- Page 1 XDMI Daughter Board Swap in Olympus Server...
- Page 2 2. Locate the 6 2-mm HEX (inbus) screws that hold the PCI Card in place. Note that the XDMI Card is secured from the rear side of the unit, not on top of the bracket. See the Olympus Server XDMI Card Diagram below.
- Page 3 Fitting the XDMI Daughter Board 1. Fit the other XDMI Daughter Board on top of the XDMI card, and secure it with the 4 screws. 2. Lower the XDMI Card back into the PCI slot in a straight motion. 3. Secure the XDMI Card with the 6 2-mm HEX screws using the supplied Allen key. 4.
- Page 4 Diagrams Olympus Server Bottom Panel Location of the four 4-mm Hex (inbus) screws that secure the server’s top and bottom sections.
- Page 5 Olympus Server rear side Location of the six 2-mm Hex (inbus) screws that secure the XDMI Card.
- Page 6 XDMI Card with Daughter Board Schematic of an XDMI Card, showing the XDMI PCI base board with a Daughter Board on top, showing the locations of the 4 screws that secure the Daughter Board to the XDMI base board. Please note that the analog Daughter Board requires different length screws than the digital Daughter Boards.
