Labconco XL 97001 Series User Manual

Hide thumbs

Table Of Contents

Table of Contents

Quick Links

Download this manual

User's Manual

Protector

Laboratory Fume Hoods

Premier

Models

4871300, 4871400, 4871500, 4871600, 4880000, 4880100, 4880200,

4880300, 4880400

6071300, 6071400, 6071500, 6071600, 6080000, 6080100, 6080200,

6080300, 6080400

7271300, 7271400, 7271500, 7271600, 7280000, 7280100, 7280200,

7280300, 7280400

9674500, 9683000

™

Models

97001 Series, 97002 Series, 97003 Series, 97004 Series, 97504 Series,

97505 Series, 97506 Series

www.labconco.com/productreg.html

or return the attached card and

receive FREE LabbyWear

LABCONCO CORPORATION

8811 PROSPECT AVENUE

KANSAS CITY, MO 64132-2696

800-821-5525, 816-333-8811

FAX 816-363-0130

E-MAIL labconco@labconco.com

HOME PAGE www.labconco.com

™

Labconco's Mascot,

Labby the LABster

Table of Contents

Need help?

Do you have a question about the XL 97001 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Labconco XL 97001 Series

Page 1 97505 Series, 97506 Series Register your product online at www.labconco.com/productreg.html or return the attached card and receive FREE LabbyWear ™ Labconco’s Mascot, Labby the LABster LABCONCO CORPORATION 8811 PROSPECT AVENUE KANSAS CITY, MO 64132-2696 800-821-5525, 816-333-8811 FAX 816-363-0130 E-MAIL labconco@labconco.com HOME PAGE www.labconco.com...
Page 3: Copyright Information
The warranty for all Labconco products will expire one year from date of installation or two years from date of shipment from Labconco, whichever is sooner, except the following: •...
Page 4: Table Of Contents
CHAPTER 1: INTRODUCTION About This Manual Typographical Conventions Your Next Step CHAPTER 2: PREREQUISITES Location Requirements Support Requirements Exhaust Requirements Exhaust Requirements Table Electrical Requirements Service Line Requirements Space Requirements Your Next Step CHAPTER 3: GETTING STARTED Unpacking Your Fume Hood Removing the Shipping Skid Sash Weight Release Installing the Hood on a Supporting Structure &...
Page 5 CHAPTER 5: USING YOUR PROTECTOR Operating the Vertical Rising Sash Operating the A-Style Combination Sash Operating the Blower Operating the Lights Working in your Protector Fume Hood Your Next Step CHAPTER 6: MAINTAINING YOUR FUME HOOD Routine Maintenance Schedule Routine Service Operations Your Next Step CHAPTER 7: MODIFYING YOUR FUME HOOD Installing Work Surfaces...
Page 6 Protector® Laboratory Fume Hood. Your Protector® Laboratory Fume Hood is designed to protect you. It is the result of Labconco’s more than 50 years experience in manufacturing fume hoods, and users like you suggested many of its features to us.
Page 7: Chapter 1: Introduction
Chapter 1: Introduction About This Manual This manual is designed to help you learn how to install, use, and maintain your laboratory fume hood. Instructions for installing optional equipment on your hood are also included. Chapter 1: Introduction provides a brief overview of the laboratory fume hood, explains the organization of the manual, and defines the typographical conventions used in the manual.
Page 8: Typographical Conventions
Chapter 1: Introduction Appendix A: Protector Hood Components contains labeled diagrams of all of the components of the fume hoods. Appendix B: Protector Hood Dimensions contains comprehensive diagrams showing all of the dimensions for the laboratory fume hoods. Appendix C: Protector Hood Specifications contains the electrical requirements for laboratory fume hood.
Page 9: Your Next Step
Chapter 1: Introduction • Critical information is presented in boldface type in paragraphs that are preceded by the exclamation icon. Failure to comply with the information following an exclamation icon may result in injury to the user or permanent damage to fume hood. •...
Page 10: Chapter 1: Introduction
Chapter 1: Introduction If your laboratory fume hood is installed and you need to perform routine maintenance on the cabinet, proceed to Chapter 6: Maintaining Your Protector Hood. For information on making modifications to the configuration of your fume hood, go to Chapter 7: Modifying Your Laboratory Fume Hood.
Page 11 Chapter 1: Introduction Product Service 1-800-522-7658...
