- Page 1 GR716-MINI Development Board GR716-MINI User's Manual Dec 2024, Version 1.1 Frontgrade Gaisler AB GR716-MINI-UM Kungsgatan 12 | SE-411 19 Goteborg | Sweden Dec 2024, Version 1.1 +46 31 7758650 | frontgrade.com/gaisler...
-
Page 2: Table Of Contents
Interfaces and Configuration ..................24 6.1 List of Connectors ....................24 6.2 List of Oscillators, Switches and LED’s ..............26 Frontgrade Gaisler AB GR716-MINI-UM Kungsgatan 12 | SE-411 19 Goteborg | Sweden Dec-242024, Version 1.1 +46 31 7758650 | frontgrade.com/gaisler... - Page 3 Figure 4-1: GR716-MINI Board Block Diagram ..............8 Figure 4-2: GR716-MINI Board Dimensions (top side) ............9 Figure 4-3: GR716-MINI Board Dimensions (bottom side - expansion connector) ....9 Figure 4-5: GR716 Microcontroller Block Diagram ............10 Figure 4-6: GR716 Package ....................11 ...
-
Page 4: Introduction
GR716-MINI INTRODUCTION Scope and Purpose of the Document This document provides a User's Manual and Interface document for the “GR716-MINI” Development and Demonstration board. The work has been performed by Frontgrade Gaisler AB, Göteborg, Sweden. Reference Documents [RD1] GR716, Data Sheet and User's Manual", Frontgrade Gaisler, GR716-UM-DS, available from http://www.gaisler.com/index.php/products/components/GR716... -
Page 5: Abbreviations
Intellectual Property Low Drop-Out Printed Circuit Board Point of Load System On a Chip Spacewire To Be Confirmed To Be Defined Frontgrade Gaisler AB GR716-MINI-UM Kungsgatan 12 | SE-411 19 Goteborg | Sweden Dec-242024, Version 1.1 +46 31 7758650 | frontgrade.com/gaisler... -
Page 6: Introduction
LVDS transceivers, regulators to support for single 3.3V supply, ideally suited for space and other high-rel applications. Because not all features of the GR716 can be simultaneously operated, the GR716-MINI Development Board comprises a custom designed PCB providing a compact implementation with a representative array of interfaces and features. -
Page 7: Handling
20°C. All devices are standard commercial types, intended for use over the standard commercial operating temperature range (0 to 70ºC). Frontgrade Gaisler AB GR716-MINI-UM Kungsgatan 12 | SE-411 19 Goteborg | Sweden Dec-242024, Version 1.1 +46 31 7758650 | frontgrade.com/gaisler... -
Page 8: Board Design
GR716-MINI BOARD DESIGN Board Block Diagram The GR716-MINI Board provides the electrical functions and interfaces as represented in the block diagram, Figure 4-2. Figure 4-1: GR716-MINI Board Block Diagram Note that not all features and interfaces are available at the same time, and the configuration of on-board resistors plus programming of registers is required to access some of the features. -
Page 9: Board Mechanical Configuration
For mounting of the board on a carrier or expansion board, four M2 mounting holes are provided in the corners of the board, as shown in the figure below. Figure 4-2: GR716-MINI Board Dimensions (top side) Figure 4-3: GR716-MINI Board Dimensions (bottom side - expansion connector) Frontgrade Gaisler AB GR716-MINI-UM Kungsgatan 12 | SE-411 19 Goteborg | Sweden Dec-242024, Version 1.1... -
Page 10: Gr716 Microcontroller
GR716-MINI GR716 Microcontroller The Frontgrade Gaisler GR716 Microcontroller features a fault-tolerant LEON3 SPARC V8 processor, communication interfaces and on-chip ADC, DAC, Power-on-Reset, Oscillator, Brown-out detection, LVDS transceivers, regulators to support for single 3.3V supply, ideally suited for space and other high-rel applications. -
Page 11: Memory
The SRAM is connected to the GR716 Microcontroller using the GPIO[50..49], GPIO[34..0], GPIO[18..0] signals as shown in the figure below. Frontgrade Gaisler AB GR716-MINI-UM Kungsgatan 12 | SE-411 19 Goteborg | Sweden Dec-242024, Version 1.1 +46 31 7758650 | frontgrade.com/gaisler... -
Page 12: Expansion/Interface Connector
Expansion/Interface Connector To allow connection to external circuits, the bottom side of the board includes an 80 pin low-profile expansion connector. Frontgrade Gaisler AB GR716-MINI-UM Kungsgatan 12 | SE-411 19 Goteborg | Sweden Dec-242024, Version 1.1 +46 31 7758650 | frontgrade.com/gaisler... -
Page 13: Lvds Interfaces
The GR716 microcontroller provides a set of three LVDS input pairs and 3 LVDS output pairs which are configurable from software via configuration registers to provide Frontgrade Gaisler AB GR716-MINI-UM Kungsgatan 12 | SE-411 19 Goteborg | Sweden Dec-242024, Version 1.1 +46 31 7758650 | frontgrade.com/gaisler... - Page 14 LVDS have grounds that are connected together. Frontgrade Gaisler AB GR716-MINI-UM Kungsgatan 12 | SE-411 19 Goteborg | Sweden Dec-242024, Version 1.1 +46 31 7758650 | frontgrade.com/gaisler...
