EW6T3364CZ
EN
Washing Machine
User Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EW6T3364CZ and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Electrolux EW6T3364CZ

Summary of Contents for Electrolux EW6T3364CZ

  • Page 1 EW6T3364CZ Washing Machine User Manual...

  • Page 2: Table Of Contents

    17. ENVIRONMENTAL CONCERNS..............36 WE’RE THINKING OF YOU Thank you for purchasing an Electrolux appliance. You’ve chosen a product that brings with it decades of professional experience and innovation. Ingenious and stylish, it has been designed with you in mind. So whenever you use it, you can be safe in the knowledge that you’ll get great results every time.

  • Page 3: Safety Information

    ENGLISH SAFETY INFORMATION Before beginning the installation and use of this appliance, carefully read the supplied instructions. The manufacturer is not responsible for any injuries or damage that are the result of incorrect installation or usage. Always keep the instructions in a safe and accessible location for future reference.
  • Page 4 1.2 General Safety This appliance is for washing domestic-type, machine- • washable laundry only. This appliance is designed for single household • domestic use in an indoor environment. This appliance may be used in, offices, hotel guest • rooms, bed & breakfast guest rooms, farm guest houses and other similar accommodation where such use does not exceed (average) domestic usage levels.

  • Page 5: Safety Instructions

    ENGLISH 2. SAFETY INSTRUCTIONS 2.1 Installation • WARNING: This appliance is designed to be installed / connected The installation must comply to a grounding connection in the with relevant national building. regulations. • Always use a correctly installed shockproof socket. •...

  • Page 6: Product Description

    Authorised Service Centre for the related equipment including hoses, other drain hose and the extension. valves, filters and aquastops, printed • Make sure that there is access to the circuit boards, electronic displays, tap after the installation. pressure switches, thermostats and sensors, software and firmware 2.4 Use...
  • Page 7 ENGLISH washing results in the minimum possible time. 3.2 Appliance overview 9 10 Control panel Drain hose Mains cable Lid handle Transit bolts Drain pump filter Hose support Feet for levelling the appliance Rating plate Inlet hose Information for register product. The rating plate reports the model name The info label reports the model name (A), (A) , product number (B), electrical...

  • Page 8: Technical Data

    4. TECHNICAL DATA Dimension Width/ Height/ Total depth 39,7 cm /90,8 cm /59,9 cm Electrical connection Voltage 230 V Overall power 2200 W Fuse 10 A Frequency 50 Hz Level of protection against ingress of solid particles IPX4 and moisture ensured by the protective cover, except...
  • Page 9 ENGLISH We recommend that you keep the packaging and the transit bolts for any transport of the appliance. Adjust the appliance correctly to prevent vibration, noise and movement of the appliance when it operates. WARNING! Do not put cardboard, wood or equivalent materials below the appliance feet to adjust the level.
  • Page 10 5.3 Water drainage min.600 mm max.1000 mm The drain hose should stay at a height of no less than 600 mm and not more than 1000 mm. You can extend the drain hose to maximum 4000 mm. Contact the authorised service centre for the other drain hose and the extension.

  • Page 11: Control Panel

    ENGLISH 6. CONTROL PANEL 6.1 Control panel description Programme dial Essorage reduction options touch button Display • No Spin option Départ Différé touch button • Rinse Hold option Time Manager touch button • Nuit option Départ/Pause touch button Marche/Arrêt push button Douceur Plus touch button Temp.

  • Page 12: Dial And Buttons

    Delay start indicator. The digital indicator can show: • Programme duration (e. g. • Delay time (e. g. • Cycle end ( • Warning code (e.g. • Indication of total operating hours of the appliance. Refer to the "Operating hours counter" section in the "Settings"...
  • Page 13 ENGLISH The final spin is not performed. The Use this option for people with allergies water of the last rinse is not drained to detergent residues and with sensitive out to prevent the fabrics from skin. creasing. The washing programme This option increases the ends with water in the drum.

  • Page 14: Programmes

    (max. half load recommended). ■ ■ ■ the shortest cycle to freshen up a ■...
  • Page 15 ENGLISH Programme Reference Maxi‐ Programme description Default tem‐ spin (Type of load and level of soiling) perature speed load Temperature Spin range speed range [rpm ] Rapide 14min 800 rpm 1,5 kg Synthetic and mixed fabric items. Lightly 30 °C (800 - 800) soiled items and items to freshen up.
  • Page 16 Programme Reference Maxi‐ Programme description Default tem‐ spin (Type of load and level of soiling) perature speed load Temperature Spin range speed range [rpm ] 1000 rpm Outdoor 2 kg Do not use fabric softener and (1000 - 30 °C make sure that there is no soften‐...
  • Page 17 ENGLISH Programme Reference Maxi‐ Programme description Default tem‐ spin (Type of load and level of soiling) perature speed load Temperature Spin range speed range [rpm ] Denim 800 rpm 2 kg Special programme for Denim clothing 30 °C (1000 - with delicate washing phase to minimize 40 °C - Cold 800)
  • Page 18 Programme Sport ■ ■ ■ ■ ■ ■ ■ ■ ■ ■ ■ Outdoor Denim ■ ■ ■ ■ ■ ■ ■ Suitable detergents for washing programmes Universal Liquid Liquid for Delicates Programme Special Universal coloureds woollens powder Eco 40-60 ▲...