Page 12 Before you install your laboratory fume hood, you need to prepare your site for installation. Carefully examine the location where you intend to install your hood. You must be certain that the area is level and of solid construction. In addition, a dedicated source of electrical power must be located near the installation site.
Page 13: Chapter 2: Prerequisites
Chapter 2: Prerequisites Location Requirements The fume hood should be located away from traffic patterns, doors, windows, fans, ventilation registers, and any other air-handling device that could disrupt its airflow patterns. All windows in the room should be closed. Support Requirements DO NOT install the fume hood on a cart, dolly, or mobile bench.
Page 14 1830 CFM 0.07" H 100 fpm 2290 CFM 0.10" H Proper blower selection can be determined from these exhaust requirements and the total system static pressure loss. Contact Labconco Customer Service for assistance in sizing a blower system. Product Service 1-800-522-7658...
Page 15: Electrical Requirements
Chapter 2: Prerequisites Electrical Requirements The Protector Hood models feature internal wiring for the fluorescent light assembly and light switch. All internal wiring is terminated at the single point wiring junction box for hook-up by a qualified electrician. The blower switch, and light switch wires are also terminated at the single point wiring junction box for hook-up by a qualified electrician.
Page 16 Now that the site for your laboratory fume hood is properly prepared, you are ready to unpack, inspect, install, and certify your unit. Read this chapter to learn how to: • Unpack and move your Protector Hood. • Set up the fume hood with the supporting structure and work surface.
Page 17: Chapter 3: Getting Started
(15) days of delivery. DO NOT RETURN GOODS WITHOUT THE PRIOR AUTHORIZATION OF LABCONCO. UNAUTHORIZED RETURNS WILL NOT BE ACCEPTED. IF YOUR HOOD WAS DAMAGED IN TRANSIT, YOU MUST FILE A CLAIM DIRECTLY WITH THE FREIGHT CARRIER.
Page 18: Removing The Shipping Skid
Chapter 3: Getting Started Removing the Shipping Skid LEAVE THE FUME HOOD ATTACHED TO ITS SHIPPING SKID UNTIL IT IS AS CLOSE TO ITS FINAL LOCATION AS POSSIBLE. MOVE THE HOOD BY USING A SUITABLE FLOOR JACK, OR BY PLACING A FURNITURE DOLLY UNDERDNEATH THE SKID.
Page 19 Chapter 3: Getting Started Install the Protector Hood on a Supporting Structure and Work Surface The Protector Hood is heavy! Use caution when lifting or moving the unit. When installing the Protector Fume Hood onto a chemically-resistant work surface or benchtop, ensure that the structure can safely support the combined weight of the fume hood and any related equipment.
Page 20 Chapter 3: Getting Started should be nonporous and resistant to the acids, solvents, and chemicals used in conjunction with the Protector Fume Hood. The work surface should also contain a dished recessed area for containing primary spills. Place Cross Support Here Figure 3-1 Dimensions Shown in Inches Hood Internal...
Page 21: Connecting To The Hood Exhaust System
The 4' integral blower model uses 10" (10.75" OD) duct. Consult Labconco Customer Service should you require help sizing your blower for the exhaust volume and total system static pressure loss.
Page 22 Chapter 3: Getting Started WARNING: The building electrical supply system for Protector Hoods should include overload protection. A switch or circuit breaker should be in close proximity to the equipment and within easy reach of the operator. The switch or circuit breaker is to be marked as the disconnecting device for the equipment.
Page 23: Connecting The Service Lines
NOTE: Inspect all fittings for leakage. Tighten the fittings slightly if needed. CAUTION: Do not use oxygen with any standard service fixture. Contact Labconco Customer Service for oxygen fixture information. Product Service 1-800-522-7658...
Page 24: Sealing The Protector Hood
• Hot Water • Vacuum • Cold Water • Natural Gas – See caution below WARNING: Contact Labconco Customer Service directly before using any service other than those listed above in these valves to assure full compatibility. CAUTION: Natural gas should be used only in the service fixture that has been pre-plumbed with brass tubing.
Page 25: Your Next Step
Industrial Ventilation Manual section on laboratory hoods. (See Appendix D – Reference) Labconco recommends an average face velocity at the sash opening of 80 to 100 feet per minute. Consult Labconco Customer Service for proper airflow volumes for your particular model.
