Page 2
3. Unscrew the 6 screws on the backpanel that secure the XDMI card’s copper panel to the chassis and in the PCI slot. See the Olympus I/O XDMI Card Diagram below. 4. Lift the XDMI card out of the PCI slot in a sideways motion.
Page 3
Fitting the XDMI Daughter Board 1. Fit the other XDMI Daughter Board on top of the XDMI Card and secure it with the 4 screws. 2. Position the XDMI Card back into the PCI slot in a sideways motion. 3. Re-fit the 6 screws that secure the XDMI Card from the rear side of the I/O unit. 4.
Page 4
Diagrams Olympus I/O Bottom Panel Location of the six M3, 2-mm Hex (inbus) screws that secure the I/O’s bottom panel.
Page 5
Olympus I/O rear side Location of the 6 screws on the backpanel that secure the XDMI card in the PCI slot. Standing on its feet: Turned upside down:...
Page 6
XDMI Card with Daughter Board Schematic of an XDMI Card, showing the XDMI PCI base board with a Daughter Board on top, showing the locations of the 4 screws that secure the Daughter Board to the XDMI base board. Please note that the analog Daughter Board requires different length screws than the digital Daughter Boards.
