DCM575_54V Chainsaw_V2
Version 02: Type1 & Type2
•
Eddy Laermans
•
11/03/2020
H
H
DCM575 54V FlexVolt Chainsaw

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FlexVolt DCM575 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for DeWalt FlexVolt DCM575

Summary of Contents for DeWalt FlexVolt DCM575

  • Page 1 DCM575 54V FlexVolt Chainsaw DCM575_54V Chainsaw_V2 Version 02: Type1 & Type2 • Eddy Laermans • 11/03/2020...
  • Page 2 Chainsaw Use & Safety Training HSE web-friendly version of full leaflet INDG345(rev1) Service & Repair Any person working within a service or repair environment who is required to use a chainsaw may only do so once he/she has been trained by a certified training manager. This will include the use of a chainsaw to test a successful repair or to diagnose an initial fault “if”...
  • Page 3 Before repair and service Follow the safety instruction...

  • Page 4: Safety Notes

    Safety Notes Before attempting any repairs, the following should be observed, Ensure that the correct tool is used and only use good quality hand tools. Ensure the workshop is clean and tidy. Always wear protective clothing, Overalls, safety gloves, safety glasses, safety hat/net etc. Check that guards function correctly, if not repair before running the product.

  • Page 5: Technical Information

    Before repair and service Technical information...
  • Page 6 KEY (LEGEND) of SYMBOLS ENGLISH GERMAN ITALIAN FRENCH SPANISH PORTUGUESE DUTCH CHECK ÜBERPRÜFEN CONTROLLARE CONTROLER COMPROBAR VERIFIQUE CONTROLEREN ATTENTION ! ACHTUNG ! ATTENZIONE ! ATTENTION ! ATENCION ! ATENÇÃO! ATTENTIE ! TOURNEZ DANS LE GIRAR SENTIDO ANTI- TURN COUNTER DREHEN GEGEN GIRARE IN SENSO SENS INVERSE DES GIRO IZQUIERDA...
  • Page 7 KEY (LEGEND) of SYMBOLS ENGLISH GERMAN ITALIAN FRENCH SPANISH PORTUGUESE DUTCH BEARING LAGERABZIEHER ESTRATTORE SACA EXTRACTEUR QUITAR COJINETE LAGER TREKKER REMOVER CUSCINETTO ROLAMENTOS CLEANING WASCH MAQUINA DE MÁQUINA DE LAVAPEZZI BAC DE LAVAGE WASMACHINE MACHINE MASCHINE LIMPIEZA LIMPEZA SWITCH ON ANSCHALTEN ACCENDERE ALLUMEZ...
  • Page 8 KEY (LEGEND) of SYMBOLS ENGLISH GERMAN ITALIAN FRENCH SPANISH PORTUGUESE DUTCH SEQUÊNCIA 1;2;3;4 SEQUENCE REIHENFOLGE SEQUENZA SEQUENCE SECUENCIA VOLGORDE … DISCONNECT TRENNEN SCOLLEGARE DEBRANCHEZ DESCONECTADO DESLIGAR ONTKOPPELEN NICHT NÃO TOQUE DO NOT TOUCH NON TOCCARE NE PAS TOUCHER NO TOCAR NIET AANRAKEN BERÜHREN DO NOT...
  • Page 9 KEY (LEGEND) of SYMBOLS ENGLISH GERMAN ITALIAN FRENCH SPANISH PORTUGUESE DUTCH UTILISEZ UN USE STATIC GEBRUIK ANTI - ANTISTATIK MATTE USARE I DISPOSITIVI EQUIPEMENT DE USE PROTECCION USE PROTEÇÃO PROTECTION STATISCH BENUTZEN ANTISTATICI PROTECTION ANTIESTATICA ESTATICA DEVICE MATERIAAL ANTISTATIQUE GRÖSSE TAMANHO CHAVE DIMENSIONE VITE TAMAÑO LLAVE...
  • Page 10 KEY (LEGEND) of SYMBOLS ENGLISH GERMAN ITALIAN FRENCH SPANISH PORTUGUESE DUTCH PH – KRUIS CROSS HEAD TOURNEVIS DESTORNILLADOR SCHRAUBEN- CACCIAVITE PH CHAVE PHILIPS SCHROEVENDRAAI SCREWDRIVER CRUCIFORME DE ESTRELLA DREHER ER (PH TYPE) TORX- TORX TORX HEAD DESTORNILLADOR SCHRAUBEN- CACCIAVITE TORX TOURNEVIS TORX CHAVE TORX SCHROEVENDRAAI...
  • Page 11 KEY (LEGEND) of SYMBOLS ENGLISH GERMAN ITALIAN FRENCH SPANISH PORTUGUESE DUTCH USE RUBBER SCHONHAMMER USARE MARTELLO UTILISEZ UN KUNSTSTOF MAZA BLANDA MALHO DE MALLET BENUTZEN DI GOMMA MAILLET HAMER BORRACHA SCHRAUBSTOCK USE TORNILLO DE USE TORNO DE GEBRUIK EEN USE A VICE USARE LA MORSA UTILISEZ UN ETAU BENUTZEN...
  • Page 12 KEY (LEGEND) of SYMBOLS ENGLISH GERMAN ITALIAN FRENCH SPANISH PORTUGUESE DUTCH NICHT NAÒ TOCAR DON´T TOUCH NON TOCCARE NE PAS TOUCHER NO TOCAR NIET AANRAKEN BERÜHREN DOUBLE SCHUTZISOLIERUN DOPPIO ISOLAMENTO ISOLATION TOTALE DOBLE AISLAMIENTO DUPLO ISOLAMENTO DUBBEL-GEÏSOLEERD INSULATED REVERSE RECHTS LINKS RECHTS/LINKS REVERSIBILITA’...
  • Page 13 ENGLISH GERMAN ITALIAN FRENCH SPANISH PORTUGUESE DUTCH Content Inhalt CONTENUTO Index Contenido Conteúdo Inhoudstabel Change Version Änderungs Version CAMBIO VERSIONE N° Changer de version Cambiar Version Alterar versão Gew ijgde versie No.xxx Nr..xxx No.xxx No xxx No.xxx Nr. xxx Change at Slide Änderung Siehe CAMBIO ALLA SLIDE Modification...
  • Page 14 DCM575N / DCM575X1 54V Chainsaw Tool Free Bar fitment & Chain Tensioning Fast Chain Adjustments Variable Speed Trigger Chain Brake /electronic and physical. No pull starting and improved control during cutting 40CM Oregon Bar and Chain Same cutting capacity as petrol equivalents Extensive over-mould For extra grip and...

  • Page 15: Parts Diagram

    CONTENT: • Parts diagram pg 16 • Disassemble tool -Type 1 & Type 2 pg 17 • Lubrification for type 1 pg 39 • Lubrification for type 2 pg 41 • Assembly hints pg 45...
  • Page 17 2013 33-59...
  • Page 21 T20 X6...
  • Page 24 T20 x 5...
  • Page 27 10mm LH 3.5Nm...
  • Page 29 T10 x2...
  • Page 30 11 x T20...
  • Page 35 T10 x2...
  • Page 39 Lubrification system Type 1...
  • Page 41 Lubrification system Type 2 One major change about the lubrification of the chain: • The cam piston pump flow rate is approx. 25ml/min. • The new worm gear pump flow rate is approx. 12ml/min. The systems are interchangeable...

  • Page 45: Assembly Hints

    Assembly Hints...

  • Page 46: Brake Assembly

    Brake assembly...
  • Page 51 Remember: the next check will be made by your customer...
