- Page 1 Core IP USER MANUAL Rasha Professional A/S 1800 Rustin Ave. Riverside CA, 92507 951-654-3585 rashaprofessional.com info@rashaprofessional.com...
-
Page 2: Copyright Notice
Discard any older versions of this manual and replace them with the current version. Rasha® is a registered trademark of RASHA PROFESSIONAL A/S (also known as RASHA or Rasha). The RASHA® logo includes the RASHA name and all other trademarks in this manual... -
Page 3: Table Of Contents
Table of Contents Safety Guide Product Info Introduction Overview Dimentions Connections Tech Specs Rigging Rigging Display Menu Map Wireless Control DMX Chart Macro Chart Returns Contact Us Rasha Professional A/S 1800 Rustin Ave., Riverside CA, 92507 951-654-3585 rashaprofessional .com info@rashaprofessional.com... -
Page 4: Safety Guide
All applicable Local Codes and regulations apply to the proper installation of this product. When hanging this product, always secure it to a fastening device using a Safety Cable. Rasha Professional A/S 1800 Rustin Ave., Riverside CA, 92507 951-654-3585 rashaprofessional .com info@rashaprofessional.com... -
Page 5: Power And Wiring
The maximum Ambient temperature is 113 °F (45 °C). Do not operate this product at a higher temperature. If you have a severe operating problem, stop using this product Immediately. Rasha Professional A/S 1800 Rustin Ave., Riverside CA, 92507 951-654-3585 rashaprofessional .com info@rashaprofessional.com... -
Page 6: Product Info
Table Below to wire it. Recepticle Scew Connection Wire (U.S.) Wire (Europe) Colors AC Live Black Brown Brass or Yellow AC Neutral White Blue Silver AC Ground Green/Yellow Green/Yellow Green Rasha Professional A/S 1800 Rustin Ave., Riverside CA, 92507 951-654-3585 rashaprofessional .com info@rashaprofessional.com... -
Page 7: Introduction
The threaded screw at the bottom of the fixture acts as a kickstand and allows for leveling the fixture on rugged terrain Core IP is a simple-to-use and powerful tool for anyone seeking to elevate their uplighting solutions. Key Features •... -
Page 8: Overview
Overview IR Sensor Wireless Antenna location Handle Kickstand WIFI App QR Code Gore Valve Wireless Charging DMX LED Port Indicator Power IR Sensor Button Rasha Professional A/S 1800 Rustin Ave., Riverside CA, 92507 951-654-3585 rashaprofessional .com info@rashaprofessional.com... -
Page 9: Dimentions
Dimentions 5.4 in 138 mm 6.25 in 158.75 mm 5.4 in 138 mm Rasha Professional A/S 1800 Rustin Ave., Riverside CA, 92507 951-654-3585 rashaprofessional .com info@rashaprofessional.com... -
Page 10: Tech Specs
600 Hz, 1200 Hz, 2000 Hz, 4000Hz, 12k Hz, 25k Hz Construction Housing Aluminum die-cast Fixture Color Black or White Menu Display LCD Menu Display Batter Life Indicator on display Mounting Hole Rasha Professional A/S 1800 Rustin Ave., Riverside CA, 92507 951-654-3585 rashaprofessional .com info@rashaprofessional.com... - Page 11 Control Control Options Wireless DMX, Manual, Auto, IR Remote, App Control DMX Modes 2Ch, 6CH, 8CH, 11Ch Wireless Operation Transmit, Receive Modes Wireless Operating 2.4 GHz Frequency Rasha Professional A/S 1800 Rustin Ave., Riverside CA, 92507 951-654-3585 rashaprofessional .com info@rashaprofessional.com...
