Eaton TRIPP LITE DWM3780XOUT Owner's Manual

Eaton TRIPP LITE DWM3780XOUT Owner's Manual

Outdoor full-motion tv wall mount
Hide thumbs
1
2
3
4
5
6
7
8

Advertisement

Table of Contents

Owner's Manual
Outdoor Full-Motion
TV Wall Mount
CAUTION: DO NOT EXCEED MAXIMUM LISTED WEIGHT CAPACITY. SERIOUS INJURY OR PROPERTY
DAMAGE MAY OCCUR!
200 x 200, 300 x 200
300 x 300, 400 x 200
400 x 300, 400 x 400
600 x 400
Este manual está disponible en español en la página de Eaton:
Tripplite.Eaton.com/support
Ce manuel est disponible en français sur le site Web de Eaton :
Tripplite.Eaton.com/support
Русскоязычная версия настоящего руководства представлена на веб-сайте компании
Eaton по адресу: Tripplite.Eaton.com/support
Dieses Handbuch ist in deutscher Sprache auf der Eaton-Website verfügbar:
Tripplite.Eaton.com/support
80"
MAX
PRODUCT REGISTRATION
Register your product today for a
chance to win an ISOBAR
surge
®
protector in our monthly drawing!
Tripplite.Eaton.com/warranty
Model:
DWM3780XOUT
110 lb.
110 lb.
(50 kg)
(50 kg)
RATED
RATED
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TRIPP LITE DWM3780XOUT and is the answer not in the manual?

Questions and answers

Related Manuals for Eaton TRIPP LITE DWM3780XOUT

Summary of Contents for Eaton TRIPP LITE DWM3780XOUT

  • Page 1 RATED RATED Este manual está disponible en español en la página de Eaton: Tripplite.Eaton.com/support Ce manuel est disponible en français sur le site Web de Eaton : Tripplite.Eaton.com/support Русскоязычная версия настоящего руководства представлена на веб-сайте компании Eaton по адресу: Tripplite.Eaton.com/support Dieses Handbuch ist in deutscher Sprache auf der Eaton-Website verfügbar:...

  • Page 2: Important Safety Instructions

    PRODUCT REGISTRATION Visit Tripplite.Eaton.com/warranty today to register your new product. You’ll be automatically entered into a drawing for a chance to win a FREE Eaton Tripp Lite series product!* * No purchase necessary. Void where prohibited. Some restrictions apply. See website for details.

  • Page 3: Component Checklist

    Component Checklist IMPORTANT: Ensure you have received all parts according to the component checklist prior to installing. If any parts are missing or faulty, visit Tripplite.Eaton.com/support for service. Mount Assembly Adapter Bracket Cable Tie Hex Key (x1) (x2) (x2) (x2)
  • Page 4 Assembly Mount on Wood Stud Wall 2.4" (60 mm) 2.4" (60 mm) Ø 5/32" Ø 5/32" (Ø 4 mm) (Ø 4 mm) Find and mark the exact location of Drill pilot holes Screw the wall mounting holes mount onto the wall WARNING •...
  • Page 5 Assembly Mount on Solid Brick or Concrete Block 2.6" (65 mm) 2.6" (65 mm) Ø 3/8" Ø 3/8" (Ø 10 mm) (Ø 10 mm) Find and mark Drill pilot holes Screw the wall the exact mount onto location of the wall mounting holes WARNING •...
  • Page 6 Assembly Install Adapter Brackets For Flat Back Screen M-C/M-D M-C/M-D M-C/M-D For Recessed Back Screen or to Access A/V Inputs Note: Choose appropriate screws, washers and spacers (if necessary) according to the type of screen. • Position the adapter brackets as close as possible to the center of the display. •...
  • Page 7 Assembly Hang Display onto the Wall Mount With the aid of an assistant or mechanical lifting equipment, hook the display with attached adapter brackets over the top of the wall mount’s arm assembly plate. Hang Display onto the Wall Mount Tighten the two safety bolts on the bottom of the adapter brackets to secure the unit.

  • Page 8: Cable Management

    –3° +3° Maintenance • Check that the bracket is secure and safe to use at regular intervals (at least every three months). • Please visit Tripplite.Eaton.com/support if you have any questions. Eaton 1000 Eaton Boulevard Cleveland, OH 44122 United States Eaton.com...
