Labconco Protector Echo User Manual

Filtered fume hoods
Hide thumbs
Table of Contents

Advertisement

Quick Links

Please read user's manual
before operating equipment
Original Instructions
LABCONCO CORPORATION
8811 Prospect Avenue
Kansas City, MO 64132
(800) 821-5525 I +1 (816) 333-8811
labconco.com
User's Manual
®
®
Echo™ & Protector
Airo™
Protector
Filtered Fume Hoods
Register this product
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Protector Echo and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Labconco Protector Echo

Summary of Contents for Labconco Protector Echo

  • Page 1 Please read user’s manual before operating equipment Original Instructions LABCONCO CORPORATION 8811 Prospect Avenue Kansas City, MO 64132 (800) 821-5525 I +1 (816) 333-8811 labconco.com User’s Manual ® ® Echo™ & Protector Airo™ Protector Filtered Fume Hoods Register this product...
  • Page 2 ® Echo™ Bench Top Filtered Fume Hood Protector 2020—Present 180410xxx 180510xxx 180610xxx 180810xxx 181410xxx 181510xxx 181610xxx 181810xxx 182410xxx 182510xxx 182610xxx 182810xxx ® Airo™ Bench Top Filtered Fume Hood Protector 2020—Present 184300xxx 184310xxx 184410xxx ® Echo™ Floor Mount Filtered Fume Hood Protector 2020—Present 183417xxx...
  • Page 3 Warranty Labconco Corporation provides a warranty to the original buyer for the repair or replacement of parts and reasonable labor as a result of normal and proper use of the equipment with compatible chemicals. Broken glassware and maintenance items, such as filters, gaskets, light bulbs, finishes and lubrication are not warranted.

  • Page 4: Table Of Contents

    Table of Contents 1: INTRODUCTION About This Manual Contents Included 2: BEFORE YOU INSTALL Location Requirements Clearance Requirements Electrical Requirements Service Line Requirements 3: SAFETY PRECAUTIONS Typographical Conventions General Safety Precautions Safety Precautions for this Product 4: INSTALLATION Unpacking Installation Filter Installation Calibrating the Airflow Sensor Certification...
  • Page 5 ® Neutrodine Filters Fan/Motor Front Airfoil Work Area Internal Service Lines Anemometer (Airflow Sensor) 6: FILTERED HOOD OPERATING SYSTEM Command Module Connecting to your filtered hood eGuard Alarm Screens 7: USING YOUR FILTERED HOOD System Reset Reset with eGuard Manual Reset Switch Sash Operation Controls Fans...
  • Page 6 Maintenance Safety Precautions Recommended Maintenance Schedule Service Operations Front Panel Removal Pre-filter Replacement Base Frame Replacement Neutrodine Filter Replacement Fan Replacement Optional HEPA Filter Installation or Replacement Airflow Sensor Replacement Acid & Formaldehyde Sensor Replacement 9: ACCESSORIES Filters Work Surfaces Base Stands, Accessory Shelves, Seismic Supports, and Hydraulic Lift Base Stands Storage Cabinets Installing Additional Service Fixtures...
  • Page 7 Wiring Diagram APPENDIX D: EGUARD Command Module Index: Connecting to your filtered hood with eGuard INFO LOGS SETTINGS Update: Connecting to your filtered hood with eGuard INFO eGuard Access Summary APPENDIX E: SETTING UP THE PROTECTOR ECHO FLOOR-MOUNTED FILTERED HOOD Unpacking...
  • Page 8 Remove from Shipping Skid Lower Base Installation Upper Cabinet Installation Sash Installation Vertical Sashes Sash Weights Sash Stops Corner Post Installation Wiring Baffle Installation Header Installation Filter Installation Front Panel Installation APPENDIX F: APPROVED CHEMICALS The Short List of Chemicals Not Recommended APPENDIX G: ACID/FORMALDEHYDE SENSOR LOCATIONS...

  • Page 9: 1: Introduction

    ® ® Echo™ or Protector Airo™ Congratulations on the purchase of a Labconco Protector Filtered Fume Hood. The filtered hood is designed on a traditional fume hood platform ® along with Neutrodine Filters that handle solvents, acids, and bases with one comprehensive filter.

  • Page 10: 2: Before You Install

    2: Before You Install Before you install the product, the site should be planned for installation. Examine the location where you intend to install it. You must be certain that the area is level and of solid construction. In addition, a dedicated source of electrical power must be located near the installation site.

