EW6T5226C5
EN
Washing Machine
User Manual

Advertisement

Table of Contents
loading

Related Manuals for Electrolux EW6T5226C5

Summary of Contents for Electrolux EW6T5226C5

  • Page 1 EW6T5226C5 Washing Machine User Manual...

  • Page 2: Table Of Contents

    17. ENVIRONMENTAL CONCERNS..............35 WE’RE THINKING OF YOU Thank you for purchasing an Electrolux appliance. You’ve chosen a product that brings with it decades of professional experience and innovation. Ingenious and stylish, it has been designed with you in mind. So whenever you use it, you can be safe in the knowledge that you’ll get great results every time.

  • Page 3: Safety Information

    ENGLISH SAFETY INFORMATION Before beginning the installation and use of this appliance, carefully read the supplied instructions. The manufacturer is not responsible for any injuries or damage that are the result of incorrect installation or usage. Always keep the instructions in a safe and accessible location for future reference.
  • Page 4 1.2 General Safety This appliance is for washing domestic-type, machine- • washable laundry only. This appliance is designed for single household • domestic use in an indoor environment. This appliance may be used in, offices, hotel guest • rooms, bed & breakfast guest rooms, farm guest houses and other similar accommodation where such use does not exceed (average) domestic usage levels.

  • Page 5: Safety Instructions

    ENGLISH 2. SAFETY INSTRUCTIONS 2.1 Installation • WARNING: This appliance is designed to be installed / connected The installation must comply to a grounding connection in the with relevant national building. regulations. • Always use a correctly installed shockproof socket. •...

  • Page 6: Product Description

    Authorised Service Centre for the related equipment including hoses, other drain hose and the extension. valves, filters and aquastops, printed • Make sure that there is access to the circuit boards, electronic displays, tap after the installation. pressure switches, thermostats and sensors, software and firmware 2.4 Use...
  • Page 7 ENGLISH washing results in the minimum "The SensiCare System load possible time. Read the paragraph detection " for more details. 3.2 Appliance overview 10 11 Control panel Drain hose Mains cable Lid handle Transit bolts Drain pump filter Hose support Lever to move the appliance Rating plate Feet for levelling the appliance...

  • Page 8: Technical Data

    4. TECHNICAL DATA Dimension Width/ Height/ Total depth 39,7 cm /90,8 cm /59,9 cm Electrical connection Voltage 230 V Overall power 2200 W Fuse 10 A Frequency 50 Hz Level of protection against ingress of solid particles IPX4 and moisture ensured by the protective cover, except...
  • Page 9 ENGLISH We recommend that you keep the packaging and the transit bolts for any transport of the appliance. Adjust the appliance correctly to prevent vibration, noise and movement of the appliance when it operates. WARNING! Do not put cardboard, wood or equivalent materials below the appliance feet to adjust the level.
  • Page 10 5.3 Water drainage min.600 mm max.1000 mm The drain hose should stay at a height of no less than 600 mm and not more than 1000 mm. You can extend the drain hose to maximum 4000 mm. Contact the authorised service centre for the other drain hose and the extension.

  • Page 11: Control Panel

    ENGLISH 6. CONTROL PANEL 6.1 Control panel description Programme dial Spin reduction options touch button Display • No Spin option Delay Start touch button • Rinse Hold option Time Manager touch button • Night option On/Off push button Start/Pause touch button Temp.

  • Page 12: Dial And Buttons

    Delay start indicator. The digital indicator can show: • Programme duration (e. g. • Delay time (e. g. • Cycle end ( • Warning code (e.g. Time Manager bars level indicator. Drum clean indicator. Child safety lock indicator. Add garments indicator. Illuminates at the beginning of the Wash phase, while the user can still pause the appli‐...
  • Page 13 ENGLISH creasing. The washing programme Use this option for people with allergies ends with water in the drum. to detergent residues and with sensitive The lid stays locked and the drum skin. turns regularly to reduce creasing. This option increases the You must drain the water to unlock programme duration.

  • Page 14: Programmes

    (max. half load ■ ■ ■ recommended). ■ the shortest cycle to freshen up a ■...
  • Page 15 ENGLISH Programme Reference Maxi‐ Programme description Default tem‐ spin (Type of load and level of soiling) perature speed load Temperature Spin range speed range [rpm ] Rapid 14min 800 rpm 1,5 kg Synthetic and mixed fabric items. Lightly 30 °C (800 - 400) soiled items and items to freshen up.
  • Page 16 Programme Reference Maxi‐ Programme description Default tem‐ spin (Type of load and level of soiling) perature speed load Temperature Spin range speed range [rpm ] 1200 rpm Outdoor 2 kg Do not use fabric softener and (1200 - 30 °C make sure that there is no soften‐...
  • Page 17 ENGLISH Programme Reference Maxi‐ Programme description Default tem‐ spin (Type of load and level of soiling) perature speed load Temperature Spin range speed range [rpm ] Denim 800 rpm 2 kg Special programme for Denim clothing 30 °C (1200 - with delicate washing phase to minimize 40 °C - Cold 400)
  • Page 18 Programme Sport ■ ■ ■ ■ ■ ■ ■ ■ ■ ■ ■ Outdoor Denim ■ ■ ■ ■ ■ ■ ■ Suitable detergents for washing programmes Universal Liquid Liquid for Delicates Programme Special Universal coloureds woollens powder Eco 40-60 ▲...

