Petsafe Train-Well PBC-302 Manual
Petsafe Train-Well PBC-302 Manual

Petsafe Train-Well PBC-302 Manual

Bark control collar
Hide thumbs Also See for Train-Well PBC-302:

Advertisement

Quick Links

**Train-Well model is like the BC-103OM and sold through Drs. Foster & Smith (FS-103)
1. Set up collar:
2. Test Collar:
3. Observe Dog:
4. Remove Battery:
5. Discharge Unit:
PBC-302/Train-Well
Bark Control Collar™
Over Mold Version
Install battery. Align arrow on battery with triangle on unit. Using a coin or
straight edge screwdriver, turn battery to right to align arrow on battery
with lock on unit.
Slide Sensor Probe across a rough surface for at least 10 inches. The
Bark Control Collar should beep. If collar does not beep, try a rougher
surface.
Do not leave the dog alone the first few times he receives the Static
Correction.
Using a coin or straight edge screwdriver, turn the battery to the left to
align arrow on battery with triangle on unit. The battery can now be
removed.
After removing the battery, the unit retains some stored storage and may
activate 2 or 3 more times. To discharge, slide the Sensor Probe across a
hard surface several times until it stops beeping.
Collar Receiver RFA-354
1 |
P a g e

Advertisement

loading
Need help?

Need help?

Do you have a question about the Train-Well PBC-302 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Petsafe Train-Well PBC-302

  • Page 1 Collar Receiver RFA-354 PBC-302/Train-Well Bark Control Collar™ Over Mold Version **Train-Well model is like the BC-103OM and sold through Drs. Foster & Smith (FS-103) 1. Set up collar: Install battery. Align arrow on battery with triangle on unit. Using a coin or straight edge screwdriver, turn battery to right to align arrow on battery with lock on unit.
  • Page 2 Static Correction.  For use on dogs weighing 8 pounds on up PetSafe® Bark Control Collar™ Features Accessory kit: (RFA-225 through Distributor Channel) Includes 2 medium contact points, 2 washers and 1 battery...
  • Page 3 Collar Receiver RFA-354 Flashing red Static correction delivered (4 flashes) Contact Points: Comes with Medium Points installed Comes with No Correction Caps that cover the points to prevent the dog from receiving the correction (No longer packaged with system) Collar Maintenance: Check collar fit frequently.
  • Page 4 Collar Receiver RFA-354 PetSafe® Bark Control Collar™ Troubleshooting Tips Check battery for proper installation Test for working unit Unit does not activate: Lift up the battery contact located inside the unit and retest Replace battery Unit does not beep: Test for a working unit. If still does not beep during this test, try the same test on a rougher surface.