  • Page 11: Electrical Requirements

    Electrical Requirements The product models have the following electrical requirements. Table 2-1 Face Light Total Hood Airflow Makeup Air No. of Fan Power Velocity Power Power Width (CFM) (CFM) Modules (watts) (fpm) (watts) (watts) 3 FT Up to 130 0, limited to min. 60-100 volume required 4 FT...

  • Page 12: 3: Safety Precautions

    3: Safety Precautions Before unpacking, installing, operating, maintaining, or servicing this equipment, read the following safety warnings and precautions. Avant le déballage, l’installation, le fonctionnement, l’entretien ou la maintenance de cet équipement, lire les avertissements de sécurité et les précautions d’emploi. –...
  • Page 13 – Air ambiant ou RISQUE DE BRÛLURE (TEMPÉRATURE ÉLEVÉE) composant devenant très chaud. Veiller à ne pas toucher ces zones délimitées. L’absence de précaution pour éviter ces zones peut entraîner des blessures modérées, voire graves. – Air or components that will be very EXTREME COLD (LOW TEMPERATURE) COLD.

  • Page 14: General Safety Precautions

    – Ne pas soulever ou déplacer cet équipement sans DANGER DE LEVAGE assistance. – Magnets or magnetic field present. MAGNETIC FIELD IN USE – Présence d'aimants ou de champ CHAMP MAGNETIQUE UTILISE magnétique. – Components or areas indicated are sensitive and will suffer DO NOT TOUCH damage if touched.

  • Page 15: Safety Precautions For This Product

    Never misuse this product. Never disable, override, or otherwise bypass safety guards, panels, switches, sensors or alarms. Doing so will result in moderate to serious injury, death, or damage to this product or property. Ne jamais utiliser ce produit à mauvais escient. Ne jamais désactiver, annuler ou contourner les capots, panneaux, interrupteurs, capteurs ou alarmes de sécurité.
  • Page 16 Do not overload the work surface with apparatus or work material. The safe operation of the laboratory hood is based upon having proper airflow through the structure. Do not place large, bulky objects such as block heaters, directly on the hood work surface.
  • Page 17 Do not use with organophosphoric (insecticide) compounds, mercury, hydrogen cyanide, or highly exothermic reactions. High exothermic reactions and smoke generation require the use of a HEPA filter. Ne pas utiliser avec (insecticides) composés organophosphorés, le mercure, le cyanure d'hydrogène, ou des réactions fortement exothermiques. Réactions exothermiques élevées et la production de fumée nécessitent l'utilisation d'un filtre HEPA.
  • Page 18 Proper operation of the filtered hood depends largely upon the hood’s location and the operator’s work habits. Le bon fonctionnement de la hotte filtrée dépend largement de l'emplacement de la hotte et les habitudes de travail de l'opérateur. If the hood is not operated as specified in this manual, it may impair the protection it provides.
  • Page 19 Use in areas where only trained users have access to the filtered hood. Any new users must be trained and should also read this User’s Manual. Utilisez dans les zones où seuls les utilisateurs formés ont accès à la hotte filtré. Les nouveaux utilisateurs doivent être formés et doivent également lire le manuel de l'utilisateur.
  • Page 20 HEPA filter during installation or normal operation. If you suspect that a HEPA filter has been damaged DO NOT use the filtered hood; contact a local certification agency or Labconco. La surface du filtre HEPA est fragile et ne doit pas être touché. Des précautions doivent être prises pour éviter de perforer le filtre HEPA pendant l'installation ou...
  • Page 21 d'accumulation dépend de la propreté de l'air ambiant, la quantité de temps le capot filtrée est en marche et la nature des travaux effectués dans la hotte filtré. Tag the filtered hood with appropriate warning if any filters have been removed for service.

  • Page 22: 4: Installation

    4: Installation With the installation site properly prepared, you are ready to unpack and install the equipment. This section covers how to:  Unpack and move the equipment  Install the equipment  Connect electrical service  Connect service utilities ...
  • Page 23 Note: United States Interstate Commerce Commission rules require that claims be filed with the delivery carrier within fifteen (15) days of delivery. Do not return goods without the prior authorization of Labconco. Unauthorized returns will not be accepted. If the product was damaged in transit, you must file a claim directly with the freight carrier.

