  • Page 1 RPP1820Li20 OPP1820...

  • Page 2: Intended Use

    ■ Do not abuse the cord. Never use the cord for IMPORTANT! carrying, pulling or unplugging the power tool. Keep It is essential that you read the instructions in this manual cord away from heat, oil, sharp edges or moving before assembling, operating, and maintaining the parts.

  • Page 3: Pruner Safety Warnings

    ■ Store idle power tools out of the reach of children ■ Do not modify the product in any way or use parts and do not allow persons unfamiliar with the power and accessories that are not recommended by the tool or these instructions to operate the power tool.

  • Page 4: Operation

    ■ Pruned branches do not always fall cleanly to the ground. one, available from an authorised RYOBI service They are easily caught and deflected by other foliage. centre. The part number is available in the product Ensure that a safety zone at least twice the length of specifications table in this manual.

  • Page 5: Transportation And Storage

    (one month or longer), be sure that the chain is lightly For damaged parts Before each use lubricated to prevent rust. Use only RYOBI bar and chain lubricant, which is available at your RYOBI authorised For loose fasteners Before each use service centre.

  • Page 6: Symbols In This Manual

    Moving direction of the chain Remove the battery pack before starting any work on the product. Pull: Quick release tab Regulatory Compliance Mark (RCM). The product meets applicable regulatory requirements. Waste electrical products should not be disposed of with household waste. Please recycle where facilities exist.
  • Page 7 Chain lubricant cap Chain Bar bolt Guide bar Ribbed bumper Sprocket cover Chain tensioning screw Extension pole Shaft coupling Harness hanger Front hand grip Trigger release On/off trigger Harness Blade cover Operator’s manual RPP1820Li20 Battery pack Charger Lubricant Know your product...
  • Page 8 Always wear safety goggles or safety Install the shaft to the extension pole Install the extension pole to the pruner glasses with side shields when through the shaft coupling. Tighten the attachment through the shaft coupling. operating the product. Wear non-slip, shaft coupling to secure the extension Tighten the shaft coupling to secure the heavy-duty protective gloves.
  • Page 9 Attach the harness. Loosen and remove the chain lubricant Add bar and chain lubricant in the bar cap. lubricant tank for automatic bar and chain lubrication. NOTE: Use bar and chain lubricant only. Other lubricants will not stick to the chain properly and will result in damage to the chain and bar.
  • Page 10 Operating the Adjusting the p.11 p.13 chain tension product 3-4 mm Replacing the p.14 chain Cleaning the Storing the p.16 p.17 product product...

  • Page 11: Operating The Product

    OPERATING THE PRODUCT WARNING: Always use two hands to operate the product. Hold the product with the right hand on the rear handle and the left hand on the front handle. 1. Install the shaft to the extension pole through the shaft coupling. Tighten the shaft coupling to secure the extension pole.
  • Page 12 NOTE: Make a shallow first cut (1/4 of limb diameter) on the underside of the limb close to the main limb or trunk. Then, make a second cut from the top side of the limb outboard from the first cut. Lastly, make a final cut close to trunk.

  • Page 13: Adjusting The Chain Tension

    3-4 mm ADJUSTING THE CHAIN TENSION 1. Remove the battery pack. 2. Using the hex key, loosen the bar bolt of the sprocket cover. 3. Adjust the chain tension until the gap between the drive teeth and guide bar is between 3 and 4 mm. To increase the chain tension, turn the chain tensioning screw clockwise.

  • Page 14: Replacing The Chain

    REPLACING THE CHAIN 1. Remove the battery pack. 2. Using the hex key, loosen the bar bolt of the sprocket cover. 3. Remove the sprocket cover and guide bar. 4. Dispose of the old chain and prepare the new one. 5.
  • Page 15 6. Reinstall the sprocket cover and install the bar bolt. NOTE: Make sure that the chain follows the direction as shown. 7. Using the hex key, partially tighten the bar bolt. The bar must be free to move for tension adjustment. 8.

  • Page 16: Cleaning The Product

    CLEANING THE PRODUCT 1. Remove the battery pack. 2. Remove all foreign materials from the product with a soft, dry brush. WARNING: Avoid using solvents when cleaning plastic parts. Most plastics are susceptible to damage from various types of commercial solvents and may be damaged by their use.

  • Page 17: Storing The Product

    STORING THE PRODUCT 1. Remove the battery pack. 2. Cover the bar guide with the bar cover. 3. Remove the harness from the harness hanger. 4. Loosen the shaft coupling to release the extension pole from the shaft. 5. Store the product in a cool, dry, and well-ventilated place that is inaccessible to children and away from sources of ignition.

  • Page 18: Product Specifications

    Cordless pole pruner standardised test and may be used to compare one tool with Model RPP1820Li20/OPP1820 another. They may be used for a preliminary assessment of exposure. Voltage 18 V d.c.
  • Page 20 Unit C, 70 Business Parade South, Highbrook, Auckland 2013, New Zealand RYOBI is a trade mark of Ryobi Limited, and is used under license. OREGON is a registered trade mark of Blount, Inc. TRILINK is a registered trade mark of Trilink Saw Chain, LLC.
