- Page 1 Issue: 4 Description: ROBINHOOD SUPERTUB DOUBLE DRAWER Model Number: ST7001 Model pictured: ST7001 Page 1 of 6...
- Page 2 Exploded Tub Assembly Page 2 of 6...
- Page 3 Exploded Tub Assembly Cont Part number Item Description ST 7001 Waste grill screw 752230 Waste grill 752214SS Overflow O ring 752220 Overflow screw (1 off) 999074 Waste seal 752209 Waste body 752205 Overflow hose clip 752229 Washing machine waste hose 752224 Washing machine waste inlet 752201...
- Page 4 Exploded Chassis Assembly Part number Item Description ST7001 Bottom drawer complete (less handle) 751066 Top drawer complete (less handle) 751067 Bottom drawer side/runner set (left & right hand) (2 x Supplied with item 1 sides & 2 x runners) Top drawer side/runner set (left & right hand) (2 x sides &...
- Page 5 Exploded Tap Assembly Part number Item Description ST7001 Tap complete including hoses and fittings 751140 Ceramic disc cartridge 751140C Part not available Aerator O ring Part not available Aerator cartridge Part not available Aerator screw end 751140OR Tap Washer Seal...
- Page 6 Installation Kit Part number Item Description ST7001 Installation kit complete (as shown above) 752043 Plug 750636 Adjustable foot assembly (1 off) 750920 Cable tie Available from Hardware Stores ECN: 07034 Australia Shriro Australia Pty Limited (ABN 28 002 386 129)
