Futurepump SE1 Manual

SE1 Solar Irrigation Pump (60W)
The Futurepump SE1 is a robust surface pump
designed for smallholder farmers with shallow water
sources, it can pump up to 0.44 litres per second of
water using just the power of the sun.
The Futurepump SE1 has three main parts:
a PV panel (60Wp) which converts sunlight into
electrical energy to drive the DC motor, a specially
designed unit coupled to a flywheel, which drives a
reciprocating, positive displacement, high efficiency
piston pump.
BENEFITS
No fuel or electricity costs
•
Robust, and farmer-fixable (as simple as a
•
bicycle)
Pumps enough to irrigate up to one acre
•
Ideal with tanks, sprinklers, hoses or drip systems
•
Removable, folding PV panels reduces theft risk
•
Supplied with 1 x 60W panel
•
Solar panel tilting system for best performance
•
No damage caused by dry pumping
•
Tolerant of grit, sand, mud and debris
•
futurepump.com
PERFORMANCE
At shallow heads (1m), the Futurepump SE1 can
deliver up to 0.44 litres per second, which is 1,600
litres per hour or over 9,500 litres per 6-hour
pumping day.
Small pulley
1 meter lift
1600 litres/hr
Inlet side vertical suction limit: 7 metres
•
Maximum total head: 15 metres
•
Horizontal discharge: up to 500m
•
Peak system efficiency: 60%
•
® © Futurepump Ltd 2024. Patent Pending. All Rights Reserved.
Discharge lift
Hauteur de décharge
Elevador de saída
Suction lift
Hauteur d'aspiration
Elevador de sucção
Max 7m (22ft)
Large pulley
Change pulley over for higher head
6.5 meter lift
1200 litres/hr
Total head
Hauteur
manométrique
totale
Aumento total
Max 15m
(50ft)
