MONTERINGSBESKRIVNING
ASSEMBLY INSTRUCTIONS
TIN CONFERENCE STAND
1
beam joint is placed offset
2
3
16pcs T-spårmutter (slotted nut)
32pcs T-spårmutter (slotted nut)
2 pcs upper track, 2 pcs lower track at each end long beam
1 pcs upper track, 1 pcs lower track at each end short beam
C
A
16pcs F6S M6x16
M507-1
DETAIL A
DETAIL C
Advertisement
Related Manuals for Horreds TIN CONFERENCE STAND
Summary of Contents for Horreds TIN CONFERENCE STAND
- Page 1 MONTERINGSBESKRIVNING ASSEMBLY INSTRUCTIONS TIN CONFERENCE STAND M507-1 DETAIL A 16pcs T-spårmutter (slotted nut) beam joint is placed offset 16pcs F6S M6x16 32pcs T-spårmutter (slotted nut) 2 pcs upper track, 2 pcs lower track at each end long beam 1 pcs upper track, 1 pcs lower track at each end short beam...
- Page 2 MONTERINGSBESKRIVNING ASSEMBLY INSTRUCTIONS TIN CONFERENCE STAND M507-1 DETAIL F Place the detail "K" in upper track & detail "F" at lower track screw them loosely 8pcs K6S M6x16 DETAIL K 8pcs F6S M6x16 fasten detail G with the correct measurement "C"...
- Page 3 MONTERINGSBESKRIVNING ASSEMBLY INSTRUCTIONS TIN CONFERENCE STAND M507-1 DETAIL I center the box on the short edge. tighten with 4pcs F6S M6x16 DETAIL J screw inner rim in corner bracket 4pcs K6S M6x16 screw the box into the inner frame 4pcs F6S M6x16...
- Page 4 MONTERINGSBESKRIVNING ASSEMBLY INSTRUCTIONS TIN CONFERENCE STAND M507-1 open the service hatch, adjust stability with the set screws at the bottom of the cone important STRX "5.0x17" "5.0x20" must not be set incorrectly place the table tops on the base. First pull the boards together with fittings "L" pull crosswise.
