Features
• Control Distance: 30m
• Brightness and color temperature adjustable
• Switching 2 output mode via one button (Single
color / Dual white)
Color temperature
adjustable
Dim brightness
Support PUSH dimming
PUSH
Parameters
Remote
Operating Voltage:
3V(AAA*2PCS)
Standby power:
< 20 A
Transmit power：
6dBm
Control Signal:
2.4G Hz
Modulation Method:
GFSK
Controller
Input Voltage:
DC12-24V
Output Current:
12A/ Channel
Total Output
Max 12A
Output Power:
144-288W
Output Type:
Constant Voltage
2 in 1 LED Controller Kits (2.4GHz)
Model No.: FUT035SA+
Remote control
Control distance 30m
Smartphone App control
(2.4GHz gateway is needed)
Support third party voice control
(2.4GHz gateway is needed)
Control Signal:
Control Distance:
IP Rate:
Working Temp.:
EMC Standard (EMC):
Safety Standard（LVD）:
Radio Equipment（RED）:
Certi cation:
Warranty:
2.4GHz RF
30M
IP20
-10~40°C
ETSI EN 301 489-1 V2.2.3
ETSI EN 301 489-3 V2.1.1
EN 61347-1：2015+A1: 2021
EN 61347-2-11: 2001+A1:2019
ETSI EN 300 440 V2.2.1
CE, EMC, LVD, RED
5 Years
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Mi-Light MiBOXER FUT035SA+
Summary of Contents for Mi-Light MiBOXER FUT035SA+
- Page 1 2 in 1 LED Controller Kits (2.4GHz) Model No.: FUT035SA+ Features • Control Distance: 30m • Brightness and color temperature adjustable • Switching 2 output mode via one button (Single color / Dual white) Remote control Color temperature adjustable Control distance 30m Smartphone App control Dim brightness (2.4GHz gateway is needed)
- Page 2 Size Φ70mm 24mm 74.5mm Function Turn on lights / Link / Unlink Color temperature Brightness Turn off lights Touch ring: brightness, saturation, color temperature use together. (It turns to adjust brightness by default if remote is not operated for 3 seconds) Remote Instruction Adjust color temperature Short press CCT key once, then touch...
-
Page 3: Connection Diagram
Install The Battery For Remote Note: 2*AAA Battery need to buy seperately 1. Open battery cover 2. Install battery correctly and behind remote. close battery cover. Connection Diagram Input: DC12V ~ 24V V- V+ Single Color Mode PUSH switch V- V+ Dual White Mode PUSH switch Set up output mode... - Page 4 Linking Code / Unlinking Code Instructions Attention: No need to match code since its already matched code in factory setting Linking Code Instructions Power Controller Link/Unlink Power Controller button Switch off light, after Short press " ON " button Lights blink 3 times 10 seconds then 3 times within 3 seconds slowly means linking...
- Page 5 Auto transmitting & Synchronization (only for remote control) Remote signal auto transmitting One light can transmit the signals from the remote control to another light within 30m, as long as there is a light within 30m, the remote control distance can be limitless.