  • Page 24: Installation

    Should you require disassembly to move the filtered hood, follow the instructions in Appendix E: Setting up the Protector Echo Floor-mounted Filtered Hood. Then, follow the steps listed (and Figure 4-1) to remove the shipping skid from the unit.
  • Page 25 chemicals used in conjunction with the filtered hood. The work surface should also contain a dished recessed area for containing primary spills. Warning: It is important to support the rear of the work surface and filtered hood. The cross support provides support for the bottom of the work surface. Install the cross support after the base cabinets and work surface are leveled and before installing the filtered hood.
  • Page 26 The following are instructions for mounting a cross support: 1. Level the base cabinets and the work surface. The filtered hood should be placed flush with the back of the work surface as shown in Figure 4-2. 2. Scribe a line on the wall or back of the base cabinet to locate the support under the work surface.
  • Page 27 Remarque: Inspectez tous les raccords pour les fuites. Serrez légèrement les raccords si nécessaire. Caution: Do not use oxygen with any standard service fixture. Contact Labconco Customer Service for oxygen fixture information. Prudence : Ne pas utiliser de l'oxygène avec l'accessoire de service standard.

  • Page 28: Filter Installation

    To confirm your order, make sure you have the correct number of fans for the filtered hood size:  M1 (1 column filtration) 3ft Protector Airo  M2 (2 column filtration) 4ft Protector Echo/Airo  M3 (3 column filtration) 5ft Protector Echo  M4 (4 column filtration) 6ft Protector Echo ...
  • Page 29  M2 (2 column filtration) 4 total Neutrodine filters  M3 (3 column filtration) 6 total Neutrodine filters  M4 (4 column filtration) 8 total Neutrodine filters  M5 (5 column filtration) 10 total Neutrodine filters Step 4 Make sure that you have located the power supply cord to attach power to the wall. If needed, the inlet power may be hard wired at the internal junction box.
  • Page 30 Step 8 Figure 4-4 With the pre-filter in place you are ready to BASE FRAME install the first Neutrodine filter. PRE-FILTER FIRST COLUMN 1. Start with the column closest to TO THE RIGHT the command module on the right corner post shown in Figure 4-4.
  • Page 31 Step 10 Repeat steps 7, 8 & 9 with all the primary filters needed for your size of filtered hood. Figure 4-7 Step 11 FAN BOX Now place the fan box (previously removed from the packaging) on top of the Neutrodine filter. Make sure the fan motor is up and the Erlab logo on the FAN LOCATOR HOLES...

  • Page 32: Calibrating The Airflow Sensor

    4. Place the cap from step 5 (Figure 4-3) on the connector called out in Figure 4- 8 (titled “Place cap here”). This is important to protect the filter junction for future use. Do not skip this step. Step 15 Make sure the secondary filter is properly seated on all sides of the fan box.
  • Page 33 Figure 4-10 Step 2 With the filtered hood powered, move the sash to your desired working height. It is recommended to MAINTENANCE be 2 to 3 inches above the working height to avoid nuisance alarms due to room pressure changes. Once in place, DO NOT move the sash until CONTAINMENT the calibration is completely over.

  • Page 34: Certification

    Step 8 The fans will automatically start and the lights inside the filtered hood will turn off. Again, the filtered hood will stabilize and chime when ready, which should be about 30 seconds. Step 9 In a stable filtered hood with the fan on, the anemometer will take readings for about a minute and calculate the approximate 80 fpm (or approximate 0.4m/s) value.

  • Page 35: 5: Performance Features

    5: Performance Features Labconco has combined its patented (U.S. Patent No. 6,461,233), containment- enhancing Protector Hood design with Neutrodine filtration technology to deliver a multi- use fume hood that requires no ducting. The filtered hood provides safety, energy savings, and adaptability to ever-changing lab spaces.

  • Page 36: Neutrodine ® Filters

    The HEPA filter manufacturer establishes the efficiency of the filter by challenging it with an aerosol of known particle size. The number of particles that penetrate the filter are quantified, and this establishes the efficiency of the filter. Note: HEPA filter media is very fragile. DO NOT touch the media. If you think the media of a HEPA filter is damaged, DO NOT USE THE FILTERED HOOD.

  • Page 37: Work Area

    Work Area Large usable interior work depth and interior Echo height of 48 inches (Airo 36 inches) provides ample working space. Available in 37.7-inch depth and 4', 5', 6' and 8' widths. 3' only available in 31.7-inch depth. Spillstopper™ Solid Epoxy Work Surface, reference Section 9: Accessories, is dished to contain spills (work surface sold separately).

  • Page 38: 6: Filtered Hood Operating System

    6: Filtered Hood Operating System The filtered hood operating system provides user control with the touch pad command module and a wireless interface called eGuard. eGuard connects the filtered hood’s command module to the user’s phone, laptop or tablet either through an Ethernet cable wireless (Wi-Fi or Bluetooth) connection.

