels and plastic components of the product. Consult cleanser manufacturer to see if agent is compatible.
  • Page 48 Thank you for choosing our product. Service Contact the appropriate customer service listed below for product information or assistance. Warranty One year, parts and labor. EC Representative FORESEESON GmbH Industriestrasse 38a, 63150 Heusenstamm, Germany Tel. +49(0)6104-643980 FORESEESON UK Ltd. 1 Wolsey Road, East Molesey Surrey, KT8 9EL United Kingdom Tel.
