User Manual
Products:
WTM3100,
WTM3400,
WTM4302,
WTM5002

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WTM3100 and is the answer not in the manual?

Questions and answers

Related Manuals for Westinghouse WTM3100

Summary of Contents for Westinghouse WTM3100

  • Page 1 User Manual Products: WTM3100, WTM3400, WTM4302, WTM5002...

  • Page 2: Table Of Contents

    9. NOISES ..............................21 HAPPY TO HELP Thank you for choosing Westinghouse. We have designed this product to make your life simpler and deliver impeccable performance for many years. Please spend a few minutes reading this document to get the best from your new Westinghouse appliance.

  • Page 3: Safety Information

    SAFETY INFORMATION WARNING Note: You must read these warnings carefully before installing or using the refrigerator. R600a refrigerant warning If you need assistance, contact your customer care center. The manufacturer will not accept liability, This appliance contains flammable should these instructions or any other safety R600a refrigerant.

  • Page 4: Side View

    • Never store fizzy drinks in the freezer Side View compartment. • Never try to repair the refrigerator yourself, only use a qualified or authorized service person for repairs. • Stabilising foot Never use electric heaters or dryers to defrost...

  • Page 5: Description Of The Appliance

    2. DESCRIPTION OF THE APPLIANCE TOP MOUNT REFRIGERATOR FEATURES • WTM3100WL/SL • WTM3400WL WTM3400 illustrated The details of the refrigerator feature: Door Multi flow cover Door Handle Cover Decoration Cover Decoration Temperature Control (Refrigerator) Evaporator Cover Sealed Crisper Temperature Control (Freezer) Adjustable Feet Ice Ball Tray Gaskets...
  • Page 6 TOP MOUNT REFRIGERATOR FEATURES • WTM4302WD/SD WTM4302 illustrated The details of the refrigerator feature: Door Temperature Control (Refrigerator) Door Handle Humidity Crisper Cover Decoration Sealed Crisper Evaporator Cover Adjustable Feet Freezer Shelf Gaskets Twist Ice and Serve Freezer Door Bins...
  • Page 7 TOP MOUNT REFRIGERATOR FEATURES • WTM5002WD/SD WTM5002 illustrated The details of the refrigerator feature: Door Temperature Control (Refrigerator) Door Handle Humidity Crisper Cover Decoration Sealed Crisper Evaporator Cover Adjustable Feet Freezer Shelf Gaskets Twist Ice and Serve Freezer Door Bins Temperature Control (Freezer) Egg Tray Refrigerator Light...
  • Page 8 TOP MOUNT REFRIGERATOR FEATURES • WTM5002WE WTM5002WE illustrated The details of the refrigerator feature: Door Temperature Control (Refrigerator) Door Handle With Quick Chill Mode Evaporator Cover Crisper Cover Decoration Adjustable Feet Ice Ball Tray Gaskets Temperature Control (Freezer) Freezer Door Bins...

  • Page 9: Temperature Control

    Freezer will raise over the default temperature setting for approximately Default setting 1-3°c. For WTM3100* & WTM3400* models This function should be switch to default setting if you feel that the beverage is not cool enough or Ice cream become soft.
  • Page 10 Mode setting (Quick chill) for model WTM5002WE Use the Quick chill Mode when you add a large amount of food to the fridge or freezer compartments for rapid cooling. 4. To select the Quick chill mode, slide the control left completely.

  • Page 11: Installing Your New Appliance

    Wind the large height adjusting nut on the handle side down until the refrigerator is Model level and stable. If you have difficulty WTM3100* winding the nut or height adjusting foot 350 mm WTM3400* down, have someone tilt the refrigerator back so you have better access.
  • Page 12 4. Check the alignment of the refrigerator to Repeat step 7 for the stability foot on the the surrounding cupboards to see if it is handle side. Whenever you need to move level. You can adjust the level as detailed in the appliance, be sure to wind the feet step 2 and 3.

  • Page 13: Using Your Refrigerator

    5. USING YOUR REFRIGERATOR USING AND REMOVING FEATURES Refrigerators work by transferring heat from the food inside to the outside air. This operation makes the back and sides of the refrigerator feel warm or Glass shelves even hot particularly at start-up and on warm days To remove the shelves, gently pull them forward –...
  • Page 14 • Remove the crisper shelf by lifting the catches Twist & Serve Ice Bin on the left and right underside of the shelf and (For WTM4302*D ,WTM5002*D models only) pulling the shelf forward. 1. Prior the first use clean the ice tray.

  • Page 15: Water Level

    Ice ball tray (For WTM3100**, WTM3400**, 6. Hold the tray at its ends and twist gently. WTM5002WE models only) Twist 1. Prior to using the ice tray , clean it with water and dish detergent. 2. To make ice ball, fill the ice tray with water until the water level.

  • Page 16: Cleaning Your Refrigerator

    6. CLEANING YOUR REFRIGERATOR WARNING Switching off your refrigerator If you switch off your refrigerator for an extended BEFORE CLEANING: Turn the refrigerator period, follow these steps to reduce the chances off at the power point and unplug the cord...

  • Page 17: Food Storage Guide

    7. FOOD STORAGE GUIDE Recommended storage times for fresh foods* Category Product Storage tips Refrigerator Freezer Meat Sausages and 1-2 Days 2-3 Months Keep cold meat at the back of the refrigerator Mince where it is coldest. Plastic can cause meat to sweat if stored in Chops and Steak 3-4 Days 4-6 Months...

  • Page 18: Troubleshooting

    8. TROUBLESHOOTING Appliance does not operate at desired temperature In a modern frost free refrigerator / freezer, cold air is circulated around the various compartments through air vents using a high efficiency fan. CONCERN WHAT TO DO Refrigerator is too warm •...
  • Page 19 Appliance noise Your new refrigerator may make sounds that your old one didn’t make. Because the sounds are new to you, you might be concerned about them. Most of the new sounds are normal. Hard surfaces, like the floor, walls and cabinets, can make the sounds seem louder than they actually are.
  • Page 20 CONCERN WHAT TO DO Compressor motor seems • The variable speed compressor and fan that at start up and on warm to run too long . These days, runs at high speeds to provide additional cooling. When less appliances use a variable...
  • Page 21 Door operation CONCERN WHAT TO DO Freezer door pops open. • This is normal and should re-close. This happens when the refrigerator door is closed too quickly. • If the freezer door stays open, it indicates that the appliance needs to be tilted backwards a little further.

  • Page 22: Noises

    10. NOISES 9. NOISES Appliance noise Appliance noise Your new refrigerator may make sounds that your old one didn’t make. Because the sounds Your new refrigerator may make sounds that your old one didn’t make. Because the sounds are new to you, you might be concerned about them.

  • Page 23: Warranty

    (c) ‘ASC’ means Electrolux’s authorised serviced centres; (vi) incomplete or improper installation; (d) ‘Westinghouse’ is the brand controlled by Electrolux Home Products (vii) incorrect, improper or inappropriate operation; Pty Ltd of 163 O’Riordan Street, Mascot NSW 2020, ABN 51 004 762 341 in respect of Appliances purchased in Australia and Electrolux (viii) insect or vermin infestation;...
  • Page 24 NEW ZEALAND phone: 0800 436 245 email: customercare@electrolux.com.nz web: westinghouse.com.nz and WESTINGHOUSE are trademarks of Westinghouse Electric Corporation. Used under license. All Rights Reserved. © 2017 Electrolux Home Products Pty Ltd. ABN 51 004 762 341...