Page 26 Performance Features: The Protector® Laboratory Hood is designed to meet the needs of the laboratory scientist. The laboratory fume hood has been designed to effectively contain toxic, noxious, or other harmful materials when properly installed. A fully featured by-pass hood with baffle and air foil, this hood maintains safe airflow.
Page 27: Chapter 4: Performance Features And Safety Precautions
Chapter 4: Performance Features and Safety Precautions 1. Unique sash provides maximum visibility of 32.15" high while conserving energy by limiting sash travel to 28". Vertical-rising sash may be raised from a closed to 28" operating height. Exhaust volume, and blower sizing is based on the 28"...
Page 28: Performance Features
Chapter 4: Performance Features and Safety Precautions 13. Shipped fully assembled and eliminates the need for costly onsite assembly. 14. Accessory Guardian™ Digital Airflow Monitor or Guardian Jr. Monitor continuously monitors face velocity. An audio/visual alarm alerts the user to low airflow conditions.
Page 29 Chapter 4: Performance Features and Safety Precautions Product Service 1-800-522-7658...
Page 30: Safety Precautions
Chapter 4: Performance Features and Safety Precautions Safety Precautions Although the laboratory hood has been engineered to maintain optimum operator safety, caution should always be used while working in the hood. Prior to using the hood, check to make sure that the exhaust blower is operating and that air is entering the hood at its specified face...
Page 31 Chapter 4: Performance Features and Safety Precautions Blocking the bottom of the baffle at rear of hood will change the airflow pattern in the hood causing turbulence and possible leakage at the face of the hood. (Don’t store containers or supplies against baffles, as this will affect airflow through the hood).
Page 32: Your Next Step
Chapter 4: Performance Features and Safety Precautions The use of heat-generating equipment in this hood without the exhaust system operating properly can cause damage to the hood. The Protector Laboratory Hood should be certified by a qualified certification technician before it is initially used.
Page 33 Chapter 4: Performance Features and Safety Precautions Product Service 1-800-522-7658...
Page 34: Operating The Vertical Rising Sash
Operating the Vertical- Rising Sash Because of the Protector Hood counterbalanced sash mechanism, it will take only a few pounds of force to move the sash up or down, and you can operate the sash smoothly with one or two hands positioned any where along the handle.
Page 35: Chapter 5: Using Your Protector Fume Hood
Chapter 5: Using Your Protector Fume Hood Operating the A-Style Combination Sash Optional hood models have additional energy saving sashes called A-Style Combination Sashes in place of vertical-rising sashes. These combination sashes allow the operator to use the hood with sashes either half open horizontally or vertically to conserve energy.
Page 36: Working In Your Protector Fume Hood
Chapter 5: Using Your Protector Fume Hood Working in your Protector Fume Hood Planning • Thoroughly understand procedures and equipment required before beginning work. • Arrange for minimal disruptions, such as room traffic or entry into the room while the hood is in use.
Page 37: Your Next Step
Chapter 5: Using Your Protector Fume Hood Final Purging • Upon completion of work, the hood should be allowed to operate for two to three minutes undisturbed, to purge airborne contaminants from the work area before shutting down blower. Unloading Materials and Equipment •...
Page 38 Now that you have an understanding of how to work in the fume hood, we will review the suggested maintenance schedule and the common service operations necessary to maintain your fume hood for peak performance. Only trained and experienced certification technicians should perform some of the service operations after the fume hood has been properly decontaminated.
Page 39: Chapter 6: Maintaining Your Protector Fume Hood
Chapter 6: Maintaining Your Protector Fume Hood Routine Maintenance Schedule Weekly • Using ordinary dish soap to clean the surface inside of the fume hood, and the work surface. • Using an appropriate glass cleaner, clean the sash and all glass surfaces. •...
