aspenhome
ah
ITEM NO: I3014-272B/-272B-WHI
I3014-273/-273-WHI
Thank you for purchasing this quality product. Be sure to check all packing material carefully for
small parts that may come loose inside the carton during shipment.
WARNING! Before using this product, please read, understand, and follow these instructions. Failure to follow
each of these assembly instructions precisely may result in damage to the product and / or injury to the consumer.
I3014-273/-273-WHI
I3014-272B/-272B-WHI
COMPONENTS LIST:
Description
No.
1
Backer
COMPONENTS LIST:
Description
No.
1
Bridge
2
Metal Hook
FUNCTIONALITY INSTRUCTION
Page 1/3
72" Backer
UNIT SHOULD BE INSTALLED BY 2 OR MORE PERSONS.
I3014-272B/-272B-WHI
Quantity
Sketch
1 PC
I3014-273/-273-WHI
Quantity
Sketch
1 PC
2 PCS
Touch Switch
Ensure support leg makes
proper contact with the
ground by adjusting leveler.
FOR INDOOR USE ONLY
MADE IN VIETNAM
ASSEMBLY INSTRUCTIONS
R
72" Bridge
TOOLS REQUIRED (NOT PROVIDED)
PHILLIPS SCREWDRIVER
HARDWARE LIST:
No.
Description
Bolt Ø1/4" x 3/4"
A
Bolt Ø1/4" x 2-1/4"
B
Lock Washer Ø1/4"
C
Flat Washer Ø1/4" x 3/4"
D
Allen Wrench 4mm
E
Metal Plate
F
HARDWARE LIST:
No.
Description
G Wood Screw #3.5 x 5/8"
Hex Bolt Ø1/4" x 1"
H
Female Bolt Ø1/4"x13/16"
I
Allen Wrench 4mm
J
I3014-272B/-272B-WHI
Sketch
I3014-273/-273-WHI
Sketch
Touch Switch
Touch the touch switch to turn
on/off or adjust the lighting.
Levelers on legs
Adjust the levelers
when necessary
Quantity
16 PCS
3 PCS
19 PCS
19 PCS
1 PCS
4 PCS
Quantity
10 PCS
8 PCS
8 PCS
2 PCS
02-11-2025
Advertisement
Related Manuals for aspenhome I3014-272B
Summary of Contents for aspenhome I3014-272B
- Page 1 ASSEMBLY INSTRUCTIONS ITEM NO: I3014-272B/-272B-WHI 72" Backer I3014-273/-273-WHI 72" Bridge Thank you for purchasing this quality product. Be sure to check all packing material carefully for small parts that may come loose inside the carton during shipment. WARNING! Before using this product, please read, understand, and follow these instructions. Failure to follow each of these assembly instructions precisely may result in damage to the product and / or injury to the consumer.
- Page 2 ASSEMBLY INSTRUCTIONS ITEM NO: I3014-272B/-272B-WHI 72" Backer I3014-273/-273-WHI 72" Bridge STEP 1: Align the side piers to the console as shown below. Pier Pier Console STEP 2: Attach the backer above the console and between side piers by using 16 bolts (A), lock washers (C), flat washers (D) with 4 metal plates (F) as shown below.
- Page 3 ASSEMBLY INSTRUCTIONS ITEM NO: I3014-272B/-272B-WHI 72" Backer I3014-273/-273-WHI 72" Bridge STEP 3: Attach the metal hooks to the bridge with wood screws (G) as shown below. STEP 4: Reverse the handles by removing the screws while each door is open and attach the handles to the front of the door with screws as shown below.