  • Page 39: Connecting To Your Filtered Hood

    Connecting to your filtered hood For connecting your phone or tablet to the filtered hood: 1. Open the network selector on your device. 2. Select the Wi-Fi network: GFH-XXXXX-XXXX (the XXXX is the serial number of the filtered hood). 3. Password is: GFH-2018 4.

  • Page 40: Eguard

    eGuard Figure 6-4 The homepage (shown in Figure 6-4) has three sections titled INFO, LOGS and SETTINGS. The Name and serial number of the filtered hood is always shown here as well. INFO displays the usage time of the filtered hood, and the safety state of the following categories: Face Velocity, Fan, Filtration and Maintenance.
  • Page 41 The only way to safely and permanently stop the filtered hood from being in alarm is by solving the problem. Once the error is resolved, the alarm icons, flashing lights, and eGuard descriptions will go away.

  • Page 42: 7: Using Your Filtered Hood

    7: Using Your Filtered Hood This section details the functional features and proper techniques for safely and efficiently using the filtered hood. System Reset A reset, normally not required, may be needed if the filtered hood IP address and/or password was changed and forgotten. There are two ways to reset: Figure 7-1 Reset with eGuard To conduct a factory reset using eGuard, follow the steps...

  • Page 43: Sash Operation

    Sash Operation Because of the filtered hood counterbalanced sash mechanism, it will take only a few pounds of force to move the sash up or down, and you can operate the sash smoothly with one or two hands positioned anywhere along the handle. The vertical-rising sash may be raised to a maximum 16-inch operating height for proper airflow between 60-100 fpm.

  • Page 44: Outlet (Optional)

    information on decreasing the volume of the alarm see Appendix D:eGuard (Others). Outlet (Optional) If optional outlets found on the filtered hood are electrically connected, they will operate even if the filtration technology is not currently turned on. Start-up 1. To begin, make sure the filtered hood is plugged in. You will hear the power up chime when it is ready to operate.
  • Page 45  Press [Main ON/OFF] on the command module. This will turn off the fans and lights.  With fans and lights off, close the sash and leave the filtered hood until next use.

  • Page 46: 8: Maintaining Your Filtered Hood

    8: Maintaining Your Filtered Hood This section details the maintenance required for optimal operation of the filtered hood. Maintenance Safety Precautions The following tools and supplies are required to maintain the equipment:  #2 Phillips Screwdriver  Suitable dish soap, solvent, disinfectant, or cleaner ...

  • Page 47: Recommended Maintenance Schedule

    Recommended Maintenance Schedule Table 8-1 Maintenance Frequency Activity Weekly Quarterly Annually Wipe down interior with suitable • • • dish soap, solvent, disinfectant or cleaner Clean exterior surfaces (especially • • • front and top) of any dust with a damp cloth Operate fan system, noting airflow •...

  • Page 48: Front Panel Removal

    Front Panel Removal Removal of the front panel is necessary for changing the filtration technology. Tools Required:  6 FT ladder It is recommended to utilize at least two (2) persons to remove the front panel, particularly for a 6 FT and 8 FT model. The front panel is tall and heavy. Use safe lifting practices, and to set the panel where it cannot fall over while uninstalled from the filtered hood.

  • Page 49: Pre-Filter Replacement

    Replacing the Filtration Technology It is recommended to replace all filtration technology (filters, pre-filters, HEPA filters, etc.) at one time to maximize the efficiency of your time and effort. When filters need replacing, the first step will always be to order new ones. More information on available filters can be found in the Chapter 9: Accessories.
  • Page 50 Step 2 Access the old pre-filter from the trap door under the bottom of the filtration column. There are two clips at the front of the column. These clips may be fixed in place by two screws. Remove and save the screws, then push on the clips and pull the trap door down.

  • Page 51: Base Frame Replacement

    Step 4 Install the new pre-filter(s) in the empty trap door in place of the used one. Close the trap door and make sure the clips are secure and reapply the screws that were initially taken out of the doors. The compartment can fit 1 to 3 pre-filters at one time. Figure 8-6 Figure 8-7 TRAP DOOR...
  • Page 52 The following safety precautions must be followed by all personnel handling the equipment and filtration columns:  It is recommended you follow all of your existing lab safety protocols as they apply to this procedure.  2 persons are required for this procedure. ...
  • Page 53 Step 4 To access the base frames, you must remove the filters and fan box above the frame, as well as the base frames, filters and fan boxes to the left of the frame being replaced. This occurs because the base frames have an interlocking connection system to limit the amount of wiring needed.
  • Page 54 Once the hardware is removed, lift the frames (in order due to the interlocking design) and dispose of them in the correct manner. Figure 8-11 START WITH LIFTING OFF THE LEFT MOST BASE FRAME. INTERLOCKING CONNECTION Step 6 Once the old is removed, unpack and place the new base frames. Start with the furthest right frame being replaced.

