Installation
14
6. Tighten by
hand until snug.
Then tighten
each supply
connection
another 2/3
turn with pliers. Do not bend, kink or
pinch water inlet hoses.
7. Turn on the water
and check for
leaks.

Connecting the drain

1. Verify the anti-
siphon disc is
in place.
2. Form a "U"
shape on the
end of the drain
hose with the
hose pointed
toward the
drain. Place
the formed end in a laundry tub or a
standpipe and secure the drain hose
with the cable tie (provided in the
enclosure package) to the standpipe,
inlet hose, laundry tub, etc. so the
hose does not pull out from the force
of the water.
Cable Tie
IMPORTANT
Check to ensure the power is off at a
circuit breaker/fuse box before plugging
the power cord into an outlet.
The standpipe inside diameter must be
1-1/4" (3.2 cm) minimum. There must be
an air gap around the drain hose in the
standpipe. A snug hose fit can cause a
siphoning action.
Completing the
installation
1. Plug the power cord into a grounded
Anti-Siphon
Disc
Improper connection of the equipment
grounding conductor can cause an
electrical shock that may result in
serious injury or death. Check with a
licensed electrician if you are in doubt
as to whether the appliance is properly
grounded.
See Electrical System Requirements and
Grounding Requirements sections of this
instruction for additional information.
2. Turn on the power at a circuit breaker/
3. Carefully slide the washer to its final
Insert Less
Than 8.5"
(21.5 cm)
4. Run the washer through a complete
5. If you have any questions during
6. Place these instructions in a location
A wiring diagram and technical data
sheet are located under the washer top
panel, on top of the detergent dispenser
housing.
NOTE
outlet.
WARNING
ELECTRICAL SHOCK HAZARD
fuse box.
position. Recheck for level and rock
corners for stability. See Leveling the
washer. Remove and discard door
tape.
cycle, checking for water leaks and
proper operation.
initial operation, please review the
Troubleshooting section before calling
for service.
near the washer for future reference.
NOTE