  • Page 19: Settings

    ENGLISH 8.2 Woolmark Wool Care - Blue The wool wash cycle of this machine has been approved by The Woolmark Compa‐ ny for the washing of wool garments label‐ led as «hand wash» provided that the products are washed according to the in‐ structions on the garment label and those issued by the manufacturer of this washing machine.

  • Page 20: Before First Use

    9.4 Factory Reset combination activates and deactivates the acoustic signals). This function allows to restore the factory 4. The display will show default options. To activate this option about 5 seconds. follow steps below: If the procedure does not 1.
  • Page 21 ENGLISH CAUTION! When using liquid Before you close the lid of detergents add them into a your appliance, make sure dosing ball (supplied by the that you close the drum detergent's manufacturer). correctly. Put the dosing ball inside the washing machine's drum, on top of the garments.
  • Page 22 11.4 Liquid or powder detergent CLICK CLICK 11.6 Starting a programme • Position A for powder detergent (factory setting). • Position B for liquid detergent. Touch the Départ/Pause button to start the programme. It is not possible to When you use the liquid...
  • Page 23 ENGLISH Cancelling the delay start after The SensiCare System is not available with all the countdown has started programmes such as :Laine, Rinçage, Essorage and To cancel the delay start: programmes with short 1. Touch the Départ/Pause button cycles. to pause the appliance. The related indicator flashes.
  • Page 24 11.11 Opening the lid - Adding 11.13 Draining water out after garments end of cycle If you have chosen a programme or an If the temperature and level option that does not empty out the water of the water in the drum are...

  • Page 25: Hints And Tips

    ENGLISH If the dial is rotated to the "Reset" If you set a programme or an position , the appliance automatically option that ends with water turns off in 30 seconds. in the drum, the Stand-by function doesn't deactivate the appliance to remind you to drain the water.

  • Page 26: Care And Cleaning

    • Normally soiled laundry may be bleach for whites and laundry washed without prewash in order to sanitization, save detergent, water and time (the – liquid detergents, preferably for environment is protected too!). low temperature wash •...
  • Page 27 ENGLISH 13.4 Descaling Indicative periodic cleaning schedule: Descaling Twice a year If the water hardness in your area is high or moderate, we Maintenance wash Once a month recommend that you use a Clean lid seal Every two months water descaling product for washing machines.
  • Page 28 13.7 Lid seal 2. Run a Coton programme with the highest temperature. Regularly examine the seal and remove 3. Add a small quantity of powder all objects from the inner part. Clean it detergent into the empty drum, in when needed, using ammonia cream order to rinse out any left residues.
  • Page 29 ENGLISH Always keep a rag nearby to dry up any WARNING! water spillages when removing the filter. • Disconnect the mains plug from the mains socket. • Do not remove the filter while the appliance operates. • Do not clean the pump if the water in the appliance is hot.

  • Page 30: Troubleshooting

    14. TROUBLESHOOTING WARNING! Refer to Safety chapters. 14.1 Alarm Codes and Possible failures The appliance does not start or it stops during operation. First try to find a solution to the problem (refer to the tables). WARNING! Deactivate the appliance before carrying out any check.
  • Page 31 ENGLISH If the display shows other alarm codes, deactivate and activate the appliance. If the problem continues, contact the Authorised Service Centre. In case of different problem with the washing machine check the table below for possible solutions. Problem Possible solution •...

  • Page 32: Consumption Values

    Problem Possible solution The programme du‐ • The SensiCare System is able to adjust the programme ration increases or duration according to the type and the laundry load size. decreases during Refer to "The SensiCare System load detection" in "Daily programme execu‐...
  • Page 33 ENGLISH 15.2 Legend Laundry load. hh:m Programme duration. Energy consumption. °C Temperature in the laundry. Litres Water consumption. Spin speed. Remaining moisture at the end of spinning phase. The higher is the spin speed, the higher is the noise and the lower is the remaining moisture. Values and programme duration may differ depending on different conditions (e.g.

  • Page 34: Quick Guide

    Programme Litres hh:mm °C Coton 20° 0.30 80.0 2:50 53.00 1300 20°C Synthétiques 0.60 50.0 2:10 35.00 1000 40°C Délicats 0.30 50.0 1:00 35.00 1000 30°C Laine 0.20 45.0 1:05 30.00 1000 30°C 1) Reference indicator of the spin speed.
  • Page 35 ENGLISH 16.2 Cleaning the drain pump filter Clean the filter regularly and, especially, if the alarm code appears on the display. 16.3 Programmes Programmes Load Product description White and coloured cottons. Normally Eco 40-60 6 kg soiled garments. Coton 6 kg White cotton and coloured cotton.

  • Page 36: Environmental Concerns

    Programmes Load Product description 2 kg Modern outdoor sporting garments. Outdoor 1 kg Denim 2 kg Denim clothing. 1) Washing programme. 2) Washing programme and waterproofing phase. 17. ENVIRONMENTAL CONCERNS appliances marked with the symbol Recycle materials with the symbol with the household waste.
  • Page 40 www.electrolux.com/shop...
