- Page 1 VERSION 2 .0 an innovative brand in smart sizes uv printers...
- Page 2 B2 LED UV PRINTER PRINTER INSTaLLaTION MaNUaL...
- Page 3 This manual is vial to your experience nd safety, as well as proper maneuvering of artisJet printers in production. The contents herein will guide you through the whole procedures of the initial setup of the printer. It is for all the printer operators involved in the production process. This file must be handed over to any operator if there is any position repla ement.
-
Page 4: Printer Overview
USB connection port. Printer front cover Print head + Control panel UV lamp Ink cartridges Working table Cylindrical transformation port General power button Fig.1 – Printer front and right side view artisjet.com | info@artisjet.com Copyright © 2019 Signs Full Joint Tech Co.,Ltd... - Page 5 Waste ink bottle Fig.2 – Printer front and left side view Printer Net Weight :190kg Fig.3 – Printer sizes overview (depth x width x height) and printer net weight artisjet.com | info@artisjet. Copyright © 2019 Signs Full Joint Tech Co.,Ltd...
-
Page 6: The Control Panel
2. The control panel Display, control buttons & functions Fig.4 – artis 5000U pro control panel and display artisjet.com | info@artisjet. Copyright © 2019 Signs Full Joint Tech Co.,Ltd... - Page 7 Move up* Move down* Move out* Move ba Move ba k the working table without auto height sensor* Mini move down* Fig. 5 – Control panel buttons and functions artisjet.com | info@artisjet. Copyright © 2019 Signs Full Joint Tech Co.,Ltd...
- Page 8 UV level adjust the power of the normal UV l Varnish level adjust the power of the varnish UV l Fig.5 – Control panel buttons and functions artisjet.com | info@artisjet. Copyright © 2019 Signs Full Joint Tech Co.,Ltd...
-
Page 9: Printer Environment
(Fig.7). Fig.6 – Four people moving the printer carefully Fig.7 – Position the printer onto the desk / table / flat surfa artisjet.com | info@artisjet. Copyright © 2019 Signs Full Joint Tech Co.,Ltd... - Page 10 Fig.8 – Open the cover carefully and take out the E-fixture mat from the working table Fig.9 – Unlock the carriage by removing the tapes Copyright © 2019 Signs Full Joint Tech artisjet.com |info@artisjet.com Co.,Ltd...
- Page 11 Fig.12 – After pressing the General Power Fig.13 – Wait till the printer is ready (a button, the “Initializing” message will be message will be displayed on the screen) displayed on the screen Copyright © 2019 Signs Full Joint Tech artisjet.com |info@artisjet.com Co.,Ltd...
- Page 12 Install the design software & print software Insert the USB drive (golden ) & the Design Software dongle (blue) (Fig.14). Fig.14 – Insert the USB drive (golden) & the Design Software dongle (blue) Copyright © 2019 Signs Full Joint Tech artisjet.com |info@artisjet.com Co.,Ltd...
- Page 13 Fig.15 – Open the workstation Next step is to install the workstation. In the folder’3-Workstaion 4.0’ folder, double click artisJet workstation for 5000U Install V4.0 Beta.exe, the window will open. Follow steps to to install workstation. Fig.17 – Install the Print...
-
Page 14: Ink System
Click “PM” icon in the Workstation as Fig 18. Click ‘Ink Charging’ to choose‘ink charging for install the printer’ It will take around 8 minutes to finish the whole process. Fig 19 artisjet.com |info@artisjet.com Copyright © 2019 Signs Full Joint Tech Co.,Ltd... - Page 15 Click’Clean’ button on control panel, Fig 22 it will show’cleaning’ during auto head cleaning process. Please wait 2 minutes, the control panel will show printer ready once cleaning process done. artisjet.com |info@artisjet.com Copyright © 2019 Signs Full Joint Tech Co.,Ltd...
- Page 16 Fig.24 – Take one piece of E-fixture and peel off the film one side only Fig.25 – Put the E-fixture mat onto the table and spread it till even on the surface artisjet.com |info@artisjet.com Copyright © 2019 Signs Full Joint Tech Co.,Ltd...
- Page 17 Fig.27 – On the Print Software, click on the “PM” icon, the “Maintenance” window will open. Click on the “Nozzle Check” button. Wait till the screen states “Print Complete” artisjet.com |info@artisjet.com Copyright © 2019 Signs Full Joint Tech Co.,Ltd...
- Page 18 Fig.28 If the print quality is not good(Not all the lines are full), click “Clean” button on the control panel till the nozzle check is full in all colors. artisjet.com |info@artisjet.com Copyright © 2019 Signs Full Joint Tech Co.,Ltd...
- Page 19 From Print Software, click on the Fig 31 icon to open the “XY Starting Point -artis 5000U .prn ” Prn file and print result (Fig 32 ) . Fig 32 artisjet.com |info@artisjet.com Copyright © 2019 Signs Full Joint Tech Co.,Ltd...
-
Page 20: Start Printing
(Fig.34) to open the “Color Test Image” file(Fig.35) and print it (Fig.36). Fig.33 - Color test im Fig.34 – Double click on the “Import” icon to import the print file template artisjet.com|info@artisjet.com Copyright © 2019 Signs Full Joint Tech Co.,Ltd... - Page 21 Locate the “Color test image.prn” file from the USB drive, and click the “Open” button. Fig.35 – Open the “Color test image.prn” print template file Fig.36 – Go to the Print Software and click on the “Print” icon artisjet.com|info@artisjet.com Copyright © 2019 Signs Full Joint Tech Co.,Ltd...
- Page 22 Print result Fig.37 – “Color test image”printing Fig.38 – Print result artisjet.com|info@artisjet.com Copyright © 2019 Signs Full Joint Tech Co.,Ltd...
- Page 23 Fig.40 – auto-detecting the sample and auto adjusting the printing height Start the product printing For each product, there can be different printing menus. artisJet provides custom menus & templates for different products. Product printing menus are available on demand.
- Page 24 CONTaCT US FOR MORE .artisjet.com ccc@artisjet.com +86 186 1133 3892...
