- Page 1 ST3601 Issue: 4 Description: ROBINHOOD SUPERTUB CLASSIC Model Number: ST3601, ST3601A Model pictured: ST3601 All dimensions in mm Model may vary slightly from images pictured...
-
Page 2: Contents Of Packaging
Allow 10mm clearance between the units. Mark the position on the floor as reference. Important safety information This Robinhood Supertub is not intended for use by young children or infirm persons without supervision. Young children should be supervised to ensure that they do not play with the Robinhood Supertub. - Page 3 Installing the Supertub Confirm if the door or washing machine waste inlet needs to be moved from right to left before securing the unit to the wall. If they do need to be changed see page 6 of these installation instructions. Fit the four adjustable feet supplied to the bottom of the cabinet and adjust to align with worktop or washing machine height.
- Page 4 Installing the Supertub cont. For easier installation of the tap ware remove the four screws holding the console in position, this also gives you access to the rear bracket of the laundry tub (can be seal on installation). Fit the tap ware to the tub using the supplied fittings.
-
Page 5: Cleaning And Maintenance
Cleaning and maintenance Powder coated surfaces must not be cleaned with abrasive or chemical cleaners. To keep the Robinhood Supertub looking its best, wipe regularly with a damp soft cloth. A mild soap and water solution may be used to remove stubborn dirt. - Page 6 Changing the washing machine inlet from right to left The washing machine outlet waste hose can be connected to either side of the Robinhood Supertub. On the outside of the laundry tub remove the screws from the white plastic washing machine waste inlet and the white plastic blanking plate.
- Page 7 Suggested plumbing fittings required for Australian installations Your ST3601A Supertub is supplied with a standard 40mm waste fitting and this will require either a S or P trap for connection to your household plumbing, using the suggested parts below or as required by your licensed plumber.
- Page 8 The product was not used, cleaned or cared for in accordance with our instructions. The product was used outdoors. All Robinhood rangehoods are suitable for indoor use only, and not suitable over BBQs or charcoal cookers designed for outdoor use.
- Page 9 The product was used outdoors. 2. All Robinhood rangehoods are suitable for indoor use only and not suitable over BBQs or charcoal cookers designed for outdoor use. 3. In addition, this warranty does not extend to damage or defects which in our opinion, directly or indirectly arise from or are due to: exposing the product to acidic or corrosive materials or chemicals such as dyes, solvents, denture cleaner or acetone;...
