- Page 1 Metal Garden Shed OWNER'S MANUAL Instructions for Assembly T-PSF56-H154 Requires two people and takes 1-2 hours for lnstallation. Quick & Easy Assembly Ridge Reinforced Walls Available in Various Sizes...
-
Page 2: Before You Start
BEFORE YOU START Owner's Manual Prior to installation, it is important that you contact your local government authority to determine if building approval is required. Study and understand this owner's manual. Important information and helpful tips will make your construction easier and more enjoyable. -
Page 3: Important Notes
PLAN AHEAD Site Selection Avoid overhanging trees as much as possible as leaves will make regular cleaning necessary and broken branches are a potential hazard. Small trees,bushes or fences nearby can be helpful,acting as a wind break. Site Preparation The site must be prepared so that the base of the shed is level all round and checking with a spirit level is required. - Page 4 Qty. Qty. PART PART 1394mm 1509mm 608mm 981mm 608mm 411mm 955mm 955mm 765mm 1560mm 876mm 1560mm 1106mm 895mm 1106mm 895mm 915mm 1360mm 915mm 910mm 276mm 910mm 134mm 1360mm...
- Page 5 Qty. Qty. PART PART 1560mm 1560mm 1560mm 1550X415mm 1560mm 1509mm 1509mm 1509mm 1550X415mm 888mm Qty. PART...
- Page 7 Qty. PART Qty. PART Qty. PART...
- Page 8 Qty. PART 、 When diagonal measurements are equal,the frame is square. 、 The Floor Frame must be BOTH square AND level or the holes will not line up properly. Qty. PART...
- Page 9 Qty. PART Ⅰ Ⅰ Ⅱ Ⅱ Qty. PART Qty. PART Ⅰ Ⅱ...
- Page 10 Qty. PART Qty. PART Ⅰ Ⅱ Qty. PART -10-...
- Page 11 Qty. PART Ⅰ Ⅱ Qty. PART Qty. PART -11-...
- Page 12 Qty. PART 7&8 Qty. PART Qty. PART F1 S3 -12-...
- Page 13 Qty. PART 21L&21R C1&C2 Qty. PART C3&C4 C1&C2 -13-...
- Page 14 Qty. PART Qty. PART -14-...
- Page 15 Qty. PART Qty. PART D1&D2 Qty. PART D1&D2 -15-...
- Page 16 Qty. PART 7&8 -16-...
- Page 17 Metal Garden Shed OWNER'S MANUAL Instructions for Assembly If you bought metal shed and window set at the same time, please read this manual. If not, please ignore manual The window set is only used to replace YX- Series metal shed with 156x43cm metal wall panels Requires two people and takes 0.1 hours for lnstallation.
- Page 18 P1-1 P1-1 P1-1 Disassemble P3 Pay attention to direction of window make sure it assembles correctly.
