Resin Garden Shed
OWNER'S MANUAL
Instructions for Assembly
Requires three people and takes 3-4 hours for
lnstallation. Quick & Easy Assembly
Ridge Reinforced Walls
Available in Various Sizes
SLD-A64
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the SLD-A64 and is the answer not in the manual?

Questions and answers

Summary of Contents for Moebelix SLD-A64

  • Page 1 Resin Garden Shed OWNER'S MANUAL Instructions for Assembly SLD-A64 Requires three people and takes 3-4 hours for lnstallation. Quick & Easy Assembly Ridge Reinforced Walls Available in Various Sizes...
  • Page 2 BEFORE YOU START Owner's Manual Prior to installation, it is important that you contact your local government authority to determine if building approval is required. Study and understand this owner's manual. Important information and helpful tips will make your construction easier and more enjoyable.
  • Page 3 PLAN AHEAD Site Selection Avoid overhanging trees as much as possible as leaves will make regular cleaning necessary and broken branches are a potential hazard. Small trees,bushes or fences nearby can be helpful,acting as a wind break. Site Preparation The site must be prepared so that the base of the shed is level all round and checking with a spirit level is required.
  • Page 4 BASEMENT COMPONENTS A64-C01 A64-C02 A64-C03 A64-C21 1200*295*14mm 1200*310*14mm 1200*310*14mm 260*43*43mm 4PCS 2PCS A64-C22 A64-C23 A64-C24-1 A64-C30 860*43*43mm 1170*43*43mm 705*45*43mm 116*47*45mm 4PCS 2PCS F35-C27 101*101*36mm 4PCS...
  • Page 5 WALL COMPONENTS/FRONT WALL A64-C06 A64-C07 A64-C12 A64-C13 A64-C14 492*276*14mm 610*276*14mm 492*1200*14m 310*1200*14mm 249*1170*14mm 2PCS 4PCS m 1PC 4PCS 2PCS A64-C20 A64-C27 A64-C28 A64-C32 A64-C33 1690*40*40mm 1170*52*19mm 232*52*19mm 196*112*19mm 190*118*8mm 4PCS 2PCS 2PCS 2PCS A64-A01 A64-A02 A64-A03 1725*61*20mm 1725*61*20mm 705*45*25...
  • Page 6 WALL COMPONENTS/LEFT/RIGHT WALL A64-C08 A64-C09 A64-C10 A64-C11 A64-C26 892*492*14mm 892*492*14mm 892*610*14mm 892*610*14mm 1670*60*18mm 3PCS 7PCS 2PCS A64-C18 A64-C31 F35-C31 F35-C32 F35-C33 875*75*54mm 90*55*46mm 412*562*18mm 540*390*13mm 348*498*2.0mm 4PCS 2PCS A64-A13 A64-A15 120*72*17mm 1748*72*11mm 4PCS 2PCS...
  • Page 8 ROOF COMPONENTS A64-C15 A64-C16 A64-C17 A64-C19 A64-C25 936*200*18mm 936*492*14mm 936*160*14mm 600*75*54mm 663*60*34mm 2PCS 4PCS 4PCS 4PCS 2PCS A64-C29 A64-A07 A64-A14 F35-C30 A64-C34 183*90*53mm 201*188*36mm 662*60*21mm 100*100*45mm 83*39*130mm 2PCS 2PCS 4PCS A64-A08 A64-A10 A64-A11 A64-A12 656*60*21mm 665*32*32mm 115*41*32mm 196*134*68mm 2PCS 2PCS 2PCS 4PCS...
  • Page 9 DOOR COMPONENTS A64-C04 A64-C05 F35-C29 440*623*14mm 310*623*14mm 47*47*21mm 4PCS 4PCS F35-D01 F35-D02 A64-A06 62*30mm 36*17*628mm 70*40mm 3PCS 2PCS A64-A04 18*27*1655mm A64-A05 18*27*1655mm...
  • Page 10 SCREWS COMPONENTS ST4.2*12mm ST4.2*12mm ST4.8*19mm ST5.5*50mm 38PCS 329PCS 32PCS 6PCS ST4.2*55mm M6*40mm M6*8.5mm 20pcs 4PCS 20PCS...
  • Page 11 PRODUCTS ASSEMBLY A64-C01 A64-C02 A64-C03 BASEMENT...
  • Page 12 A64-C22 A64-C30...
  • Page 13 A64-C24-1 F35-C27 A64-C21 F64-C23...
  • Page 15 A64-C12 A64-C13 BACK WALL...
  • Page 16 A64-C08 A64-C11 LEFT WALL...
  • Page 17 A64-C09 A64-C10 A64-C11 RIGHT WALL...
  • Page 18 F35-C31 F35-C32 F35-C33 WINDOW...
  • Page 19 A64-C15 A64-C16 A64-C17 A64-C19 R O O F...
  • Page 21 A64-C14 A64-C32 A64-C33 W I N D O W x2...
  • Page 22 A64-A07 A64-A08 A64-A10 A64-A11 R O O F S U P P O R T I N G A64-A12 ATTENTION: DO NOT LOCK UP THE SCREWS.
  • Page 23 A64-C06 A64-C07 F R O N T W A L L x2...
  • Page 24 A64-C04 A64-C05 A64-A04 A64-A05 A64-A06 DOOR...
  • Page 25 F35-C29 F35-D01...
  • Page 26 A64-C20 BACK WALL...
  • Page 27 A64-C20 A64-C26 LEFT WALL THIS SIDE WITH CHAMFERING NEED TO BE UP.
  • Page 30 A64-C20 A64-C26 RIGHT WALL...
  • Page 32 A64-A01 A64-A02 A64-A03 FRONT WALL...
  • Page 36 A64-C27 A64-C28 A64-C14 ROOF...
  • Page 38 A64-A13 A64-C18 ROOF SUPPORTING...
  • Page 42 PLEASE USE RUBBER KNIFE TO HELPPING ASSEMBLY.
  • Page 43 A64-C25...
  • Page 44 A64-C34 A64-A14...
  • Page 45 A64-C29 A64-C31 F35-C30...
  • Page 47 ROOF SCREWS ASSEMBLY...
  • Page 49 F35-D02...
  • Page 51 ATTENION!! When the door is not vertical or parallel after installation, please make appropriate adjustments according to the following figure 1.Lossen the screws 2.If the door corner tilted upward, press the corner with your hand, pull it upward slightly, and lock screws.
  • Page 52 BASEMNET EXPANSION SCREWS ASSEMBLY...