Page 40: Routine Service Operations
Chapter 6: Maintaining Your Protector Fume Hood Routine Service Operations Front Panel Removal: 1. Simply lift the front panel up and then away from the hood to provide access to the top. Changing the Fluorescent Lamp: 1. Turn light switch to “OFF”. 2.
Page 41 Chapter 6: Maintaining Your Protector Fume Hood Product Service 1-800-522-7658...
Page 42: Installing Work Surfaces
Installing Work Surfaces Your Protector Fume Hood requires a work surface to work properly. Contact Labconco Customer Service for ordering information. Figure 7-1 Product Service 1-800-522-7658...
Page 43: Chapter 7: Modifying Your Protector Fume Hood
Enclosures above the Fume Hood Your Protector Fume Hood has mounting holes to accept a ceiling enclosure to close off the area between the top of the hood and the ceiling. Contact Labconco Customer Service for ordering information. Figure 7-2 Installing Rear Panels...
Page 44: Installing Additional Service Fixtures
Additional service fixtures can be installed in the available service fixture holes in both sidewalls and corner posts. The fume hood is factory set to accept up to four valves per side. Contact Labconco Customer Service for information. Figure 7-3 - Knob Figure 7-4 - Valve Figure 7-5 –...
Page 45: Distillation Grids - Field Installation
The distillation grids allow the hood user to mount glassware, motors, stirrers, and other apparatus. Contact Labconco Customer Service for ordering information. Figure 7-8 Sash Stop Kit – Field...
Page 46: Installing An Electrical Duplex Outlet
Your Protector Fume Hood can be ordered with duplex outlets, however, if you ordered a model without an electrical duplex outlet you can have one installed in the field by a qualified electrician. Contact Labconco Customer Service for ordering information. (Not acceptable on explosion-proof hoods).
Page 47 Chapter 7: Modifying Your Protector Fume Hood Product Service 1-800-522-7658...
Page 48 Refer to the following table if your fume hood fails to operate properly. If the suggested corrective actions do not solve your problem, contact Labconco for additional assistance. PROBLEM CAUSE CORRECTIVE ACTION Remote blower and Wires not connected Check connection of switches.
Page 49: Chapter 8: Troubleshooting
Chapter 8: Troubleshooting PROBLEM CAUSE CORRECTIVE ACTION Fume hood blower Lamp wiring is Inspect lamp wiring. operates but lights disconnected. will not operate Defective lamp Replace lamp ballasts. ballasts. Contaminants Improper user See “Certifying the Hood” Chapter 3 outside of fume techniques for the and “Safety Precautions”...
Page 50 Chapter 8: Troubleshooting PROBLEM CAUSE CORRECTIVE ACTION Vertical sash frame is Place horizontal glass symmetrically distorted. and pull sash down to air foil. Straighten damaged frame. Cable is frayed or has Re-install, cable must be replaced slipped off the immediately if damaged. pulleys.
Page 51 Chapter 8: Troubleshooting Product Service 1-800-522-7658...
Page 52 Quantity Part No. Description 9817000 Valve, Labconco ¼" Compression Fitting 9817001 Valve, Labconco 3/8" Compression Fitting 9817002 Valve, Labconco Deionized ¼" Compression Fitting 9817003 Valve, Labconco Deionized 3/8" Compression Fitting 9818000 Nut, Valve Mounting. (Labconco) 9826800 WaterSaver Valve/Gooseneck -GRN 9826801 WaterSaver Valve/Connector (VAC) –...
Page 53: Appendix A: Protector Components
Appendix A: Protector Components Item Quantity Part No. Description 9819000 Nut, Hose Barb - NOT SHOWN 9825500 Label, Knob (contains all the labels) 9818900 Lens, Knob 9826600, 01, 02 115V Duplex Receptacle (GRAY) Right, Left 4' - 6', Left 8' w/ wires 9818200 Cover Plate 115V Duplex 9826603, 04, 05...
Page 54 Appendix A: Protector Components Figure A-1 23, 25, 26, 27 5, 6 10, 21 Product Service 1-800-522-7658...
Page 55 Appendix A: Protector Components Product Service 1-800-522-7658...
Page 56: Appendix B: Protector Dimensions
Premier Model Widths 48.00 60.00 72.00 96.00 38.25 50.25 62.25 86.25 Dimensions in inches. CAD layouts available upon request. Figure B-1 Product Service 1-800-522-7658...
Page 57 Appendix B: Protector Dimensions Premier Integral Model Widths 48.00 60.00 72.00 38.25 50.25 62.25 Figure B-2 Product Service 1-800-522-7658...
