- Page 1 EN User Manual | Washing Machine EW6T3372E...
-
Page 2: Table Of Contents
Welcome to Electrolux! Thank you for choosing our appliance. Get usage advice, brochures, trouble shooter, service and repair information: www.electrolux.com/support Subject to change without notice. CONTENTS 1. SAFETY INFORMATION................2 2. SAFETY INSTRUCTIONS................4 3. PRODUCT DESCRIPTION................6 4. TECHNICAL DATA..................7 5. -
Page 3: General Safety
the use of the appliance in a safe way and understand the hazards involved. • Children between 3 and 8 years of age and persons with very extensive and complex disabilities shall be kept away from the appliance unless continuously supervised. •... -
Page 4: Safety Instructions
• The ventilation opening in the base must not be covered by a carpet, mat, or any floor covering. • The appliance must be connected to the water mains using the new supplied hose sets, or other new hose sets supplied by the Authorised Service Centre. -
Page 5: Water Connection
2.4 Use • Always use a correctly installed shockproof socket. • Make sure that the parameters on the WARNING! rating plate are compatible with the Risk of injury, electric shock, fire, burns electrical ratings of the mains power or damage to the appliance. supply. -
Page 6: Product Description
These lamps are intended to withstand • Disconnect the appliance from the mains extreme physical conditions in household electrical and water supplies. appliances, such as temperature, • Cut off the mains electrical cable close to vibration, humidity, or are intended to the appliance and dispose of it. -
Page 7: Technical Data
Lid handle Mains cable Drain pump filter Transit bolts Feet for levelling the appliance Hose support Inlet hose Rating plate Drain hose Information for register product. The rating plate reports the model name The info label reports the model name (A), (A) , product number (B), electrical ratings (C) product number (B ) and serial number (C). -
Page 8: Installation
5. INSTALLATION WARNING! Refer to Safety chapters. 5.1 Unpacking and positioning ENGLISH... -
Page 9: The Inlet Hose
Adjust the appliance correctly to prevent vibration, noise and movement of the appliance when it operates. WARNING! Do not put cardboard, wood or equivalent materials below the appliance feet to adjust the level. Make sure that carpets do not stop the air circulation below the appliance. Make sure that the appliance does not touch the wall or other units. -
Page 10: Water Drainage
5.3 Water drainage min.600 mm max.1000 mm Subject to change without notice. The drain hose should stay at a height of no less than 600 mm and not more than 1000 mm. You can extend the drain hose to maximum 4000 mm. Contact the authorised service centre for the other drain hose and the extension. -
Page 11: Control Panel
failure to comply with the above safety precaution. 6. CONTROL PANEL 6.1 Control panel description Programme dial Easy Iron touch button Spin reduction options touch button Soft Plus touch button Temperature touch button Extra Rinse touch button Display Stain touch button Delay Start touch button Prewash touch button Time Manager touch button... - Page 12 6.2 Display The Temperature area: Temperature indicator Cold water indicator Child safety lock indicator. Delay start indicator. Lid locked indicator. The digital indicator can show: • Programme duration (e. g. • Delay time (e. g. • Cycle end ( • Warning code (e.g.
-
Page 13: Dial And Buttons
The spin area: Spin speed indicator No Spin indicator. Spin phase is off. 7. DIAL AND BUTTONS 7.1 Introduction Touch repeatedly this button to: • Decrease the spin speed. The display shows only the spin speeds available for the set programme. The options/functions are not available •... -
Page 14: Permanent Extra Rinse
some programmes the rinses are Use this option for people with allergies to performed with more water. detergent residues and with sensitive skin. If you touch the Start/Pause button, the appliance performs the only draining This option increases the programme phase. -
Page 15: Time Manager
7.11 Time Manager indicator With this option you can reduce the programme duration depending on the load size and the degree of soiling. When you set a washing programme, the display shows the default duration and dashes. ■ ■ Touch Time Manager button to reduce the ■... - Page 16 Programme Reference Maxi‐ Programme description Default tempera‐ spin speed (Type of load and level of soiling) ture Spin speed load Temperature range range 1200 rpm 2 kg Delicate fabrics such as acrylics, viscose and mixed fab‐ Delicates (1200- 400 rics requiring gentler washing. Normally and lightly soiled 30 °C rpm) items.
- Page 17 Programme Reference Maxi‐ Programme description Default tempera‐ spin speed (Type of load and level of soiling) ture Spin speed load Temperature range range 1200 rpm 2 kg Outdoor (1200- 400 30 °C 1 kg rpm) Do not use fabric softener and make sure that 40 °C - Cold there is no softener residue in the detergent dispenser.
- Page 18 Programme options compatibility Programme Eco 40-60 ■ ■ ■ ■ ■ ■ ■ ■ ■ ■ ■ ■ ■ ■ Cottons ■ ■ ■ ■ ■ ■ ■ ■ ■ ■ ■ Synthetics Delicates ■ ■ ■ ■ ■ ■ ■...
