IQ 35M DIN Rail Clip Installation Instructions
IQ35M-RMC
Product Diagram
When attaching the clips to the underside of the
IQ 35M meter, these stopping pegs must face in
towards the meter housing surface. Set pegs into the
available slots on the meter.
1
IQ35M-RMC IB02601012E February 2011 www.eaton.com
Additional Resources:
For a copy of the full installation guide for the IQ 35M
Meter Series, including all relevant safety information,
visit www.eaton.com.
Z205932-0A
