- Page 1 HANDRAIL SCALE PH-740 INSTRUCTION MANUAL Please keep this manual in a safe place, and make sure it is readily available whenever necessary. Please use this product only after carefully reading this manual and fully understanding its contents.
-
Page 2: Table Of Contents
• When disposing of this equipment, please do so in accordance with the prevailing regulations in your country, state and city. • If an unauthorized person attempts to disassemble or repair any part of the equipment, the warranty will become invalid. When the unit malfunctions, please consult your nearest Tanita sales office or agent. -
Page 3: Assembly Instructions
5. Assembly Instructions 1. List of Components 2. Assembly Base (fully assembled and pre-wired to display assembly) 1) Install the Lower Pillar Assembly into 2) Assemble the Top Head Display into the 3) Connect the Cable (Base side) the Base using the four (4) Screws while Lower Pillar assembly while carefully Cable from the Lower Pillar Assembly... -
Page 4: Operation By Ac Adapter
10) Insert the Hight Rod Assembly into the Pillar. 5. Assembly Instructions (continued) 7) Place the Front Cover over the screws and fix it by inserting its 8) Insert the Back Cover. pins into the holes. *Be careful not to pinch the cable while performing this operation. Note: Place the scale on a hard, flat surface where these is minimal vibration to ensure safe and accurate measurement. -
Page 5: Operation
8. Operation 1. Standard Weighing Procedures 3. Step on Function The scale will turn on automatically when the user steps onto the platform. 1) Turn on the power by pressing the key. Note: •If the weight is less than 22lb/10kg, the “Step-On” function will not work. 2) After all the segments flash, [0.0lb/0.0kg] is displayed. -
Page 6: Measuring Height Procedure
2) Gently lower the Height Rod Arm until the Height Rod Arm touches the very top of the user’s head. If you want to use the USB output, you must install the necessary driver onto your PC, available to download from http://www.tanita.com. 3) Read the measurement. INCORRECT way to measure the height of If the subject is taller than 48”... -
Page 7: 12. Troubleshooting
Output data 11. Specifications Header Pattern Name of item Output data (ASCII code) Model PH-740 kg mode lb mode BMI mode Weight mode Measurement System Strain Gauge Load Cell Control data Fix to 16 2 Bytes fixed 450kg / 0.1kg Control data ˜0... - Page 8 • Consult the dealer or an experienced radio or television technician for help. Modifications The FCC requires the user to be notified that any changes or modifications made to this device that are not expressly approved by Tanita Corporation may void the user’s authority to operate the equipment.
