Quick Start Guide Aurora
1 Welcome
Welcome to the Aurora Manikin Quick Setup Guide. This guide is
intended for for the Aurora Manikin user. This guide includes the
following details:
1. Contents of the Aurora Manikin Package
2. Manikin power and connection status
3. Starting and connecting the RespiSim® software and running a
simulation
4. Starting the Landing Application to connect the Patient Monitor
2 Aurora Manikin Contents
The Aurora Manikin includes the following components:
• Aurora Manikin (available in light or dark skin tones)
• Manikin charger
• Input: Universal 100 to 240 VAC, 1.5A Max, 50-60Hz
• Output: 15V 4.0A Max, 60W
• Universal power adapters (3)
• Manikin consumable package
• IV Cannulation pad – Forearm
• IV Cannulation pad – Dorsal
• Humeral IO Replacement
• Manikin consumable package
• Tape
• Lubricant
• Humeral IO extra fat
• Luer lock pipe
• Internal lung technology based on the ASL 5000® Breathing
Simulator architecture
• RespiSim® Software application (installed on Windows-based
tablet – "Instructor" PC)
• RespiSim® Patient Monitor application (installed on Win-
dows-based tablet – "Learner Display")
• RespiSim® Virtual Ventilator Software
Figure 2-1: Aurora Manikin (Dark Skin Tone) with Learner Display
Figure 2-2: Aurora Displays and Accessories