  • Page 55: Neutrodine Filter Replacement

    base frame. Place the filters and fan boxes, taking great care to place them back in the column they came from. Reference filter and fan box labels applied during their initial installation. For more information on how to install the filtration technology, see Section 4: Installation (Filters).
  • Page 56 The following safety precautions must be followed by all personnel handling the equipment and filtration columns:  It is recommended you follow all of your existing lab safety protocols as they apply to this procedure.  2 persons required for this procedure. ...
  • Page 57 filter manufacturer to your job site. Remove all packing material, lay them flat and stack them out of the way of the filtered hood, but near it. Do not throw away any packaging until all filters are installed and operating correctly. Ensure you have a cap for every filtered unpacked.
  • Page 58 sticker. Remove the secondary sticker if needed to make the new label clear. To review how to install filters see Section 4: Filtration Installation. Once stacked, make sure the locators are inserted firmly and the electrical connections are good. Remove the cap covering the electrical connection and save.

  • Page 59: Fan Replacement

    Fan Replacement Fans will need replacement when damaged or if failure occurs in the fan’s motor or solvent sensor. This section will cover how to:  Remove front panel  Identify your model and order new fans  Unpack new fan boxes ...
  • Page 60 Step 3 To unpack the new fans, carefully remove from the packaging. Keep track of all boxes after unpacking. The fan boxes are shipped directly from the filter manufacturer to your job site. Once you’ve remove all packaging material, lay them flat and stack them out of the way of the filtered hood but near it.

  • Page 61: Optional Hepa Filter Installation Or Replacement

    Step 8 Repeat steps 4 through 7 for all columns that need a fan box replaced. All fan boxes must be disposed of correctly. When completed, it will look like Figure 8-19. Figure 8-19 REINSTALLED SECONDARY FILTER NEW FAN BOX Step 9 When all fan boxes have been replaced, connect the filtered hood to power.
  • Page 62 Figure 8-20 1P2C SECONDARY Traditional configuration for use with NEUTRODINE FILTER powders, liquids and vapors, the 1P2C FAN MODULE column configuration positions the PRIMARY NEUTRODINE FILTER HEPA filter immediately above the JUNCTION FRAME base frame. Following the HEPA filter is the junction frame, primary filter, fan HEPA FILTER box and secondary filter on top.
  • Page 63 The following safety precautions must be followed by all personnel handling the equipment and filtration columns:  It is recommended you follow all of your existing lab safety protocols as they apply to this procedure  2 persons required for this procedure ...
  • Page 64 Step 5 If you are installing the HEPA filters for the first time, ignore this and move to the next step. Remove the old HEPA filters you just labeled as “Used”. This filter will no longer be in use so it must be disposed of correctly. Consult local regulations and laws for disposal of hazardous waste.

  • Page 65: Airflow Sensor Replacement

    closest to the HEPA. Also check the seal is tight and electrical connection is good. Make sure the secondary filter is the top most layer of the column and has a cap covering the electrical plug on the top of the filter. Step 8 Repeat for all columns that need new or replaced HEPA filters.

  • Page 66: Acid & Formaldehyde Sensor Replacement

    as shown in Figure 8-23. Remove and save this hardware for later. Lift the left side panel approximately 3 inches up to clear the structures holding it in place and pull straight away from the filtered hood until free of the filtered hood. Store away from the filtered hood and keep track of this panel.
  • Page 67 Step 1 Order and unpack the new sensor. Orderable parts can be found in Appendix A: Parts List. Locate the fan box in the filtered hood with the ‘A’ or ‘F’ sticker as shown in Figure 8-25. This is the old sensor; label it as ‘Used’. If installing the sensor for the first time, reference Appendix G:Acid/Formaldehyde Sensor Locations for placement instructions.
  • Page 68 Step 5 Start up the filtered hood. If the filtered hood is in alarm, check eGuard for the explanation. If eGuard says the base frame has been replaced, press the [mute] button on the command module. If there is an alarm other than the replacement message, disconnect the power, re-check all electrical connections and try again.

