- Page 1 Subordinate New Brand DMX512 Master ( Color Temperature )
- Page 2 DMX512 master ). 5. Bu�on with sound and LED indica�ng lamp. 6. This products can be controlled by Mi-Light/Miboxer RF remote, and smartphone ( need WL-Box1 WiFi gateway ). 7. This product can be used as RF remote to control MiBoxer 2.4GHz lamps.
- Page 3 3. Connec�on Diagram Input: AC100 ~ 240V 50/60Hz DMX512 master dimming channel comparison table: Zone 1 Zone 2 Zone 3 Zone 4 Color Temperature LED Lamp Power input DC12V/24V D2-CX Decoder Color Temperature LED Lamp Power input DC12V/24V D2-CX Decoder Color Temperature LED Lamp Power input...
- Page 4 4. Func�on of keys Remark: When touching the bu�on, LED indica�ng lamp will flash once with different sound (Touch slider with no sound). CCT Slider Dimming Slider 60S Delay OFF Master OFF Master ON Zone ON Zone OFF Touch the slider to change color temperature. Touch dimming slider to change the brightness from 1~100%.
- Page 5 1). Linking Code Instruc�ons Link / Unlink Power Light Power Light bu�on Power off and power on Short press " I " bu�on Lights blink 3 �mes again a�er 10 seconds. 3 �mes within 3 seconds. slowly means linking is done successfully. Linking failed if light is not blinking slowly, Please follow above steps again.
- Page 6 6. DMX512 master used as RF receiver Instruc�on DMX512 master can receive RF remote signal, and transform it to DMX control signal to control the lamps. Note: When RF remote control DMX512 master, RF remote need to link the master; a�er linking, RF remote 1-4 channel correspond to DMX512 master 1-4 channels.
- Page 7 7. Installa�on / Dismantlement Install the bo�om case into the Fix the controller base on the wall; Above are the standard bo�om case with screw. bo�om cases. Dismantle Clicks into the upper side of Plug into the below bayonet glass panel on the controller with a screwdriver, and upwarp screwdriver, then you can base, then press the lower side...
