Feelworld L1 PLUS User Manual

Feelworld L1 PLUS User Manual

Multi-format video switcher
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
L1 PLUS
Multi-format Video Switcher
User Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the L1 PLUS and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Feelworld L1 PLUS

Summary of Contents for Feelworld L1 PLUS

  • Page 1 L1 PLUS Multi-format Video Switcher User Manual...

  • Page 2: Table Of Contents

    2.4 Connecting Microphone and External Monitoring Devices ................9 2.5 Connect USB and Webcam .......................... 10 2.6 Connect Computer ............................10 2.7 Turn on Your L1 PLUS ........................... 11 Chapter 3 Use Your Product ..........................12 3.1Touch Screen Operation ..........................12 Touch Screen Introduction ..........................12 Swipe Shortcut ..............................
  • Page 3 5.1 Connect L1 PLUS and computer ......................... 35 Direct Link via a Network Cable ........................35 Static Direct Connection ...........................36 Connect Wirelessly with Your Router ......................36 5.2 Using Feelworld Live ............................37 Search Device ..............................38 PTZ Camera Setting ............................38 Chroma Key ................................39 Live Streaming ..............................

  • Page 4: Safety Instruction

    Thank you for choosing our product! This User Manual is designed to show you how to use this video processor quickly and make use of all the features. Please read all directions and instructions carefully before using this product. Declarations Safety Instruction The general safety information in this summary is for operating personnel.

  • Page 5: Chapter 1 Your Product

    While presets for PIP and PBP are provided, L1 PLUS includes full pixel-to-pixel scaling capabilities for both the PIP and background video layers–truly unique in a streaming mixer of this size – features usually found only on larger professional video mixers.

  • Page 6: Front Panel

    4 Preset to load, Audio,Record on/off,Mute on/off,Chroma Key on/off 1. Operate L1 PLUS menu by tapping it and monitor 4 inputs in real time 2” Touch 2. Monitor the screen of the currently controlled camera in real time...

  • Page 7: Interface Panel

    1 Type C Jack for power input, connect to PD power adapter Power Switch on to power on L1 PLUS MIC IN & MIC IN & AUDIO OUT, support one passive MIC input and one audio output via 2 in 1...

  • Page 8: Chapter 2 Install Your Product

    2.2 Input HDMI Signal Source You can use any camera, computer or other HDMI device as the input source of the L1 PLUS. It supports up to 4 sources of different formats and resolutions at the same time via 4 HDMI ports, and 4 HDMI inputs support up to 4K@60Hz.

  • Page 9: Connecting Hdmi Output

    Note: The HDMI cable is not included in the L1 PLUS package and needs to be purchased separately. Some camcorders use a mini HDMI port, you need to buy a mini HDMI-HDMI cable separately when you use these camcorders. 2.3 Connecting HDMI Output You can use a HDMI cable to connect the HDMI output to a monitor with an HDMI input interface, so that you can monitor the input, output and audio display in real time.

  • Page 10: Connecting Microphone And External Monitoring Devices

    2.4 Connecting Microphone and External Monitoring Devices L1 PLUS provides a 3.5mm standard headphone interface support one passive MIC input and one audio output via 2 in 1 audio splitter cable, or LINE output from the external audio console to do audio mixing of multiple external audio inputs.

  • Page 11: Connect Usb And Webcam

    2.5 Connect USB and Webcam Connect the USB 3.0 port on L1 PLUS to computer by USB 3.0 cable (blue) and computer will capture L1 PLUS USB output as a webcam source which can be pushed to Facebook,YouTube,Zoom, Twitter and other streaming media platform.

  • Page 12: Turn On Your L1 Plus

    2.7 Turn on Your L1 PLUS After L1 PLUS is connected to power supply, push the Power button on the rear panel,the device will enter to the boot interface and enter operation interface within 10S.

  • Page 13: Chapter 3 Use Your Product

    3.1Touch Screen Operation Touch Screen Introduction There is a 2” touch screen on L1 PLUS operation board, through which most operation can be done, so let’s introduce this touch screen first. Before introducing the operation of the touch screen, we need to introduce the button 【MENU】, the MENU and back key.

  • Page 14: Preset Menu

    Unlit: No signal source is connected or the resolution of the signal source connected is not accepted. Switch Effect Setting L1 PLUS is default 0.5S Fast Fade mode, by pushing ①②③④ signal buttons, 4 input signals can be switched in fast fade mode.

  • Page 15: Switch Mode Setting

    If you want to use more transition effects, tap【EFFECT】icon on the touch screen. You can enter the【Effects】selection interface, where fade in, fade out and various other transition effects can be selected. The inside icons on the menu can be dragged and sorted according to your preferences.

  • Page 16: T-Bar Switch And Multi-Screen Preview

    PST and PGM. 3.4 PIP L1 PLUS defaults to single-screen switching. If you need to use PIP, push button 【MENU】 to return to the main menu, then find【PIP】, and tap the icon to enter the PIP setting interface. PIP Layout Setting Layout offers 8 layout options for picture-in-picture.

