Wharfedale Pro TOURUS+ Series Quick Start Manual

Congratulations on the purchase of your TOURUS+ series loudspeaker. We take great pride in engineering and building every Wharfedale Pro product so thank
you for entrusting us with your audio. From the time Gilbert Briggs built his first Wharfedale loudspeaker in 1932, to the present day, we have maintained
the same standard of quality in components, workmanship and performance.
For safety reasons and to get the most from your new loudspeaker please take the time to read this guide completely.
To get the most from your system and to protect it from potential damage, always use with Factory DSP Presets.
Preset libraries are available for many of our DSP equipped amps and processors.
These presets can be downloaded from https://www.wharfedalepro.com/download/wharfedale-pro-preset-library/
Specifications
Model Name
System Type
Configuration
Frequency Response (+/-3 dB)
Frequency Range (-10 dB)
Sensitivity 2.83 V/1 m
Calculated Maximum SPL @1 m
System Rated Impedance
Low Frequency Transducer
Size
Voice Coil Size
High Frequency Transducer
HF Driver Type
Coil Size
Exit Size
Diaphragm Material
Waveguide Type
Nominal Coverage (H x V)
Driver Brand
Power
System Continuous Power
System Programme Power
System Peak Power
Crossover frequency
Recommended HPF = BW 18 dB/oct.
Input Connector
Rigging & Hardware
Optional Accessories
Handle
Pole Mount
Enclosure
Cabinet Type
Enclosure Material & Finish
Colour Options
Grille Material & Finish
Monitor Angle (degrees)
Dimensions - Unpacked
Height
Width Front
Width Rear
Depth
Dimensions - Packed
Height
Width
Depth
Weight
Net Weight
Gross Weight
IAG House, 13/14 Glebe Road, Huntingdon, Cambridgeshire, PE29 7DL, UK
TOURUS+ Passive Series
Quick Start Guide
TOURUS+8 TOURUS+10
8" Passive 10" Passive
68 Hz - 20 kHz 63 Hz - 20 kHz
60 Hz – 20 kHz 55 Hz – 20 kHz
95 dB
124 dB
203.2 mm / 8" 254.0 mm / 10"
50.8 mm / 2" 63.5 mm / 2.5"
33.8 mm / 1.33"
180 W
360 W
720 W
50 Hz
1 On Top
459.8 mm / 18.1" 527.9 mm / 20.8"
280 mm / 11.0" 320 mm / 12.6"
163.8 mm / 6.4" 178.9 mm / 7.0"
269 mm / 10.6" 299.5 mm / 11.8"
531 mm / 20.9" 582 mm / 22.9"
323 mm / 12.7" 367 mm / 14.4"
313 mm / 12.3" 342 mm / 13.5"
9.8 Kg / 21.6 lbs 12.1 Kg / 26.7 lbs
11.6 Kg / 25.6 lbs 14.3 Kg / 31.5 lbs
TOURUS+12
12" Passive
Two-Way
58 Hz - 20 kHz
50 Hz – 20 kHz
96 dB 97 dB
125 dB 128 dB
8 Ω
304.8 mm / 12"
Compression Driver
35 mm / 1.37"
Titanium
Constant Directivity
90° x 60°
Wharfedale Pro
200 W 300 W
400 W 600 W
800 W 1200 W
2 KHz
45 Hz 40 Hz
2 x speakON
5 x M8
-WPB-T -Heavy-duty transport soft cover
1 On Top, 1 On Side
Dual Angle (0° / -3°) 35 mm
Trapezoid
Polypropylene
Black, White on request
Powder Coated Steel
45
609.1 mm / 24.0"
359.7 mm / 14.2"
200.6 mm / 7.9"
346 mm / 13.6"
680 mm / 26.8"
480 mm / 18.9"
420 mm / 16.5"
16.6 Kg / 36.6 lbs
20.5 Kg / 45.2 lbs
TOURUS+15
15" Passive
50 Hz - 20 kHz
42 Hz – 20 kHz
98 dB
130 dB
381 mm / 15"
76.2 mm / 3"
43.9 mm / 1.73"
350 W
700 W
1400 W
1.8 KHz
35 Hz
695.7 mm / 27.4"
417 mm / 16.4"
222.6 mm / 8.8"
368.5 mm / 14.5"
777 mm / 30.6"
503 mm / 19.8"
441 mm / 17.4"
18.4 Kg / 40.6 lbs
22.8 Kg / 50.3 lbs
WWW.WHARFEDALEPRO.COM
