- Page 1 Arka Thermostatic TMV3 Mixer Shower INSTALLATION INSTRUCTIONS Stock Code 25421-2 Please read all instructions before installation and leave this document with the end user for future reference as it contains important warranty information...
- Page 2 G 1/2” G 1/2” please check that all components are present from the packaging box prior to installation of this product. if anything is missing or damaged please contact General enquiries - see back page. General: 01905 823 298 www.akw-ltd.co.uk...
-
Page 3: Specifications
Order: 01905 823 299 orders.akw-ltd.co.uk Technical Support: 01905 560 219... -
Page 4: Installation
4. Clean with a cloth and warm soapy water when everything is secure. Cold 150 ± 15 mm Cold Cold Cold 150 ± 15 mm 150 ± 15 mm 150 ± 15 mm Seal with ptfe tape or liquid sealant Filter Filter Filter Filter General: 01905 823 298 www.akw-ltd.co.uk... -
Page 5: Operation
For water economy reasons, the flow is limited by a stop. To obtain a higher flow, press the override button on the flow lever and continue to rotate the lever. Order: 01905 823 299 orders.akw-ltd.co.uk Technical Support: 01905 560 219... - Page 6 General: 01905 823 298 www.akw-ltd.co.uk...
- Page 7 （ （ Different scale reflects different temperature） ） repeat this process until the maximum override temperature is set at 41 °C. 38°C Step override Limit Ring Limit Ring 41°C Step Order: 01905 823 299 orders.akw-ltd.co.uk Technical Support: 01905 560 219...
- Page 8 41 °C. if the temperature is not 41 °C, re-adjust the override Limit Ring accordingly by removing the lever again. only when then temperatures are set, then replace the cover cap. General: 01905 823 298 www.akw-ltd.co.uk...
- Page 9 If the normal or maximum override flow rates are incorrect, then re-adjust accordingly. finally replace, tighten the screw, and replace cap. Note: record the commissioning tests on page 13 Order: 01905 823 299 orders.akw-ltd.co.uk Technical Support: 01905 560 219...
-
Page 10: Maintenance And Servicing
Never use corrosive acidic or alkaline cleaning materials on fittings or surfaces. Always flush cleaning materials away with copious amounts of water and wipe down. Check Valve (Remove with 9 mm hex key) inlet Connector filter inlet Cover 1/2” - 3/4” BSp fitting General: 01905 823 298 www.akw-ltd.co.uk... - Page 11 SmV-001 - check the boiler or water tank that is Water goes cold in use supplying the hot water. Water is leaking Seals worn or damaged - request service. from the SmV-001 Order: 01905 823 299 orders.akw-ltd.co.uk Technical Support: 01905 560 219...
-
Page 12: Product Identification
Product Identification To be completed be installer. Product identification label can be found on the outer box packaging. model/part number SmV-001 Serial number (Sn) Batch number (Bn) installed on installed by: address: Contact: General: 01905 823 298 www.akw-ltd.co.uk... - Page 13 ........................................................................................please use same test equipment as previously used for commissioning test. Record Commissioning Tests Date of future servicing Record Max Temperature Serviced by Order: 01905 823 299 orders.akw-ltd.co.uk Technical Support: 01905 560 219...
- Page 14 General: 01905 823 298 www.akw-ltd.co.uk...
- Page 15 Order: 01905 823 299 orders.akw-ltd.co.uk Technical Support: 01905 560 219...
- Page 16 rights.