  • Page 17: Pip Layer Setting

    ,then press the toggle to adjust the picture ratio and get a better view. 3.4 Views L1 PLUS save preset to View in real time. If you want to quickly load current preset next time, just save it to corresponding View. The View will save all the currently set parameters including PIP layout, Chroma Key setting, PTZ presets, therefore when you need to load any preset, just push corresponding View button in Shortcut interface.

  • Page 18: Video Output

    (5) If you want the modified preset to be loaded from the View, you need to re-save it to the current View or a new View. Please repeat the above save operation. 3.5 Video Output L1 PLUS offers output through HDMI and USB. HDMI Output HDMI output defaults multi-screen preview,which can be switched to PGM or the 4 input content in field application.
  • Page 19 HDMI output. Push button 【MENU】 again when the touch screen is in main menu interface and touch screen will enter 4-screen input source preview. Turn on 【Viewfinder】 , you can see a white rectangle in the PST as shown in the picture,helping users frame the camera view.

  • Page 20: Usb 3.0 Output

    Turn on Standard Simple USB 3.0 Output USB 3.0 output recognized as WEBCAM on computer defaults to be PGM which can be changed to multi-screen PST or TP (Test Pattern). Push button【MENU】to return main menu and find【Output】to do WEBCAM setting. It is default to be PGM and tap “>”on the right to change to PST or TP.

  • Page 21: Audio

    3.6 Audio L1 PLUS supports mixed output of multiple channels, and also supports audio delay. Tap the button 【MENU】 to return to the main menu, find and tap 【Audio】 to enter the sound setting interface. The audio output can be turned on or off, and the volume can be adjusted by sliding the bar.

  • Page 22: Chroma Key

    Shortcut interface, the PGM audio volume can be adjusted by the toggle. 3.7 Chroma Key L1 PLUS supports matting, the Chroma Key in the menu, removing the pure color background and overlaying it on another signal to realize the application of virtual reality. Matting can be done Feelworld Live or simple settings and adjustments can be made on the Chroma Key in the menu.
  • Page 23 Not only that, the L1 PLUS can also save the position and zoom information of the camera, so that you can quickly retrieve it the next time you use it. The PTZ preset of L1 PLUS not only saves the parameters of the PTZ, but also includes calling the...

  • Page 24: Record

    4. Set the file system to exFAT and the size of allocation unit to 128kb 5. Select “quick format”and start Insert the SSD or USB storage into the USB2.0 interface RECORD. Note:If the SSD could not be recognized when inserting into L1 PLUS, then use a dual USB cable to power the...
  • Page 25 L1 PLUS will automatically recognize the hard disk or U disk and display the relevant information on the recording window of multi-screen PVW . After inserting the SSD or USB storage, push button【MENU】to return to the main menu, and then tap【Record】to enter the interface to switch on Record and view the status of the SSD.

  • Page 26: Chapter 4 Streaming

    Chapter 4 Streaming 4.1 YouTube Streaming 1. Create a video or post. 2. Then click “Go live”. 4. Click “More option”. 3. Enter Live streaming interface. And then add a title. 5. Set video and audio as USB 3.0 6. After finished all setting, click “NEXT”. Video/Audio device.

  • Page 27: Facebook Streaming

    7. Go live. 4.2 Facebook Streaming 2. Click ”Video” 1. Enter “Publishing Tools”. 3. Click ”+Live” 4. Choose ”Use Camera”...

  • Page 28: Zoom Streaming

    6. Add a title and description. 5. Set video and audio as USB 3.0 Video/Audio device. 7. Go Live. 4.3 Zoom Streaming 1. Enter Zoom, click “Setting” icon. 2. Click “Video”, set Camera as “USB Video Device”.

  • Page 29: Obs Streaming

    3. Click “Audio”, set Microphone as “USB Audio Device”. 4.4 OBS Streaming Video Capture L1 PLUS is compatible with many third party steaming software, we recommend OBS, which is available to https://obsproject.com/download. download on Download the software and update to the latest version.
  • Page 30 3. Choose : FEELWORLD USB 3.0 Capture and Choose Video Format YUY2 Note：If there is no video format YUY 2 after setting above, check the USB 3.0 port connection. Make sure it is linked to USB 3.0 port on PC by USB 3.0 cable. (USB 3.0 cable or port is standard in blue while USB 2.0 is in Audio Setting black).
  • Page 31 1. Set the audio source: Setting→Audio→Mic/Auxiliary Audio Devices 2.Right click the Video Capture Device in Source and choose Filter 3. Click “+”under Audio/Video Filters and choose Video Delay (Async)
  • Page 32 4.You can custom the filter name in the pop-up window. Click OK to confirm the filter name. 5.Input delay value in ms, the value need to adjusted until the video and audio is synchronous. Streaming Setting 1. Find the RTMP URL and Stream Key provided by streaming broadcast website. 2.

  • Page 33: Vmix Streaming

    4.5 vMix Streaming 1. Click a new blank, then click the “Add Input” button. 2. Select Camera-Camera-FEELWORLD USB3.0 Capture.
  • Page 34 3. Select the same resolution as the L1 PLUS output. Then click “OK”. 4. Click Stream setting button. 5. Complete the URL and Key information. Click “Start 1”,vMix will begin streaming.

