Wharfedale Pro TOURUS+ Active Series Quick Start Manual

Congratulations on the purchase of your TOURUS+ series loudspeaker. We take great pride in engineering and building every Wharfedale Pro product so thank
you for entrusting us with your audio. From the time Gilbert Briggs built his first Wharfedale loudspeaker in 1932, to the present day, we have maintained
the same standard of quality in components, workmanship and performance.
For safety reasons and to get the most from your new loudspeaker please take the time to read this guide completely.
Specifications
Model Name
System Type
Configuration
Frequency Response (+/-3 dB)
Frequency Range (-10 dB)
Calculated Maximum SPL @1 m
Low Frequency Transducer
Size
Voice Coil Size
High Frequency Transducer
HF Driver Type
Coil Size
Exit Size
Diaphragm Material
Waveguide Type
Nominal Coverage (H x V)
Special Features
Preset
Location Mode
Driver Brand
Amplifiers
Amplifier Design
Power Rating
Thermal Protection
Low Line Voltage Shut Down
Driver Protection
DC and Short Protection, Clip Limiter
LED Indicators
Input Sensitivity
Maximum Input Level
Input Impedance
AC Power Supply Details
Digital Connectors
Input
Link
AC Power
Rigging & Hardware
Optional Accessories
Handle
Pole Mount
Enclosure
Cabinet Type
Enclosure Material & Finish
Colour Options
Grille Material & Finish
Dimensions - Unpacked
Height
Width Front
Width Rear
Depth
Dimensions - Packed
Height
Width
Depth
Weight
Net Weight
Gross Weight
IAG House, 13/14 Glebe Road, Huntingdon, Cambridgeshire, PE29 7DL, UK
TOURUS+ Active Series
Quick Start Guide
TOURUS+A8
8" Active
68 Hz - 20 kHz
60 Hz - 20 kHz
124 dB
203.2 mm / 8"
50.8 mm / 2"
33.8 mm / 1.33"
560 W Peak (500 W LF + 640 W Peak (560 W LF +
60 W HF), 280 W Continuous 80 W HF), 320 W Continuous
(250 W LF + 30 W HF) (280 W LF + 40 W HF)
Limiter: Red, Signal: Green, Power/Active: White, Find Function: Blue
1 On Top
459.8 mm / 18.1"
280 mm / 11.0"
163.8 mm / 6.4"
269 mm / 10.6"
531 mm / 20.9"
323 mm / 12.7"
313 mm / 12.3"
10.3 Kg / 22.7 lbs
12.1 Kg / 26.7 lbs
TOURUS+A10 TOURUS+A12
10" Active 12" Active
Two-Way Bi-Amped
63 Hz - 20 kHz 58 Hz - 20 kHz
55 Hz - 20 kHz 50 Hz - 20 kHz
125 dB
254.0 mm / 10" 304.8 mm / 12"
63.5 mm / 2.5"
Compression Driver
35 mm / 1.37"
Titanium
Constant Directivity
90° x 60°
Bluetooth, Display, FIR, editable 3 band EQ
NORMAL, LIVE, DJ, SPEECH
Stand or Monitor
Wharfedale Pro
Class D
900 W Peak (800 W LF +
100 W HF), 450 W Continuous
(400 W LF + 50 W HF)
Amplifier Shut Down. Auto Reset
60% Nominal Line Voltage
Independent LF/ HF RMS and Peak Limiters
Yes
+4 dBu
+18 dBu
Balanced:10 KΩ
220~240 V AC / 100~120 V AC 50/60 Hz
Balanced Socket XLR
Balanced Pin XLR
AC Input: VDE
5 x M8
-WPB-T -Heavy-duty transport soft cover
1 On Top, 1 On Side
Dual Angle (0° / -3°) 35 mm
Trapezoid
Polypropylene
Black Paint
Powder Coated Steel
527.9 mm / 20.8" 609.1 mm / 24.0"
320 mm / 12.6" 359.7 mm / 14.2"
178.9 mm / 7.0" 200.6 mm / 7.9"
299.5 mm / 11.8" 346 mm / 13.6"
582 mm / 22.9" 680 mm / 26.8"
367 mm / 14.4" 480 mm / 18.9"
342 mm / 13.5" 420 mm / 16.5"
12.6 Kg / 27.8 lbs 17.6 Kg / 38.8 lbs
14.8 Kg / 32.6 lbs 21.45 Kg / 47.3 lbs
TOURUS+A15
15" Active
50 Hz - 20 kHz
42 Hz - 20 kHz
128 dB 130 dB
381 mm / 15"
76.2 mm / 3"
43.9 mm / 1.73"
1000 W Peak (900 W LF +
100 W HF), 500 W Continuous
(450 W LF + 50 W HF)
695.7 mm / 27.4"
417 mm / 16.4"
222.6 mm / 8.8"
368.5 mm / 14.5"
777 mm / 30.6"
503 mm / 19.8"
441 mm / 17.4"
19.1 Kg / 42.1 lbs
23.14 Kg / 51.0 lbs
