93pm ups (208–480v) seismic door retention kit

Advertisement

E E a a t t o o n n 9 9 3 3 P P M M U U P P S S ( ( 2 2 0 0 8 8 – – 4 4 8 8 0 0 V V ) ) S S e e i i s s m m i i c c ( ( O O S S H H P P D D ) ) D D o o o o r r R R e e t t e e n n t t i i o o n n K K i i t t I I n n s s t t a a l l l l I I n n s s t t r r u u c c t t i i o o n n s s
Use these instructions to install the seismic door retention kit brackets to secure the uninterruptible power
supply (UPS) door. One kit is required per UPS door.
These instructions are applicable to all UPS frame sizes for the following models:
Eaton 93PM-L UPS (208V)
Eaton 93PM UPS (480V)
NOTE 1
NOTE 2

Seismic Door Retention Kit Contents

Bracket, 93PM Cabinet, OSHPD
Bracket, 93PM Door, OSHPD
Flange Head Bolt, Black M5 X 12
NOTE See
For seismic installations, the UPS cabinet floor mounting surface must be level.
To install the brackets:
1.
Unload and mechanically install the UPS according to the instructions in the applicable installation and
operation manual.
2.
Open the UPS door. Locate the horizontal slot on the top rear of the door. See
horizontal slot location.
3.
Remove the two M4 screws directly beneath the opening. See
4.
Install the door bracket and secure with two M4 screws previously removed. Hand tighten the screws.
5.
Install the cabinet bracket using the two M5 thread forming screws included in the kit. Hand tighten the
screws. See
6.
Both brackets have slots for adjusting bracket position. Adjust brackets so the spring-loaded fastener on
the cabinet bracket aligns with the threaded insert of the door bracket.
7.
Once the brackets are properly aligned, secure the brackets by tightening the screws to the following
torque specifications.
Door bracket M4 screws
Cabinet bracket M5 screws
8.
Close and secure the UPS door.
This kit is used to support seismic installations where applicable.
Refer to the installation and operation manual supplied with the UPS for dimensions and
required clearances.
Figure 1
for door retention kit details.
Figure 3
for cabinet bracket mounting location and
Eaton 93PM UPS (208–480V) Seismic (OSHPD) Door Retention Kit Install Instructions
IMPORTANT
Figure 2
for the screw location.
Figure 4
bracket installation details.
2.0–3.3 Nm, or 18–29 in-lbs.
4.1–6.6 Nm, or 36–58 in-lbs.
P-164000883—Rev 01
Quantity
1
1
2
Figure 2
for the bracket
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the OSHPD and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Eaton OSHPD

  • Page 1 Once the brackets are properly aligned, secure the brackets by tightening the screws to the following torque specifications. Door bracket M4 screws 2.0–3.3 Nm, or 18–29 in-lbs. Cabinet bracket M5 screws 4.1–6.6 Nm, or 36–58 in-lbs. Close and secure the UPS door. Eaton 93PM UPS (208–480V) Seismic (OSHPD) Door Retention Kit Install Instructions P-164000883—Rev 01...
  • Page 2 Cabinet Bracket NOTE Slots in cabinet bracket allow for adjustment in the depth direction. NOTE 1 The Seismic Door Retention kit is designed for use with all Eaton 93PM UPS (480V) and Eaton 93PM-L UPS (208V) models. NOTE 2 One kit is required per UPS door.
  • Page 3 NOTE The interior of the UPS door is identical for the Eaton 93PM-L UPS (208V) and Eaton 93PM UPS (480V) models. Eaton 93PM UPS (208–480V) Seismic (OSHPD) Door Retention Kit Install Instructions P-164000883—Rev 01...
  • Page 4 NOTE For clarity, the UPS door is not shown. Holes used to mount the cabinet bracket. Eaton 93PM (480V) UPS NOTE For clarity, the UPS door is not shown. Eaton 93PM UPS (208–480V) Seismic (OSHPD) Door Retention Kit Install Instructions P-164000883—Rev 01...
  • Page 5 NOTE For clarity, the UPS door is not shown. Cabinet bracket installed (bolts provided in kit). Eaton 93PM (480V) UPS NOTE For clarity, the UPS door is not shown. Eaton 93PM UPS (208–480V) Seismic (OSHPD) Door Retention Kit Install Instructions P-164000883—Rev 01...
  • Page 6 Please use the following e-mail address for comments, suggestions, or to report an error in these instructions: E-ESSDocumentation@eaton.com Eaton is a registered trademark of Eaton or its subsidiaries and affiliates. All other trademarks are property of their respective companies. ©Copyright 2019 Eaton, Raleigh, NC, USA. All rights reserved. No part of this document may be reproduced in any way without the express written approval of Eaton.