  • Page 19: Settings

    ENGLISH 8.2 Woolmark Wool Care - Blue The wool wash cycle of this machine has been approved by The Woolmark Compa‐ ny for the washing of wool garments label‐ led as «hand wash» provided that the products are washed according to the in‐ structions on the garment label and those issued by the manufacturer of this washing machine.

  • Page 20: Daily Use

    11. DAILY USE 2. Put the detergent and the fabric WARNING! conditioner into the proper Refer to Safety chapters. compartments. 11.1 Activating the appliance Always follow the instructions that you find on 1. Connect the mains plug to the mains the packaging of the socket.
  • Page 21 ENGLISH 11.4 Liquid or powder detergent Flap for powder or liquid detergent. CLICK CLICK • Position A for powder detergent If a selection is not possible (factory setting). an acoustic signal sounds • Position B for liquid detergent. and the display shows When you use the liquid detergent: •...
  • Page 22 The display The SensiCare System is shows the indicator not available with all When the countdown is completed, the programmes such as :Wool , programme starts automatically. Rinse, Spin and programmes with short Cancelling the delay start after cycles.
  • Page 23 ENGLISH 11.11 Opening the lid - Adding 11.13 Draining water out after garments end of cycle If you have chosen a programme or an If the temperature and level option that does not empty out the water of the water in the drum are of the last rinse, the programme is too high and/or the drum is completed, but:...

  • Page 24: Hints And Tips

    If the dial is rotated to the "Reset" If you set a programme or an position , the appliance automatically option that ends with water turns off in 30 seconds. in the drum, the Stand-by function doesn't deactivate the appliance to remind you to drain the water.

  • Page 25: Care And Cleaning

    ENGLISH powder detergents containing • Normally soiled laundry may be bleach for whites and laundry washed without prewash in order to sanitization, save detergent, water and time (the – liquid detergents, preferably for environment is protected too!). low temperature wash •...
  • Page 26 13.4 Descaling Indicative periodic cleaning schedule: Descaling Twice a year If the water in your area is hard or medium hard, we Maintenance wash Once a month recommend that you use a Clean lid seal Every two months water softener for washing machines.
  • Page 27 ENGLISH 13.7 Lid seal Always follow the instructions that you find on Regularly examine the seal and remove the packaging of the all objects from the inner part. Clean it product. when needed, using ammonia cream Do not clean the drum with cleanser agent without scratching the acidic descaling products, seal surface.
  • Page 28 13.9 Cleaning the inlet hose and the valve filter 13.10 Cleaning the drain filter WARNING! • Disconnect the mains Regularly check the drain pump filter and plug from the mains make sure that it is clean. socket. Clean the drain pump if: •...

  • Page 29: Troubleshooting

    ENGLISH 13.11 Emergency drain 1. Disconnect the mains plug from the mains socket. If the appliance cannot drain the water, 2. Close the water tap. carry out the same procedure, described 3. Put the two ends of the inlet hose in in 'Cleaning the drain pump' paragraph.
  • Page 30 • Make sure that the sink spigot is not clogged. • Make sure that the drain hose has no kinks or bends. The appliance does • Make sure that the drain filter is not clogged. Clean the fil‐ not drain the water.
  • Page 31 ENGLISH Problem Possible solution • Set the spin programme. The spin phase does • Make sure that the drain filter is not clogged. Clean the fil‐ not operate or the ter, if necessary. Refer to "Care and cleaning". washing cycle lasts •...

  • Page 32: Consumption Values

    15. CONSUMPTION VALUES 15.1 Introduction See the web link www.theenergylabel.eu for detailed information about Energy Label. The QR code on the energy label supplied with the appliance provides a web link to the information related to the performance of the appliance in the EU EPREL database.

  • Page 33: Quick Guide

    ENGLISH Power consumption in different modes Off (W) Stand-by (W) Delay start (W) 0.48 0.48 4.00 Time to Off/Standby mode is 15 minutes maximum. 15.4 Common programmes These values are indicative only. Programme Litres hh:mm °C Cottons 2.60 3:25 1200 90°C Cottons 1.85...
  • Page 34 Connect the mains plug to the mains 2. Set the desired options (1) by means socket. of the corresponding touch buttons. To start the programme, touch the Open the water tap. Start/Pause (2) button. Load the laundry. 3. The appliance starts.

  • Page 35: Environmental Concerns

    ENGLISH Programmes Load Product description Single synthetic blanket, padded clothes, Downing Jacket 2 kg duvets, down jackets. Special programme for silk and mixed syn‐ 0,5 kg thetic items. Silk Machine washable wool, hand washable 1 kg wool and delicates. Wool Sport 3 kg Sportswear.
  • Page 36 www.electrolux.com/shop...
