- Page 1 Operating- and assembly manual Block divider SSVD progressive...
-
Page 2: Table Of Contents
All information subject to technical changes. Rev. Type of change Date / Author Date / Release First edition 29.01.2025 / HB 29.01.2025 / RJ Lubmann GmbH | Kleiner Johannes 21 | 91257 Pegnitz | Germany Phone: +49 9241 80898700 | E-Mail: info@lubmann-gmbh.de | Homepage: www.lubmann-gmbh.de... -
Page 3: Imprint
E-Mail: info@lubmann-gmbh.de Website: www.lubmann-gmbh.de Training courses In order to provide a maximum of safety and economic viability, Lubmann GmbH carries out detailed training courses. It is recommended that the training courses are attended. For more information, please contact Lubmann GmbH. -
Page 4: Explanation Of Symbols
(e.g., piston wear, piston jamming, plugins, embrittled sealings). Lubmann does not assume liability on damages caused by lubricants, even if these lubricants have been tested and released by laboratory tests, as damages caused by lubricants (e.g., by expired or improper stored lubricants, batch variations etc.) can not be retraced to their root cause in retrospect. - Page 5 Original spare parts and accessories authorized by the manufacturer serve for higher safety. The use of other parts may rule out liability for the consequences of such use. For components, which are retrofitted by the operator, Lubmann does not assume liability nor claims for compensation.
- Page 6 The spray jet can cause water to penetrate the monitoring system via the seals. In this case, Lubmann GmbH does not assume any warranty / guarantee! Lubricant The system has been designed for commercially available multi-purpose greases of NLGI class 2 for operation in summer and winter.
-
Page 7: Delivery, Returns And Storage
Delivery, Returns and Storage Delivery The progressive dividers of the SSVD series are packaged according to standard commercial packaging in accordance with the regulations of the recipient country and wishes of the customer. There are no restrictions for land, sea or air transport. -
Page 8: Shutdown And Disposal
Operating instructions for components installed during assembly of the central lubrication system ▪ ▪ Release regulations and regulations in the company Lubmann GmbH | Kleiner Johannes 21 | 91257 Pegnitz | Germany Phone: +49 9241 80898700 | E-Mail: info@lubmann-gmbh.de | Homepage: www.lubmann-gmbh.de... -
Page 9: Technical Data
[kg] SSVD-6 15010359 SSVD-8 15010360 SSVD-10 15010361 SSVD-12 15010362 SSVD-14 15010363 SSVD-16 15010364 SSVD-18 15010365 SSVD-20 15010366 SSVD-22 15010367 Lubmann GmbH | Kleiner Johannes 21 | 91257 Pegnitz | Germany Phone: +49 9241 80898700 | E-Mail: info@lubmann-gmbh.de | Homepage: www.lubmann-gmbh.de... -
Page 10: Dosing Screw
15010378 10,9 0,008 SSVD-1,80 15010379 0,007 Install the dosing screws with a tightening torque of 19 ± 1 Nm. Lubmann GmbH | Kleiner Johannes 21 | 91257 Pegnitz | Germany Phone: +49 9241 80898700 | E-Mail: info@lubmann-gmbh.de | Homepage: www.lubmann-gmbh.de... -
Page 11: Components
Screw plug with sealing ring Outlet screw coupling Dosing screw Divider monitoring sensor with sealing ring Identification and assignment of the outlets: Lubmann GmbH | Kleiner Johannes 21 | 91257 Pegnitz | Germany Phone: +49 9241 80898700 | E-Mail: info@lubmann-gmbh.de | Homepage: www.lubmann-gmbh.de... -
Page 12: Inlet Screw Couplings