  • Page 69: 9: Accessories

    9: Accessories This section details the available field-installable accessories and approved modifications for the filtered hood. These include the addition of replacement Neutrodine carbon filters, HEPA filters, work surfaces, base stands, base stand shelves, seismic supports, storage cabinets, service fixtures, electrical duplex outlets, sash stops, distillation grids and sash reduction wing kits.
  • Page 70 Use this key to configure the seven digit catalog number to order a SpillStopper Dished Solid Epoxy Work Surface. For example, a 9501610 is a 6 FT wide x 36-inch deep SpillStopper Work Surface, with a left rear cupsink cutout. Figure 9-1...

  • Page 71: Base Stands, Accessory Shelves, Seismic Supports, And Hydraulic Lift Base Stands

    Base Stands, Accessory Shelves, Seismic Supports, and Hydraulic Lift Base Stands The following base stands, hydraulic lift base stands, accessory shelves, and seismic supports may be used with the accessory work surfaces to support the filtered hoods. Hydraulic Lift Base Stands allow easy movement up and down and may be portable if the caster kit is also ordered.

  • Page 72: Storage Cabinets

    Storage Cabinets The following storage cabinets may be used with the accessory work surfaces to support the filtered hoods. Table 9-4 SOLVENT ACID Dual Right Left Dual Right Left Size/Description Doors Hinge Hinge Doors Hinge Hinge 48” 9902000 9901000 36” 9902100 9901100 30”...

  • Page 73: Cold Water Gooseneck Fixture Kits

    Table 9-6 Max. Max. Flaw Knob/Connector Catalog # Tubing Valve Working Color Rate Pressure Copper Brass Green 3.5 GPM 40 psi 9808300** Cold Water (CW) (13.2 LPM) 9808400** Copper Brass Orange 23.7 CFM 40 psi Air (AIR) Copper Brass Yellow 8.6 CFM 14.7 psi 9808500**...

  • Page 74: Deionized/Distilled Water Gooseneck Fixture Kit

    GPM = gallons per minute, LPM = liters per minute, CFM = cubic feet per minute, BTU/sec = British thermal unit per second, LBM/min = pounds mass per minute, *Contact Labconco for ordering information on Standard Service Features with chrome-plated bras hose connectors for protector Stainless Steel Hoods, †Maximum allowable pressure is 200 psi with a working pressure of 40 psi, ** Protector Stainless Steel and PVC Hoods require drill hole in liner, ††...

  • Page 75: Sash Stop Kit

    The distillation grids allow the hood user to mount glassware, motors, stirrers and other apparatus. They are for Benchtop Echos only. For orderable Floor-Mounted Distillation Grids contact Labconco. Kits include stainless steel rods, connectors, instruction sheet and drill template. Requires installation including drill holes.
  • Page 76 Table 9-15 Sash Wing Catalog # Description Sash Opening Width 10” 9584904 4 FT Sash Reduction Wing Kit 18" W X 16" H 12” 9584905 5 FT Sash Reduction Wing Kit 26" W X 16" H 14” 9584906 6 FT Sash Reduction Wing Kit 34" W X 16" H 19”...

  • Page 77: 10: Troubleshooting

    10: Troubleshooting This section details common troubleshooting for the filtered hood. Service valves no longer operate...

  • Page 78: Fans And Lights Not Working

    Fans and Lights not working...

  • Page 79: Vertical Sash No Longer Operates Smoothly

    Vertical sash no longer operates smoothly...

  • Page 80: Electrical Duplex Outlets No Longer Have Power

    Electrical duplex outlets no longer have power Fan operates but lights dim or not working...

  • Page 81: Contaminates Outside The Filtered Hood

    Contaminates outside the filtered hood...

  • Page 82: Lights Operate But Fans Will Not

    Lights operate but fans will not...

  • Page 83: Smart Command Alarms

    Smart Command Alarms...
  • Page 84 If needed, contact Labconco to troubleshoot further.

  • Page 85: Appendix A: Parts List

    Required Number Description 9823700 Valve, Labconco (Water) 1/4" Compression Fitting 9823701 Valve, Labconco (Water) 3/8" Compression Fitting Valve, Labconco 1/4" Compression Fitting (AIR, GAS, VAC, 9817000 NIT, etc.) Valve, Labconco 3/8" Compression Fitting (AIR, GAS, VAC, 9817001 NIT, etc.) 9823702 Valve, Labconco Deionized 1/4"...