Page 58 Appendix B Protector Dimensions XL Model Widths 48.00 60.00 72.00 96.00 120.00 144.00 192.00 External Depth 33.20, 39.20, or 45.20 38.25 50.25 62.25 86.25 110.25 134.25 182.24 Internal Depth 24.00, 30.00, or 36.00 Filler Panel 8.00, 14.00, or 20.00 Duct 48.00 50.00 62.00...
Page 59 Appendix B: Protector Dimensions Product Service 1-800-522-7658...
Page 60: Specifications
Environmental Conditions • Indoor use only. • Maximum altitude: 6562 feet (2000 meters). • Ambient temperature range: 41° to 104°F (5° to 40°C). • Maximum relative humidity: 80% for temperatures up to 88°F (31°C), decreasing linearly to 50% relative humidity at 104°F (40°C).
Page 61: Appendix C: Protector Specifications
Appendix C: Protector Hood Specifications Product Service 1-800-522-7658...
Page 62 Appendix C: Protector Hood Specifications Product Service 1-800-522-7658...
Page 63 Appendix C: Protector Hood Specifications Product Service 1-800-522-7658...
Page 64 Appendix C: Protector Hood Specifications Product Service 1-800-522-7658...
Page 65 Appendix C: Protector Hood Specifications Product Service 1-800-522-7658...
Page 66 Many excellent reference texts and booklets are currently available. The following is a brief listing: Laboratory Ventilation Standards Federal Register 29 CFR Part 1910 Non-mandatory recommendations from “Prudent Practices”. • Fume hoods should have a continuous monitoring device • Face velocities should be between 60-100 linear feet per minute (lfpm) •...
Page 67: Appendix D: References
Appendix D: References ASHRAE 110-1995 Method of Testing Performance of Fume Hoods Evaluates fume hood’s containment characteristics • Three part test: Smoke generation, Face velocity profile, Tracer gas release @ 4 liters per minute • Rated As Manufactured (AM), As Installed (AI) and As Used (AU) American Society of Heating, Refrigerating, and Air Conditioning Engineers...
Page 68 Appendix D: References NFPA 30 – 1996 Flammable and Combustible Liquids Code • Approved cabinets may be metal or wood • Vent location on cabinets are required • Venting of cabinets not a requirement National Fire Protection Association 1 Batterymarch Park P.O.
Page 69 Appendix D: References National Fire Protection Association, NFPA 45 Fire Protection for Laboratories Using Chemicals, Quincy, MA, 1996. NIH Guidelines for the Laboratory Use of Chemical Carcinogens. NIH Publication No. 81-2385. Rayburn, Stephen R. The Foundation of Laboratory Safety, A Guide for the Biomedical Laboratory. Springer-Verlag, New York: 1990 Sax, N.
Page 70 – – Required Tools The following tools will be required for disassembly and reassembly: Cordless Drills and Phillips bits. 1/4", 5/16", 3/8", 7/16" Sockets Small Screwdriver Phillips Screwdriver Right Angle Screwdriver 1/4", 5/16" Box Ratchet 1/4" Extension 5/16", 3/8", 7/16" Combination Wrench 1/4" Ratchet Small Right Angle Needle Nose Pliers Nut Driver Set Decorative Panel Removal 1.
Page 71: Appendix E: Disassembly And Reassembly Instructions
Appendix E: Disassembly and Reassembly Instructions Header Removal 1. The header is fastened to the corner posts by four #12 screws. Simply reach behind the corner posts from the side and remove the screws while another person supports the header. Sash Removal There is one sash to be removed on the 4', 5', and 6' hoods.
Page 72 Appendix E: Disassembly and Reassembly Instructions Airfoil Removal 1. Remove lower corner post screw located under the airfoil. 2. Remove the airfoil by removing the rear screws located on top of the airfoil on each side. Rear Frame Removal 1. Remove the rear frames from the side frames by removing screws from each side frame.
Page 73 Product Service 1-800-522-7658...
Page 74: Product Registration Card
Model Number* ______________________Serial Number* __________________________Date of Installation __________ *Model and serial numbers are located on the lower right-hand corner of the sash and the left-hand corner cover behind the front panel. Indicate Labconco accessories purchased with your Protector Hood. ❑ Acid Storage Cabinet ❑...
Page 75 LabbyWear is the official uniform ™ of LABsters everywhere! Be a LABster! As a token of our thanks for returning your Product Registration Card, we would like to send you the LabbyWear of your choice. Please select from one of the three items listed or collect Labby Bucks and redeem for other LabbyWear merchandise.
