8
Central heating
Domestic hot water (reference to MAGIS COMBO PLUS V2)
TB (°C)
65
55
A
35
10
0
-30 -25 -5
Cooling
TM (°C)
35
25
5
0 10
12
COOLING CIRCUIT FUNCTIONING LIMITS
System
B
0 35 46
TE (°C)
46 60
MAGIS COMBO V2
KEY:
TM - Flow water temperature (°C)
TE - Outdoor air temperature (°C)
Work area covered by Heat pump
KEY:
TB - Storage tank temperature probe (°C)
TE - Outdoor air temperature (°C)
A = Work area covered by condensation
generator
B = Work area covered by Heat pump
TE (°C)
60
KEY:
TM - Flow water temperature (°C)
TE - Outdoor air temperature (°C)