Cutting ring-single edge-SRE- 9900209 D6LL-ST-ZnNi Pos. 1 Cutting ring-single edge-SRE- 9900211 D8LL-ST-ZnNi Union nut-ÜM-D6LL-ST-ZiNi 9900199 Pos. 2 Union nut-ÜM-D8LL-ST-ZiNi 9900202 Lubmann GmbH | Kleiner Johannes 21 | 91257 Pegnitz | Germany Phone: +49 9241 80898700 | E-Mail: info@lubmann-gmbh.de | Homepage: www.lubmann-gmbh.de... -
Page 13: Outlet Screw Couplings
Install the screw plug with a tightening torque of 19 ± 1 Nm. Part nr. Screw plug-DIN908-M10x1-ST- Pos. 1 3010401940 ZnNi Sealing ring-DR-DIN7603 A- Pos. 2 3010401930 10x14x1-Cu Lubmann GmbH | Kleiner Johannes 21 | 91257 Pegnitz | Germany Phone: +49 9241 80898700 | E-Mail: info@lubmann-gmbh.de | Homepage: www.lubmann-gmbh.de... -
Page 14: Divider Accessories
The connection cable between the monitoring sensor and the lubrication pump is NOT included in the scope of delivery! For information about suitable cables, check “Divider monitoring – Cables”. Lubmann GmbH | Kleiner Johannes 21 | 91257 Pegnitz | Germany Phone: +49 9241 80898700 | E-Mail: info@lubmann-gmbh.de | Homepage: www.lubmann-gmbh.de... -
Page 15: Divider Monitoring - Cables
RD24 Serie 693 (DIN EN 175 301-803-A) Plug of divider Cable kit-divider monitoring-with BD- Cable kit-divider monitoring-with Plug HSC-Plug Lubmann GmbH | Kleiner Johannes 21 | 91257 Pegnitz | Germany Phone: +49 9241 80898700 | E-Mail: info@lubmann-gmbh.de | Homepage: www.lubmann-gmbh.de... -
Page 16: Mounting Brackets
ST-ZnNi Swivel Please check the hoses between the banjo and the pump before starting refilling grease from the banjo! Lubmann GmbH | Kleiner Johannes 21 | 91257 Pegnitz | Germany Phone: +49 9241 80898700 | E-Mail: info@lubmann-gmbh.de | Homepage: www.lubmann-gmbh.de... -
Page 17: Working Principle
For divider with sealing screw and sealing steel ball, none of the outlets 1# and 2# can be blocked by a blind plug. on ret rn valve ealing ball ealing scre Lubmann GmbH | Kleiner Johannes 21 | 91257 Pegnitz | Germany Phone: +49 9241 80898700 | E-Mail: info@lubmann-gmbh.de | Homepage: www.lubmann-gmbh.de... - Page 18 1#, 4# and 6# need be blocked with a blind plug and remove the sealing screw and sealing steel ball. ealing scre ith sealing ring on ret rn valve ith sealing cone Lubmann GmbH | Kleiner Johannes 21 | 91257 Pegnitz | Germany Phone: +49 9241 80898700 | E-Mail: info@lubmann-gmbh.de | Homepage: www.lubmann-gmbh.de...
-
Page 19: Part Numbers Of Components For Combination
Install the screw plug with a tightening torque of 19 ± 1 Nm. Install the sealing screw for divider outlet separation with a tightening torque of 2,5 ± 0,2 Lubmann GmbH | Kleiner Johannes 21 | 91257 Pegnitz | Germany Phone: +49 9241 80898700 | E-Mail: info@lubmann-gmbh.de | Homepage: www.lubmann-gmbh.de... -
Page 20: Commissioning / Assembly
Make sure that all lubrication lines are installed correctly. During operation, ensure that there is sufficient lubricant in the lubrication pump. Please note the applicable documents! Lubmann GmbH | Kleiner Johannes 21 | 91257 Pegnitz | Germany Phone: +49 9241 80898700 | E-Mail: info@lubmann-gmbh.de | Homepage: www.lubmann-gmbh.de... -
Page 21: Troubleshooting
To check, the grease lubrication pump must be in operation and several lubrication cycles must have run so that the main divider and any secondary dividers are sufficiently supplied with lubricant. Lubmann GmbH | Kleiner Johannes 21 | 91257 Pegnitz | Germany Phone: +49 9241 80898700 | E-Mail: info@lubmann-gmbh.de | Homepage: www.lubmann-gmbh.de... -
Page 22: Order Key
13 Order key Lubmann GmbH | Kleiner Johannes 21 | 91257 Pegnitz | Germany Phone: +49 9241 80898700 | E-Mail: info@lubmann-gmbh.de | Homepage: www.lubmann-gmbh.de...