-
Page 19: Settings
Programme Universal Liquid Uni‐ Liquid for Delicates Special versal coloureds woollens powder 1) ▲ ▲ Duvet ▲ ▲ Silk ▲ ▲ Wool ▲ ▲ ▲ Sport ▲ ▲ Outdoor ▲ ▲ ▲ Denim At temperature higher than 60 °C the use of powder detergent is recommended. ▲... -
Page 20: Daily Use
To activate/deactivate this option, hold down button until comes on/goes off If the procedure does not work (due to on the display. timeout, wrong programme dial position The appliance will default to this option after or wrong keys combination), switch the you switch it off. -
Page 21: Activating The Appliance
11.1 Activating the appliance 5. Close the drum and the lid. 1. Connect the mains plug to the mains CAUTION! socket. Before you close the lid of your 2. Open the water tap. appliance, make sure that you close the 3. -
Page 22: Liquid Or Powder Detergent
11.4 Liquid or powder detergent CLICK CLICK • Position A for powder detergent (factory setting). If a selection is not possible an acoustic • Position B for liquid detergent. signal sounds and the display shows When you use the liquid detergent: •... -
Page 23: The Sensicare System Load Detection
placed below the time digits play a simple 2. Touch the Start/Pause button. The animation. The drum rotates shortly. appliance lid locks and starts the countdown 2. The programme duration could be of the delay start. The display shows the adjusted accordingly and could increase indicator or decrease. -
Page 24: Cancelling A Running Programme
2. Change the options. The given Close the drum door and lid. Touch the information in the display changes Start/Pause button. accordingly. The programme or the delay start continues. 3. Touch the button Start/Pause again. 11.12 End of the programme The washing programme continues. -
Page 25: Stand-By Option
Press the button On/Off to activate the • If you have set Rinse Hold appliance again. appliance drains the water and spins. • 5 minutes after the end of the washing • If you have set Night the appliance programme. only drains the water Press the On/Off button to activate the appliance again. -
Page 26: Stubborn Stains
– there is large amounts of foam during washing. • When using detergent tabs or pods, always put them inside the drum, not in the detergent dispenser. Insufficient detergent may cause: • unsatisfactory washing results, • the wash load to turn grey, •... -
Page 27: Care And Cleaning
Use the correct quantity of water softener. Follow the instructions that you find on the packaging of the product. 13. CARE AND CLEANING paragraphs. If necessary, please contact the WARNING! Authorised Service Centre. Refer to Safety chapters. 13.3 External cleaning 13.1 Periodic cleaning schedule Clean the appliance with mild soap and warm water only. -
Page 28: Cleaning The Drum
part of the appliance, run a maintenance 1. Remove all laundry from the drum. wash regularly (at least once a month). 2. Run a Cottons programme with the highest temperature. 3. Add a small quantity of powder detergent into the empty drum, in order to rinse out Refer to "Cleaning the drum"... -
Page 29: Cleaning The Inlet Hose And The Valve Filter
Proceed as follows to clean the pump: 13.10 Cleaning the inlet hose and the valve filter 13.11 Emergency drain 13.12 Frost precautions If the appliance cannot drain the water, carry If the appliance is installed in an area where out the same procedure, described in the temperature can reach values around 0°... -
Page 30: Troubleshooting
4. Empty the drain pump. Refer to the WARNING! emergency drain procedure. 5. When the drain pump is empty, install the Make sure that the temperature is higher inlet hose again. than 0 °C before you use the appliance again. The manufacturer is not responsible for damages caused by low temperatures. - Page 31 • The programme was not finished properly or the appliance stopped too early. Switch the appliance off and on again. No communication between elec‐ • If the alarm code appears again, contact the Authorised Service Centre. tronic elements of the appliance. •...
-
Page 32: Consumption Values
Potential failures Possible solution • Make sure the levelling of the appliance is correct. Refer to "Installation instruc‐ tion". The appliance makes an unusual noise and vi‐ • Make sure that the packaging and/or the transit bolts are removed. Refer to "In‐ brates. - Page 33 15.2 Legend Laundry load. hh:mm Programme duration. Energy consumption. °C Temperature in the laundry. Litres Water consumption. Spin speed. Remaining moisture at the end of spinning phase. The higher is the spin speed, the higher is the noise and the lower is the remaining moisture. Values and programme duration may differ depending on different conditions (e.g.
-
Page 34: Quick Guide
Programme rpm 1) Litres hh:mm °C Cottons 1.65 90.0 3:50 53.00 1300 60°C Cottons 20° 0.30 90.0 2:50 53.00 1300 20°C Synthetics 0.55 50.0 2:10 35.00 1200 40°C Delicates 0.35 50.0 1:00 35.00 1200 30°C Wool 0.20 45.0 1:10 30.00 1200 30°C Reference indicator of the spin speed. - Page 35 2. Turn the programme dial to set the 5. The appliance starts. desired programme. At the end of the programme, remove the 3. Set the desired options by means of the laundry. corresponding touch buttons. Push the On/Off button to switch the 4.
-
Page 36: Environmental Concerns
Programmes Load Product description 2 kg Modern outdoor sporting garments. Outdoor 1 kg Denim 2 kg Denim clothing. Washing programme. Washing programme and waterproofing phase. 17. ENVIRONMENTAL CONCERNS appliances marked with the symbol with Recycle materials with the symbol . Put the the household waste. - Page 40 135959720-A-512023...
