MOTORHOME EXTERIOR

Motorhome Dimensions and Capacities
Your Motor Home is larger than your standard van or automobile, so please be careful when
entering underpasses, garages, parkades, etc.
DIMENSION (approximate)
LENGTH BUMPER TO
BUMPER
HEIGHT WITH ROOF
AIR CONDITIONER
WIDTH WITHOUT SIDE
MIRRORS
WIDTH WITH MIRRORS
BED AREA RD
(APPROXIMATE)
BED AREA TS & TD
(APPROXIMATE)
CAPACITIES (approximate)
FUEL
FRESH WATER
GREY WATER
(SINKS AND SHOWER)
BLACK WATER
(TOILET)
PROPANE( LPG)
WATER HEATER
NOTE: The height of your Motorhome may vary depending upon the tire pressure, air ride
pressure and optional components mounted on the roof. The width of the motor home will very
with the positions of the outside mirrors. All measurements and capacities are approximate. There
are many variables in the construction of the vehicle for measurements to be absolute
TIRE/ AIR RIDE PRESSURE:
Tire pressures as recommended by Ford Motor Company. Tire Size LT 245 / 75 R16E
FRONT TIRES: 55 PSI / 380 kPa
REAR TIRES: 80 PSI / 550 kPa
REAR AIR RIDES: 50 PSI this is a recommended setting for general use.
The Air rides are used to assist the springs and shocks of the vehicle. Your inflation rates will
very depending on the loading of the vehicle. It is recommended that you inflate the air rides
to a pressure that keeps the vehicle ride level.
20' 4" 620 cm
9' 0" 2874 cm
7' 3" 221 cm
7' 11" 241 cm
L- 81" 205 cm
W- 54" 137 cm
L – 74" 188 cm
W – 81" 206 cm
35 US gal 132 L
24 US gal 91 L
26 US gal 97 L
12 gal 45 L
8.1 gal 31 L
(At 80 %) (At 80 %)
6 gal 23 L
