- Page 1 PRODUCT MANUAL ALP01 Single Point Lubricator...
-
Page 2: Table Of Contents
ALP01 Pump Index Overview Grease Filling Grease Refilling Period Test and Time Setting System Debugging Installation Dimension Accessories 11-12... -
Page 3: Overview
ALP01 Pump Overview Lubmann progressive - single point lubricator - ALP01 has been widely used in industries like wind power, mining, metallurgy, machine tools, textiles, food, etc. as one of the best price - performance rate choice. Our Lubmann single point lubricator lubricates all lube points as required through the lubricator directly like in Dia. - Page 4 ALP01 Pump Overview The Lubmann single point lubricator - ALP01 is electrically operated by a replaceable 3.6V Lithium battery cell (around 28 hrs continues running time) with max. 40 bar operation pressure with NLGI 2 grease. The ALP01 series lubricator differs in various reservoir size 120ml, 250ml and 500ml. No matter By using a magnet cap on the top cover of the lubricator in Dia.
-
Page 5: Grease Filling
ALP01 Pump Grease Refilling 1. Take off the magnet cap (Dia. 5.1-1). 2. Connect the manual/electrical grease gun with the greasing nipple under the magnet cap (Dia. 5.1-2). 3. Inject the grease into the reservoir smoothly till the “MAX. Grease Level”* (Dia. 5.1-2). -
Page 6: Grease Refilling Period
ALP01 Pump Grease Refilling Period Preset of the Operation Period (Theoretical Grease Refilling Period ) The preset operation period equals the theoretical grease refilling period, which can be set on the single point lubricator ALP01. Based on the reservoir size and preset operation period which can be adjusted on the lubricator in Dia. -
Page 7: Test And Time Setting
Test and Time Setting Control Panel of ALP01 The control panel area of ALP01 single point lubricator is built up by the LED indicator area ( and ② in Dia. 7.1) and the EM inductive area (③ and ④ in Dia. 7.1). - Page 8 ALP01 Pump Test and Time Setting Operation Period Adjustment To change the preset operation period: 1. Use the magnetic cap vertically close to the Setup EM induction point to active the setting mode till the preset/default operation period LED turns on, then move the cap away.
-
Page 9: System Debugging
ALP01 Pump System Debugging No Motor pulse Warning During the running time of the lubricator, the controller will detect the motor pulse. If less than 2 motor pulse has been detected by the controller in 45 seconds, the lubricator will send an error code on the LED indicator area like in Dia. -
Page 10: Installation Dimension
ALP01 Pump Installation Dimension Level MAx. Level MIn. ALP01 Reservoir Size 120 ml 250 ml 78,5 R 3/8 500 ml * R 3/8 is standard connecting thread, for other connection thread requirement please contact us. -
Page 11: Accessories
ALP01 500ml without battery* 2010110190 Dia. 11.1 Single Point Lubricator with/without Battery Item Specification Part No. Battery ALP01 Battery Set with fixing parts 2010120530 Dia. 11.2 Single Point Lubricator Battery Item Specification Part No. Magnet Cap ALP01 Magnet Cap 3020101500 Dia. - Page 12 ALP01 Pump Accessories Item Type Specification Part No. Elbow High Pressure Quick Coupling (xxx bar) 2010120420 G3/8 - D8 Elbow Double Cone Drive Coupling G3/8 - D8 2010120400 Couplings for Bracket Straight High Pressure Quick Coupling (xxx bar) 2010120410 G3/8 - D8...