-
Page 15: Ftdi Serial To Usb Interface
GR716-MINI FTDI Serial to USB Interface The GR716-MINI board provides an FTDI FT4232HL Serial to USB interface chip which provides up to 4 serial ports which connect to a single Micro-B USB connector (J1). This USB port can be connected to a host computer to allow communication over serial interfaces to Host PC's which do not have conventional 9 pin D-sub type RS232 connectors. -
Page 16: Analog Signals
GR716-MINI Analog Signals The GR716-MINI board provides four micro-miniature (MMCX) coaxial connectors to allow access to up to 4 ADC inputs or 4 DAC outputs of the GR716 microcontroller. As shown in Figure 4-11, depending on which resistors are installed, each MMCX connector can be either an ADC input or a DAC output. -
Page 17: Gpio
ADC or DAC signals. Care must be taken to account for this. No current limiting or overvoltage protection components are included on the GPIO signals of the GR716-MINI board. The signals are connected directly from the microcontroller to the expansion connector. -
Page 18: Bootstrap Signals
Remote Access/Boot from Memory Pull-down SPIM_SCK Boot Source 0 Pull-down SPIM-SEL Boot Source 1 Pull-down Table 4: Bootstrap Resistor Settings Frontgrade Gaisler AB GR716-MINI-UM Kungsgatan 12 | SE-411 19 Goteborg | Sweden Dec-242024, Version 1.1 +46 31 7758650 | frontgrade.com/gaisler... -
Page 19: Debug Support Unit Interfaces
Program download and debugging to the processor is performed using the GRMON Debug Monitor tool from Frontgrade Gaisler ([RD4]). The GR716 microcontroller provides a UART based DSU interface for Debug and control of the processor by means of a host terminal, as represented in Figure 4-11. -
Page 20: Oscillators And Clock Inputs
GR716-MINI 4.12 Oscillators and Clock Inputs The oscillator and clock scheme for the GR716-MINI Board is shown in Figure 4-12. Two oscillator inputs are required: CLK for the main system clock, and SPW_CLK for the SpaceWire clock of the microcontroller. -
Page 21: Power Supply And Voltage Regulation
LMZ21701 micro Point-of-Load regulator is included on the board which generates the 3.3V for the rest of the GR716-MINI board. In an alternative scenario, when the GR716-MINI board is installed on an Expansion board or Motherboard, it is intended that the Motherboard should generate a regulated 3.3V supply and provide this via the Expansion connector. -
Page 22: Reset Circuit And Button
Please refer to [RD1]. Frontgrade Gaisler AB GR716-MINI-UM Kungsgatan 12 | SE-411 19 Goteborg | Sweden Dec-242024, Version 1.1 +46 31 7758650 | frontgrade.com/gaisler... -
Page 23: Setting Up And Using The Board
ERROR condition. To perform program download and software debugging on the hardware it is necessary to use the Frontgrade Gaisler GRMON3 debugging software, installed on a host PC (as represented in Figure 4-11). Please refer to the GRMON3 documentation for the installation of the software on the host PC (Linux or Windows), and for the installation of the associated hardware dongle. -
Page 24: Interfaces And Configuration
Table 7: J1 USB type Micro B connector – FTDI Serial Link Name Comment Inner ANALOG Refer to section 4.8 Outer AGND Ground Table 8: J2,J3,J4,J5 MMCX miniature coax connectors Frontgrade Gaisler AB GR716-MINI-UM Kungsgatan 12 | SE-411 19 Goteborg | Sweden Dec-242024, Version 1.1 +46 31 7758650 | frontgrade.com/gaisler... -
Page 25: Table 9: Expansion Connector P1 Pin-Out
GR716-MINI Table 9: Expansion connector P1 Pin-out Frontgrade Gaisler AB GR716-MINI-UM Kungsgatan 12 | SE-411 19 Goteborg | Sweden Dec-242024, Version 1.1 +46 31 7758650 | frontgrade.com/gaisler... -
Page 26: List Of Oscillators, Switches And Led's
Table 11: List and definition of PCB mounted LED's Name Function Description RESET Push button RESET switch Table 12: List and definition of Switches Frontgrade Gaisler AB GR716-MINI-UM Kungsgatan 12 | SE-411 19 Goteborg | Sweden Dec-242024, Version 1.1 +46 31 7758650 | frontgrade.com/gaisler... -
Page 27: Figure 6-1: Pcb Top View
GR716-MINI Figure 6-1: PCB Top View Figure 6-2: PCB Bottom View Frontgrade Gaisler AB GR716-MINI-UM Kungsgatan 12 | SE-411 19 Goteborg | Sweden Dec-242024, Version 1.1 +46 31 7758650 | frontgrade.com/gaisler... -
Page 28: Figure 6-3: Pcb Top View (Photo)
GR716-MINI Figure 6-3: PCB Top View (Photo) Figure 6-4: PCB Bottom View (Photo) Frontgrade Gaisler AB GR716-MINI-UM Kungsgatan 12 | SE-411 19 Goteborg | Sweden Dec-242024, Version 1.1 +46 31 7758650 | frontgrade.com/gaisler... -
Page 29: Revision Information
Handling instructions for LVDS added 2024-12-19 Section 4.2 Carrier board picture is removed since it is not possible to procure. Frontgrade Gaisler AB GR716-MINI-UM Kungsgatan 12 | SE-411 19 Goteborg | Sweden Dec-242024, Version 1.1 +46 31 7758650 | frontgrade.com/gaisler... - Page 30 T: +46 31 7758650 Frontgrade Gaisler AB reserves the right to make changes to any products and services described herein at any time without notice. Consult the company or an authorized sales representative to verify that the information in this document is current before using this product. The company does not assume any responsibility or liability arising out of the application or use of any product or service described herein, except as expressly agreed to in writing by the company;...
