Table 3-1. Features of the PERC S100 controller and PERC S300 controller
RAID Controller Feature Description
Physical disk roaming The controller supports moving a physical disk from one
Storage port (Storport)
driver support
Stripe size
26
Features
backplane slot or cable connection to another (on the same
controller). The controller automatically recognizes the
repositioned physical disk and logically places it in the proper
order.
WARNING:
roaming while an OCE is running at Storage Management.
NOTE:
For more information on how to open the system and
add parts, see the Hardware Owner's Manual, available on the
Dell Support website at support.dell.com/manuals.
Perform the following steps for physical disk roaming:
NOTE:
These steps do not apply to systems that have a
backplane with hot-swap capability.
Turn off the power to the system, physical disks, and system
1
components.
Disconnect the power cables from the system.
2
Move the physical disks to different slots on the backplane
3
or to different cable connections.
Perform a safety check. Make sure the physical disks are
4
inserted properly.
Connect the power cables and power up the system.
5
NOTE:
The controller detects the RAID configuration from the
configuration data on the physical disks.
For use with Microsoft Windows Server 2003 and later, the
Storport driver improves throughput and miniport driver
interfaces.
Stripe size is determined by a PERC S100 adapter/PERC
S300 adapter algorithm. Stripe size cannot be configured by
the user.
A virtual disk is lost if you perform disk
(continued)