-
Page 12: Rigging
2. Fasten the clamp to the truss and Tighten fully. 3. Pull the safety cable Through the handle and over the trussing system or another suitable rigging point. M10 Mounting Hole Rasha Professional A/S 1800 Rustin Ave., Riverside CA, 92507 951-654-3585 rashaprofessional .com info@rashaprofessional.com... -
Page 13: Display
• For a smooth navigation thru the menu, please make sure the display surface is dry and dust free. • Function for inactivity automatically turning off display is user adjustable. <Menu> <Up> <Down> <Enter> Rasha Professional A/S 1800 Rustin Ave., Riverside CA, 92507 951-654-3585 rashaprofessional .com info@rashaprofessional.com... -
Page 14: Menu Map
Set color preset Auto preset with speed Program Auto Speed 1-16 adjustment Fade preset with speed Fade Fade 1-3 Speed 1-16 adjust Sound Sound 1-4 Sound program preset Rasha Professional A/S 1800 Rustin Ave., Riverside CA, 92507 951-654-3585 rashaprofessional .com info@rashaprofessional.com... - Page 15 2200K 2400K 2600K 2800K 3200K 3600K 4000K 4400K 4800K 5200K Set color Temperature Program 5600K preset 6000K 6400K 6600K 7200K 7600K 8000K 8400K 8800K 9200K 9600K 10,000K Rasha Professional A/S 1800 Rustin Ave., Riverside CA, 92507 951-654-3585 rashaprofessional .com info@rashaprofessional.com...
- Page 16 Set menu lock function Menu lock activates after the display times out Menu Lock On/Off Hold the <UP> and <DOWN> buttons simultaneously for 5 seconds to unlock screen Rasha Professional A/S 1800 Rustin Ave., Riverside CA, 92507 951-654-3585 rashaprofessional .com info@rashaprofessional.com...
- Page 17 LED Curve 2 Curve Set dimmer curve preset LED Curve 3 LED Curve 4 Version Vx.x Current time 00H 00M 00s Information Fixture information Temperature xx°c IDxxxxxxxxxxxxx Rasha Professional A/S 1800 Rustin Ave., Riverside CA, 92507 951-654-3585 rashaprofessional .com info@rashaprofessional.com...
-
Page 18: Wireless Control
DMX address. Press <ENTER> to confirm selection. 5. Use <MENU> button to navigate the fixture’s Channel menu page and set the desired Channel mode. Press <ENTER> to confirm selection. Rasha Professional A/S 1800 Rustin Ave., Riverside CA, 92507 951-654-3585 rashaprofessional .com... - Page 19 5. Use <MENU> button to navigate the fixture’s Channel menu page and set the desired Channel mode. Press <ENTER> to confirm selection. 2.4Ghz Channel Color Chart Channel ID Color Green Yellow Blue Magneta Cyan White Rasha Professional A/S 1800 Rustin Ave., Riverside CA, 92507 951-654-3585 rashaprofessional .com info@rashaprofessional.com...
-
Page 20: Dmx Chart
6Ch 8Ch Function Value Description Dimmer 0-255 Intensity Strobe 0-255 Strobe Rate 0-255 0-100% Green 0-255 0-100% Blue 0-255 0-100% White 0-255 0-100% Amber 0-255 0-100% 0-255 0-100% Rasha Professional A/S 1800 Rustin Ave., Riverside CA, 92507 951-654-3585 rashaprofessional .com info@rashaprofessional.com... - Page 21 10-50 Color Macro (Ch 11 selects Color) 51-100 Color Jump Color Macro 101-150 Color Fade 151-200 Color Pulse 201-255 Blackout Macro Speed 0-255 Macro Speed/ Color selection Rasha Professional A/S 1800 Rustin Ave., Riverside CA, 92507 951-654-3585 rashaprofessional .com info@rashaprofessional.com...
-
Page 22: Macro Chart
136-143 Rose 144-151 Spring Green 152-159 Dark Blue 160-167 White 168-175 Bronze 176-183 Grey 184-191 Lilac 192-199 Sky Blue 200-207 Orchid 208-215 216-223 Ultra Pink 224-231 Turquoise Rasha Professional A/S 1800 Rustin Ave., Riverside CA, 92507 951-654-3585 rashaprofessional .com info@rashaprofessional.com... - Page 23 Value Color 232-239 Beige 240-247 Gold 248-255 Melrose Rasha Professional A/S 1800 Rustin Ave., Riverside CA, 92507 951-654-3585 rashaprofessional .com info@rashaprofessional.com...
-
Page 24: Returns
Returns You must send the product prepaid, in the original box, and with the original packing and accessories. Rasha Professional will not issue call tags. Call Rasha and request a Return Merchandise Authorization (RMA) number before shipping the product. Be prepared to provide the model number, serial number, and a brief description of the Claim(s) for the return. -
Page 25: Contact Us
+1 (951) 654 3585 Outside the U.S. contact the dealer of record. Follow their instructions to request support or to return a product. Visit our website for contact details. Rasha Professional A/S 1800 Rustin Ave., Riverside CA, 92507 951-654-3585 rashaprofessional .com...