  • Page 86: Neutrodine (By Erlab) Filtration Technology Replacement Parts

    Quantity Item Required Catalog Number Description 9947100, 01, 02 115V Duplex Receptacle (GRAY) Right, Left 4' - 6',Left 8' w/ wires 9818200 Cover Plate 115V Duplex 9947103, 04, 05 115V GFCI Duplex Receptacle (GRAY) Right 4'-6',Left 8' w/ wires 9818100 Cover Plate, 115V GFCI 9818300 Cover Plate, Blank...
  • Page 87 Quantity Catalog Item Required Number Description 9575023 3 FT (M1) Complete Airo w/ Formaldehyde Tech. Package, no filters 9575024 4 FT (M2) Complete Echo/Airo w/ Formaldehyde Tech. Pack, no filt. 5 FT (M3) Complete Echo w/ Formaldehyde Tech. Package, no filt. 9575025 9575026 6 FT (M4) Complete Echo w/ Formaldehyde Tech.
  • Page 88 Figure A-1 25 27 28 22 23 24 REFERENCE: 1 2 3 4 5 6 SERIAL TAG...

  • Page 89: Appendix B: Dimensions

    Appendix B: Dimensions Table B-1 and Figure B-1 indicate the benchtop filtered hood product dimensions. Table B-2, B-3 and Figure B-2 indicate floor mounted filtered hood product dimensions. All dimensions shown are in inches unless specified. ® Echo™ Bench Top Filtered Fume Hood Protector Table B-1 Width...

  • Page 90: Protector ® Echo™ Floor Mount Filtered Fume Hood

    ® Echo™ Floor Mount Filtered Fume Hood Protector 2.5" ID (64 cm) UTILITY PASS-THROUGH OPENING 2.3" (5.8 cm) FILTRATION COLUMN, (NEUTRODINE 2G FILTERS SOLD 3.7" SEPARATELY) (9.4 cm) SINGLE POINT INTERNAL FIELD W IRED BOX, ONE 1.9" ON EACH SIDE (9.4 cm) Figure B-2 4.0"...

  • Page 91: Protector Airo™ Bench Top Filtered Fume Hood

    ® Airo™ Bench Top Filtered Fume Hood Protector Figure B-3, B-4 & B-5 indicates small 54.2” height Airo product dimensions. All dimensions shown are in inches unless specified. Figure B-3 MODEL SERIES 3' X 31.7" AIRO 4.00 MINIMUM AIR GAP ADD 3 INCH FOR 36.0 HEPA FILTER...
  • Page 92 Figure B-5 4.00 MODEL SERIES 4' X 37.7" AIRO MINIMUM AIR GAP ADD 3 INCH FOR HEPA FILTER 54.2 36.0 INTERNAL 28.6 24.2 26.0 HEIGHT 21.5 SASH HEIGHT OPENING 48.0 37.7...

  • Page 93: Appendix C: Specifications

    Appendix C: Specifications Environmental Conditions  Indoor use only.  Maximum altitude: 10,000 feet (3,048 meters).  Ambient temperature range: 41° to 104°F (5° to 40°C).  Maximum relative humidity: 80% for temperatures up to 88°F (31°C), decreasing linearly to 50% relative humidity at 104°F (40°C). ...

  • Page 94: Wiring Diagram

    Wiring Diagram Figure C-1...

  • Page 95: Appendix D: Eguard

    Appendix D: eGuard The filtered hood operating system provides user control with the touch pad command module and a Wi-Fi-connection interface called eGuard. eGuard connects the filtered hood to the user’s phone, laptop or tablet either through an Ethernet cable into the command module or by connecting the mobile device to the network of the filtered hood that will be used.

  • Page 96: Info

    (the XXXX is the serial number of the filtered hood). 3. Password is: GFH-2018 4. Open an internet browser (Google Chrome, Mozilla Firefox… etc.) and enter the following address in the browser menu: http://192.168.1.1 For connecting the filtered hood to a laptop: 1.

  • Page 97: Logs

    LOGS Figure D-4 LOGS has record of this filtered hood’s specific event history and will keep track of alarms and power on/off of the hood. Every event recorded will have a date and time stamp and the code in one scroll through menu. Date and time of every alarm occurring and subsequently cleared, as well as general use records will be documented all in one place.
  • Page 98 Date/Time Figure D-7 Also available for manipulation is the date and time. You must check and set the correct date and time. Usage time from the INFO page and every recording in the LOGS event history requires an accurate date and time.
  • Page 99 Sensor Sensitivity Here the sensitivity of the filtered hood’s sensors can be adjusted. In addition, background noise can be taken in to account, but should only be used after investigation. Premature use of the option can cause Figure D-10 limitations of the sensor that limit safety unnecessarily. No numeric value can be seen for the solvent adjustment, but a range is still used and displayed for the setting bar.

