- Page 1 iSure Electric Shower INSTRUCTIONS Stock code 8.5 kW - 30309 9.5 kW - 30310 Please read all instructions before installation and leave this document with the end user for future reference as it contains important warranty information...
-
Page 2: Product Features
Eco Setting reduced power setting Power Button Push button on off retains user preferred power and temperature settings Flexible Installation 6 cable entry points 8 water entry points Dual power blocks for left or right wiring Fitting plate retro-fit footprint - Optional Extra General: 01905 823 298 www.akw-ltd.co.uk... -
Page 3: Table Of Contents
Fitting to wall - With Fitting Plate (Optional Extra) ............. Fitting to wall - Without Fitting Plate ................ 13 Reassembly - Bottom Cover .................. 14 Reassembly - Front Cover .................... 15 Plumbing ........................16-17 Electrical ........................18-19 Order: 01905 823 299 orders.akw-ltd.co.uk Technical Support: 01905 560 219... -
Page 4: User
This information is provided on the condition that the installer determines its suitability for each case. -
Page 5: Operating Instructions
The Temperature and Power Level are indicated on their respective controls. Temperature Setting note: Increasing temperature setting reduces flow rate. changes in the water temperature may take a few seconds to reach the handset. Order: 01905 823 299 orders.akw-ltd.co.uk Technical Support: 01905 560 219... -
Page 6: Troubleshooting
Water from non-product issue: pressure relief contact aKW technical obstruction in outlet - PRD Enquiries (see back page) hose or handset activated General: 01905 823 298 www.akw-ltd.co.uk... -
Page 7: Filter Cleaning
Order: 01905 823 299 orders.akw-ltd.co.uk Technical Support: 01905 560 219 Order: 01905 823 299 orders.akw-ltd.co.uk... -
Page 8: Installer
Side Pipe Inlet entry Side Pipe Inlet entry cut-out cut-out Diverter Valve Fixing hole Fixing hole shower hose Outlet Bottom Pipe inlet and Bottom Pipe inlet and Cable Entry Cover Cable Entry Cover Inlet Filter General: 01905 823 298 www.akw-ltd.co.uk... -
Page 9: Specifications
Footprint Width (W2) 218 mm Water Ingress rating IPX4 cable entry Points 6 - top, bottom or rear. Water entry Points 8 - top, bottom, rear or side. accredItatIonS & certIFIcatIonS Order: 01905 823 299 orders.akw-ltd.co.uk Technical Support: 01905 560 219... -
Page 10: Installation Requirements
• Block, restrict or connect the water outlet pipe to any parts other than those aKW specifically state for use with this electric shower, as it acts as a vent. -
Page 11: Disassembly
Reinsert the cover shown before mounting If using side pipe entry, cut out the area on to the wall. Leave the corner section to one the two parts shown. side until pipe installation is complete. Order: 01905 823 299 orders.akw-ltd.co.uk Technical Support: 01905 560 219... - Page 12 Before drilling, check for any buried points on the wall. note: the 3 marked holes cables or pipework. drill, insert wall match aKW electric showers within the plugs and screw to wall. stock code range 29010 to 29092. Knock out...
-
Page 13: Fitting To Wall - Without Fitting Plate
Remove the fitting screw to the wall first and then bottom template from the wall and drill the marked screws should be fitted only fixing points. during final installation. Order: 01905 823 299 orders.akw-ltd.co.uk Technical Support: 01905 560 219... -
Page 14: Reassembly - Bottom Cover
Once the cable and pipe connections have been made, reassemble the corner section. if using side entry, slide the entry covers in. Slide the corner section in to the unit. Fasten the screws holding the corner section. General: 01905 823 298 www.akw-ltd.co.uk... -
Page 15: Reassembly - Front Cover
(fully anti-clockwise) before assembling correct position and press the bottom the front cover to the back case. of the cover to clip. screw in place. Order: 01905 823 299 orders.akw-ltd.co.uk Technical Support: 01905 560 219... -
Page 16: Plumbing
Move inlet Direction left Inlet right Inlet Move inlet Direction left Inlet retaining retaining Screw Screw left Inlet right Inlet left Inlet right Inlet Water Water Water Water Flow Flow Flow Flow General: 01905 823 298 www.akw-ltd.co.uk General: 01905 823 298 www.akw-ltd.co.uk... - Page 17 Side entry left or right rear inlet. left or right side inlet. Order: 01905 823 299 orders.akw-ltd.co.uk Technical Support: 01905 560 219 Order: 01905 823 299 orders.akw-ltd.co.uk Technical Support: 01905 560 219...
-
Page 18: Electrical
Where shower cubicles are located outside of a bathroom, all socket outlets in the room must be protected by a 30 ma rcd. consult the wiring regulations. It is recommended to use the shortest cable route possible from the consumer unit to the shower. General: 01905 823 298 www.akw-ltd.co.uk General: 01905 823 298 www.akw-ltd.co.uk... - Page 19 IMPORTANT - connect to only the left OR right terminal blocks. never make a simultaneous connection to both left and right terminal blocks. left or right side rear cable entry. Order: 01905 823 299 orders.akw-ltd.co.uk Technical Support: 01905 560 219...
- Page 20 If the issue is still Follow us on Social: unresolved, contact AKW Technical Enquiries who will provide further advice and arrange for a maintenance engineer to visit if necessary. none of the foregoing affects your statutory rights.
