Summary of Contents for Moebelix SLD-F35
- Page 1 Resin Garden Shed OWNER'S MANUAL Instructions for Assembly SLD-F35 Requires three people and takes 3-4 hours for lnstallation. Quick & Easy Assembly Ridge Reinforced Walls Available in Various Sizes...
- Page 2 BEFORE YOU START Owner's Manual Prior to installation, it is important that you contact your local government authority to determine if building approval is required. Study and understand this owner's manual. Important information and helpful tips will make your construction easier and more enjoyable.
- Page 3 PLAN AHEAD Site Selection Avoid overhanging trees as much as possible as leaves will make regular cleaning necessary and broken branches are a potential hazard. Small trees,bushes or fences nearby can be helpful,acting as a wind break. Site Preparation The site must be prepared so that the base of the shed is level all round and checking with a spirit level is required.
- Page 4 BASEMENT COMPONENTS F35-C01 F35-C02 F35-C03 F35-C24-1 310*1495*14mm 280*1495*14mm 310*1495*14mm 43*45*629mm F35-C27 F35-C28 F35-C19 F35-C20 101*101*36mm 101*101*36mm 43*43*835mm 43*43*860mm 3PCS F35-C21 43*43*1465mm...
- Page 5 WALL COMPONENTS F35-C08 F35-C09 F35-C10 F35-C11 492*1495*14mm 310*850*14mm 310*850*14mm 122*850*14mm 3PCS F35-C12 F35-C13 F35-C14 F35-C15 310*890*14mm 310*890*14mm 310*890*14mm 492*1495*14mm 10PCS F35-C16 F35-C22 F35-C23 F35-C25 310*1495*14mm 33*33*1825mm 33*33*1710mm 57*34*22mm 4PCS 2PCS 2PCS F35-C26 F35-C31 F35-C32 F35-C33 62*34*22mm 412*560*18 540*390*13 348*498*2.0 F35-A01 F35-A02 F35-A03 41*18.5*1700mm...
- Page 7 ROOF COMPONENS F35-C06 F35-C07 F35-C17 F35-C18 380*1580*14mm 310*1580*14mm 75*54*1480mm 75*54*890mm 2PCS 2PCS 2PCS F35-C30 F35-A08 100*100*45mm 935*66*16mm 4PCS...
- Page 8 DOOR COMPONENTS F35-C04 F35-C05 F35-C29 415*606*14mm 310*606*14mm 47*47*21mm 4PCS 4PCS F35-D01 F35-D02 F35-A04 62*30mm 36*17*609mm 70*40mm 2PCS 3PCS F35-A05 18*27*1630mm F35-A06 18*27*1630mm...
- Page 9 SCREWS 4.2*12mm 4.2*12mm 4.8*19mm 5.5*50mm 38PCS 205PCS 24PCS 4PCS...
- Page 10 ASSEMBLY F35-C01 F35-C02 F35-C03...
- Page 11 0.5CM...
- Page 12 F35-C20 F35-C20...
- Page 13 F35-C24-1 F35-C27 F35-C28 F35-C19 F35-C21...
- Page 14 F35-C09 F35-C10 F35-C11...
- Page 16 F35-C16 F35-C15...
- Page 17 F35-C12 F35-C13...
- Page 19 F35-C12 F35-C14...
- Page 20 F35-C06 F35-C07...
- Page 21 F35-C23...
- Page 23 F35-C22 F35-C22...
- Page 26 F35-C08 F35-A03 F35-A01 F35-A02...
- Page 31 F35-C17...
- Page 32 F35-C18...
- Page 33 F35-C17 Please use rubber knife to help C17/C18 stick into the wall board...
- Page 35 F35-C30 ·...
- Page 36 F35-C25 F35-C26...
- Page 37 F35-C04 F35-C05 F35-A04 F35-A05 F35-A06 BEND IT BY HAND...
- Page 39 F35-D01...
- Page 41 F35-D02...
- Page 43 F35-A08 Please put rubber knife firstly, then put A08...
- Page 45 ATTENION!! When the door is not vertical or parallel after installation, please make appropriate adjustments according to the following figure 1.loosen the screws...
- Page 46 BASEMENT EXPANSION SCREWS ASSEMBLY...