  • Page 35: Chapter 5 Feelworld Live Operation

    PLUS, or link the L1 PLUS to your router and the computer to the Wi-Fi emitted by your wireless router. Note:The IP address of the L1 PLUS must be in the same WLAN segment as the computer or the mobile control device you choose.

  • Page 36: Connect L1 Plus And Computer

    The L1 PLUS is connected to a computer via TCP/IP protocol for data transfer. Therefore, you need to keep the L1 PLUS on the same IP network segment as your PC or mobile device. If the L1 PLUS is connected directly to a computer, you need to change the L1 PLUS's IP manually to avoid IP conflicts on the same network segment.

  • Page 37: Static Direct Connection

    Connect Wirelessly with Your Router The L1 PLUS provides wireless control, so you can control it from a greater distance when the L1 PLUS is not in your immediate vicinity. A wireless router is required to use this feature. The computer receives the WIFI signal from the wireless router you connect the L1 PLUS to.

  • Page 38: Using Feelworld Live

    Feelworld Live simulates the L1 PLUS's real world appearance and the operations you can control with Feelworld Live are very similar to those you can do with the L1 PLUS's hardware. Feelworld Live has put all the functions in the "M" button. You can use this button for functions that are not possible with the L1 PLUS hardware.

  • Page 39: Search Device

    3. Select the desired device by SN and IP and operation panel on real L1 PLUS device. enter the management interface. PTZ Camera Setting When controlling the PTZ camera, the computer, L1 PLUS and PTZ camera should be in the same network segment.

  • Page 40: Chroma Key

    3. After IP address setting,turn on “Enable” and you can control PTZ camera. Chroma Key L1 PLUS also provides chroma key of sub-screens. Sub-screen keying is possible with PIP turned on,which helps you to combine characters with the virtual background.

  • Page 41: Live Streaming

    Live Streaming Device Capture:choose FEELWORLD USB3.0 Capture H.265: When it is ON, users can watch 4 inputs streaming back on Feelworld Live software. Import the related OBS application if users need to do live streaming, click Relate to confirm. OBS: slide ON to start streaming.

  • Page 42: Test Pattern

    PLUS in the same LAN, Feelworld Live provides a password protection function, as an administrator, you can set a password for the device controlling Feelworld Live, and when you control the interface again, you need to enter the password to control it.

  • Page 43: Upgrade

    2.1 Power on the device and connect LAN ports between PC and device by Cat6 cable; 2.2 Ensure that your computer is on the same network as the L1 PLUS. The default IP address of L1 PLUS is 192.168.0.99, in which case your computers IP address should be in the range 192.168.0.xxx (xxx can not be the same as L1 PLUS or other device on the network) to enable connection between the L1 PLUS and your computer.
  • Page 44 2. Click on the “Properties” button 1. Press keys together to open the Command Prompt; In the dialog type: ms-settings:network-status 3. Scroll down to find your IP address If the IP address is not in the same section, manual change of IP address is required. Here are the steps: Step 1.
  • Page 45 2. Fill in the IP Address of the L1 PLUS(as 1. Click”Connection”and select “other series” example above, default L1 PLUS IP is 192.168.0.99),and click “Confirm”. 3. Review Connection Status at bottom left, to 4. The firmware package will be ready with confirm indicator light is green and there is XTOOL automatically.
  • Page 46 7. L1 PLUS is now upgraded and ready to use.

  • Page 47: Chapter 6 Appendix

    Chapter 6 Appendix 6.1 Specification Connectors Input HDMI 4K 4×HDMI-A Output HDMI 2K 1×HDMI-A Streaming 1×USB Type-A Recording 1×USB Type-A 2×3.5mm Stereo Jack Audio 1×3.5mm Stereo Jack Communication 1×RJ45 Power 1×PD Type-C Performance Input Resolutions HDMI SMPTE 720p@50/60 |1080i@50 | 1080p@24/30/50/60 |2160p@60 VESA 1024×768@60 | 1280×720@60 | 1280×768@60 | 1280×800@60 | 1280×1024@60 | 1360×768@60 | 1366×768@60 | 1440×900@60 |...

  • Page 48: Faq

    4. L1 PLUS cannot control PTZ. A：Please make sure that the IP address of L1 PLUS and PTZ are in the same network segment. For example, the IP address of PTZ is 192.168.5.163. Please also set the IP address of L1 PLUS to 192.168.5.X ( (2~254) except163 Outside), confirm on Feelworld Live whether the Visca port number in the PTZ settings is the corresponding port number, for example, the Visca port number of the PTZ of FEELWORLD is 1259.
  • Page 49 8. L1 PLUS HDMI input what kind of YUV. A：L1 PLUS supports 4:4:4，not supports 4:2:0. 9. When L1 PLUS input is i format signal will be half-screened or cut with the P format signal, the height of the P format will be cut.
  • Page 50 13. Can L1 PLUS control PTZ of Pelco protocol? A：Currently, the PTZ controlling this protocol is not supported, L1 PLUS supports to control Visca protocol PTZ.
