1. Features
Product adopt the widely used 2.4GHz wireless technology with the features of low power
consumption, long signal transmitting and strong anti-interference, etc. This product has
auto-transmitting and auto-synchronizing function. Widely used on the controlling of hotel
lighting and home lighting.
RGB LED
16 Millions of
colors to choose
Mix Red, Green and Blue light
to adjust color temperature
Dim brightness /
Saturation
2.4G RF wireless
transmission technology
RGBW LED
16 Millions of
colors to choose
Dim brightness /
Saturation / White mode
2.4G RF wireless
transmission technology
Signal transmitting &
Modes synchronization
Subordinate New Brand
Remote control
Control distance 30m
Smartphone app control
(2.4GHz gateway is needed)
Support third party voice control
(2.4GHz gateway is needed)
Signal transmitting &
Modes synchronization
Remote control
Control distance 30m
Smartphone app control
(2.4GHz gateway is needed)
Support third party voice control
(2.4GHz gateway is needed)
Advertisement
Related Manuals for Mi-Light MiBOXER FUT038S
Summary of Contents for Mi-Light MiBOXER FUT038S
- Page 1 Subordinate New Brand 1. Features Product adopt the widely used 2.4GHz wireless technology with the features of low power consumption, long signal transmitting and strong anti-interference, etc. This product has auto-transmitting and auto-synchronizing function. Widely used on the controlling of hotel lighting and home lighting.
- Page 2 2. Linking Code / Unlinking Code Instructions Linking Code Instructions Power Light Light Power Link / Unlink button Switch off light, after Short press " I " button Lights blink 3 times 10 seconds then 3 times within 3 seconds slowly means linking switch on again.
- Page 3 3. The mode of “Do Not Disturb” It can be activated or turned off via remote control Turn on “Do not disturb” (wide using in the area which have power failure frequently to save energy) Press “OFF” button three times within three seconds and press “ON” button three times, Activated successfully once led light flashes four times quickly.
- Page 4 5. Signal transmitting One light can transmit the signals from the remote control to another light within 30m, as long as there is a light within 30m, the remote control distance can be limitless. 6. Modes synchronization Different lights can work synchronously when they are started at different times, light by the same remote, under same dynamic mode and within 30m distance.
- Page 5 Dynamic mode table 1 (default) Number Dynamic Mode Brightness / Saturation / Speed Mardi Gras Automatic color change Gemstone Adjustable Twilight American Fat Tuesday Party Slow Color Splash Dynamic mode table 2 (need to switch manually) Number Dynamic Mode Brightness / Saturation / Speed Colors gradual change White light Gradual change RGB gradual change...
- Page 6 8. Scan QR code to watch video instruction Smartphone app control Third party voice control (WL-Box1 video) 9. Attention 1. Please check whether the voltage of the power supply is in accordance with the light, and please check the connection of both the cathode and anode, otherwise the light will be broken. 2.