  • Page 100: Update: Connecting To Your Filtered Hood With Eguard

    Update: Connecting to your filtered hood with eGuard Another page with options for manipulation is the update section of eGuard. Your phone, tablet or laptop still needs to be connected to the filtered hood: 1. Open the network selector on your device. 2.
  • Page 101 the fans even if there are no primary filters. Figure D-13 shows the default settings of the filtered hood. To make changes adjust the switches as needed and touch [Update]. The range of the rotation speed possible by the fan boxes are 1,000 to 3,000 rpm. It is recommended to stay at or below 2,400 rpm (or 2,600 with optional HEPA filters) for a Working Setpoint as it will effect dwell time.

  • Page 102: Eguard Access Summary

    Figure D-16 eGuard Server configuration The eGuard server can be changed. Shown in Figure D- 16 is the default. If changes are needed, simply type the desired server settings in the boxes. To make changes touch [Update]. The same can be done for the server port.

  • Page 103: Appendix E: Setting Up The Protector Echo Floor-Mounted Filtered Hood

     Unpack and move the floor-mounted filtered hood.  Set up the floor-mounted filtered hood. Your Protector Echo Floor-Mounted (Walk-In) Filtered Hood was shipped as ten main component assemblies located on three shipping skids. The skids are as follows: 1. Lower base and sashes 2.

  • Page 104: Unpacking

    The Protector Echo Floor-Mounted Filtered Hood models weigh between 700 to 1500 lbs. (318-675 kg). The multiple shipping pallets allow for lifting with a mechanical lift truck or floor jack. If you must lift the filtered hood manually, follow safe-lifting guidelines.

  • Page 105: Upper Cabinet Installation

    Upper Cabinet Installation Remove the upper cabinet assembly side panels. Place the upper cabinet assembly on top of the lower base assembly. Be sure to clear the lower base assembly during placement. Mount the lower base to the upper cabinet using the ¼-20 hex head screws, lock washers, and nuts included in the hood package.

  • Page 106: Sash Weights

    Sash Weights The sash weights have been secured to the shipping skid. Remove the weights from the skid and attach them to the respective sash cables using the hooks provided. With the sashes in place, install the counterbalance weights. The large single sash weight is installed in the middle and attached to the lower rear sash.

  • Page 107: Wiring

    are held in place by stainless steel machine screws. The outer back edge of both corner posts are held in place with steel self-drilling screws. The screws are included in the filtered hood packet. See Figure E-3. Now reinstall the side panels of the lower base. Figure E-3 LEFT CORNER LOWER MIDDLE...

  • Page 108: Baffle Installation

    Figure E-4 LINER TOP REFERENCE SMALL UPPER BAFFLE UPPER MIDDLE BAFFLE BRACE, HARDWARE & HARDWARE COVERS LOWER MIDDLE PERFORATED BAFFLE LOWER PERFORATED BAFFLE Baffle Installation Be sure the baffles are resting in the proper baffle mount supports. The upper baffles require a small baffle connected to a large baffle via a brace, hardware, and hardware covers.
  • Page 109 Figure E-5 TYPICAL NEUTRODINE FILTRATION TECHNOLOGY #12 SCREWS FRONT PANEL CORNER POST HEADER...

  • Page 110: Appendix F: Approved Chemicals

    Appendix F: Approved Chemicals ® List of approved chemicals for GreenFumeHood Technology (GFHT) with proprietary ® Neutrodine Filtration. More information on the approved chemical long list can be found online through Erlab. Get to the pdf on a computer by clicking here. If the embedded link did not work, follow these steps: 1.
  • Page 111 This guide is the result of 50 years of research and development into filtration ® technologies and demonstrates the expertise of Erlab’s R&D laboratory in the field of molecular and particulate filtration. ® This booklet is delivered with every filtered hood equipped with GreenFumeHood ®...

  • Page 112: Appendix G: Acid/Formaldehyde Sensor Locations

    Appendix G: Acid/Formaldehyde Sensor Locations Fan boxes that have acid or formaldehyde sensors will be labeled with small ‘A’ or ‘F’ stickers in the bottom left corner of the fan face and the carton it shipped in. The installment locations for the sensors will be as follows: Figure G-1 Key: S = Solvent Sensor (standard on all Fan Modules)
