- Page 1 XKM01 CaseUp Foldable Keyboard and Mouse Combo with Laptop Stand User Manual www.protoarc.com support@protoarc.com (+1) 866-287-6188 Monday-Friday: 10am-1pm , 2pm -7pm (Eastern Time) *Closed during Holidays support-uk@protoarc.com...
-
Page 2: Packing List
Packing List Foldable Keyboard* 1 Mouse* 1 EVA Carrying Case* 1 User Manual User Foldable Type-C Manual* 1 Laptop Stand* 1 Charging Cable* 1 - 1 -... -
Page 3: Keyboard Features
Keyboard Features Multifunction Type-C Button Charging Port 2.4G Caps Lock Indicator Indicator Indicator Indicator Charging/ Charging: Red Light Low Battery Fully Charged: Green Light Indicator Low Battery: Red Light Flashing 2.4G Bluetooth Bluetooth Connection Connection 1 Connection 2 - 2 -... -
Page 4: Mouse Features
Mouse Features Left Button Right Button Scroll Wheel Button DPI Switch Button Charging/Low Battery Indicator Type-C Charging Port Charging: Red Light BT1 Indicator Fully Charged: Green Light Channel Switch Button Low Battery: Red Light Flashing Power Switch BT2 Indicator USB Receiver 2.4G Indicator - 3 -... - Page 5 2.4G Connection Unfold the keyboard automatically turns on. Turn the power switch to ON. Press the channel switch Single press channel button, button until the light is on, and the indicator light flashes the mouse enters into 2.4G USB slowly, enter into 2.4G USB channel.
- Page 6 Keyboard Bluetooth Connection Unfold the keyboard automatically turns on. Single press channel button, and the indicator light flashes once to enter the Bluetooth channel. Long press this Bluetooth channel button for 3–5 seconds again, the indicator light flashes quickly, then the keyboard enters into the Bluetooth pairing mode.
- Page 7 Mouse Bluetooth Connection Turn the power switch to ON. Press the channel switch button until the indicator light is on, the mouse enters the Bluetooth channel. Long press the channel switch button for 3-5 seconds again, until light flashes quickly, then the mouse enters the Bluetooth pairing mode.
- Page 8 Mode Switch Method Mouse After are connected, short press Mode Switch Button on the bottom of the mouse, easily switch between multiple devices. Keyboard After are connected, short press the channel key on the keyboard, easily switch between multiple devices. - 7 -...
- Page 9 Laptop Stand User Guide Take out the stand. Extend the stand into required width. Pull up the spring-loaded support Place your laptop on feet on both sides, adjust to a the stand. comfortable angle, and lock in place. Pull up the anti slip small baffle. (Note: 6 adjustable angles, from 10°...
-
Page 10: Charging Guide
Charging Guide 1. When the battery is low, the low battery indicator light on the keyboard or mouse will rapidly flash to indicate low power. 2. Insert the Type-C port into the mouse or keyboard and the USB-A port into the computer to charge, the red light stays on while charging. 3. - Page 11 Multimedia Function Keys Keys Windows OS Android OS Mac OS Light - Light - Light - Light - Light + Light + Light + Light + Window Switch Window Switch Window Switch Application Application Open latest Open latest Switch Switch Window Window Display Desktop...
-
Page 12: Product Parameters
Product Parameters Keyboard Parameters Battery Capacity 210 mAh Working Current ≤ 3.5 mA Sleep Current 31 uA Charging Current 190 mA (±20mA) Standby Current ≤ 0.3 mA Input 250mA Standby Time ≥ 150 Days Charging Time < 2 Hours Wake Up Way Press any key Weight 297 g... - Page 13 Product Parameters Laptop Stand Specifications Material Aluminum alloy Compatible Laptop Size 13-17.3 inch Product Dimensions (Folded) 256 * 55 * 8mm Adjustment Angles Range 10°/ 20°/ 25°/ 30°/ 35°/ 40° 2.4G Transmission Parameters Transmission Distance Working Voltage 3.7V Working Current <5mA Polling Rate 250Hz...
-
Page 14: Sleep Mode
Tips 1. If Bluetooth connection is not working properly, fold the keyboard to turn off its power, then unfold the keyboard again to restart the device's Bluetooth and attempt to reconnect. Or delete the extra Bluetooth option name in the Bluetooth connection list of the device and reconnect. -
Page 15: Safety Warning
Safety Warning IMPORTANT: To reduce risk of fire, electric shock, or injury, follow these safety instructions. Charging Safely: Use only the provided cable. Charge in a well-ven- tilated, dry area away from inflammable materials. Battery Handling: Do not attempt to replace the item’s lithium battery. -
Page 16: Eu Declaration Of Conformity
EU Declaration of Conformity Declared Object: Foldable Keyboard and Mouse Combo with Laptop Stand Model: XKM01 CaseUp Rating: 3.7V 10mA Input: 250mA Place of Production: Made in China Manufacturer: Shenzhen Hangshi Electronic Technology Co., LTD Email: chen.zhao@bow.cn Address: Floor 2, Building A1, Zone G, Democratic West Industrial Zone, Democratic Community, Shajing Street, Bao'an District, Shenzhen City, Guangdong Province, China, 518104 European...
