- Page 1 UP Squared 7100 Edge UP System UPS-EDGE-ASL User’s Manual 1 Last Updated: November 27, 2024...
-
Page 2: Copyright Notice
Copyright Notice This document is copyrighted, 2024. All rights are reserved. The original manufacturer reserves the right to make improvements to the products described in this manual at any time without notice. No part of this manual may be reproduced, copied, translated, or transmitted in any form or by any means without the prior written permission of the original manufacturer. - Page 3 Acknowledgement All other products’ name or trademarks are properties of their respective owners. Microsoft®, Windows® are registered trademarks of Microsoft Corp. ⚫ Intel® and Iris® are registered trademarks of Intel Corporation ⚫ Linux® is a registered trademark of Linus Torvalds in the U.S. and other ⚫...
- Page 4 Packing List Before setting up your product, please make sure the following items have been shipped: Item Quantity UP Squared 7100 Edge (UPS-EDGE-ASL) ⚫ If any of these items are missing or damaged, please contact your distributor or sales representative immediately. Preface...
- Page 5 About this Document This User’s Manual contains all the essential information, such as detailed descriptions and explanations on the product’s hardware and software features (if any), its specifications, dimensions, jumper/connector settings/definitions, and driver installation instructions (if any), to facilitate users in setting up their product. Users may refer to the product page at AAEON.com for the latest version of this document.
- Page 6 Safety Precautions Please read the following safety instructions carefully. It is advised that you keep this manual for future references All cautions and warnings on the device should be noted. Make sure the power source matches the power rating of the device. Position the power cord so that people cannot step on it.
- Page 7 If any of the following situations arises, please the contact our service personnel: Damaged power cord or plug Liquid intrusion to the device iii. Exposure to moisture Device is not working as expected or in a manner as described in this manual The device is dropped or damaged Any obvious signs of damage displayed on the device...
- Page 8 FCC Statement This device complies with Part 15 FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received including interference that may cause undesired operation.
- Page 9 China RoHS Requirements (CN) 产品中有毒有害物质或元素名称及含量 AAEON System QO4-381 Rev.A0 有毒有害物质或元素 部件名称 铅 汞 镉 六价铬 多溴联苯 多溴二苯醚 (Pb) (Hg) (Cd) (Cr(VI)) (PBB) (PBDE) 印刷电路板 × ○ ○ ○ ○ ○ 及其电子组件 外部信号 × ○ ○ ○ ○ ○ 连接器及线材 ○ ○...
- Page 10 China RoHS Requirement (EN) Hazardous and Toxic Materials List AAEON System QO4-381 Rev.A0 Hazardous or Toxic Materials or Elements Component Name PCB and Components Wires & Connectors for Ext.Connections Chassis CPU & RAM HDD Drive LCD Module Optical Drive Touch Control Module Battery This form is prepared in compliance with the provisions of SJ/T 11364.
-
Page 11: Table Of Contents
Table of Contents Chapter 1 - Product Specifications..................1 Specifications ......................2 Chapter 2 – Hardware Information ..................4 Dimensions ....................... 5 Jumpers and Connectors ..................6 List of Jumpers, Connectors, & Physical Interfaces ......... 11 2.3.1 Dual GbE LAN (1/2) ..................12 2.3.2 HDMI/DP Port (3/4).................. -
Page 12: Chapter 1 - Product Specifications
Chapter 1 Chapter 1 - Product Specifications... -
Page 13: Specifications
Specifications System Intel® Processor N97 Intel® Processor N100 Memory Up to 16GB LPDDR5 Graphics Intel® UHD Graphics for 12th Gen Intel® Processors Storage Up to 128GB eMMC Ethernet GbE RJ-45 x 2 Wi-Fi/BT Optional via M.2 2230 E-Key x 1 Expansion Slot M.2 2230 E-Key x 1 (PCIe [x1], USB 2.0) M.2 2280 M-Key x 1 (PCIe Gen 3 [x2]) - Page 14 Power Supply Power Requirement 12V DC-in, 5A Power Supply Type AT/ATX Power Consumption 15W~37W (Typical) Mechanical Mounting VESA Mounting Dimensions (W x H x D) 3.74” x 3.74” x 2.16” (95mm x 95mm x 55mm) Net Weight 0.99 lb. (4.5Kg) Gross Weight 1.32 lb.
-
Page 15: Chapter 2 - Hardware Information
Chapter 2 – Hardware Information Chapter 2... -
Page 16: Dimensions
Dimensions Chapter 2 – Hardware Information... -
Page 17: Jumpers And Connectors
Jumpers and Connectors System Level Front I/O Chapter 2 – Hardware Information... - Page 18 Right I/O: Chapter 2 – Hardware Information...
- Page 19 Left I/O: Chapter 2 – Hardware Information...
- Page 20 Board Level Component Side Chapter 2 – Hardware Information...
- Page 21 Solder Side Chapter 2 – Hardware Information...
-
Page 22: List Of Jumpers, Connectors, & Physical Interfaces
List of Jumpers, Connectors, & Physical Interfaces Please refer to the table below for all of the system’s physical ports and interfaces. Label Function LAN 1 (GbE) LAN 2 (GbE) HDMI 2.0b Port Display Port 1.2 USB 3.2 Gen 2 (Type-A) USB 3.2 Gen 2 (Type-A) Power Button 12V DC-in... -
Page 23: Dual Gbe Lan (1/2)
2.3.1 Dual GbE LAN (1/2) LAN 1 Signal Signal LAN1_MDI0+ LAN1_ACTLED- LAN1_MDI0- LAN1_ACTLED+ LAN1_MDI1+ LAN1_LINK1000# LAN1_MDI1- LAN1_LINK100# LAN1_MDI2+ LAN1_MDI2- LAN1_MDI3+ LAN1_MDI3- R10A LAN 2 Signal Signal LAN2_MDI0+ LAN2_ACTLED- LAN2_MDI0- LAN2_ACTLED+ LAN2_MDI1+ LAN2_LINK100# LAN2_MDI1- LAN2_LINK1000# LAN2_MDI2+ LAN2_MDI2- LAN2_MDI3+ LAN2_MDI3- Chapter 2 – Hardware Information... -
Page 24: Hdmi/Dp Port (3/4)
LAN 2 Signal Signal R10B 2.3.2 HDMI/DP Port (3/4) HDMI Signal Description Signal Description Signal Description HDMI_TX2+ HDMI_TX2- HDMI_TX1+ HDMI_TX1- HDMI_TX0+ HDMI_TX0- HDMI_CLK+ HDMI_CLK- HDMI_CEC HDMI_SCL HDMI_SDA +5V/0.5A HDMI_Hot Plug Detect Signal Description Signal Description Signal Description DP_TX0+ DP_TX0- DP_TX1+ DP_TX1- DP_TX2+ DP_TX2-... -
Page 25: Usb 3.2 Gen 2 (Type-A) Dual Stack (5/6)
Signal Description Signal Description Signal Description Pull down 1M to DP_AUX_EN DP_AUX+ DP_AUX- DP_Hot Plug Detect +3.3V/1A 2.3.3 USB 3.2 Gen 2 (Type-A) Dual Stack (5/6) USB #1 Signal Signal Signal +5V/2A USB2_D1- USB2_D1+ USB3_RX1- USB3_RX1+ USB3_TX1- USB3_TX1+ USB #2 Signal Signal Signal... -
Page 26: Dc-In (8)
2.3.4 12V DC-in (8) Signal Signal DC_IN GND_Signal 2.3.5 COM 1 (12) Signal Signal DCDN SINN SOUTN DTRN DSRN RTSN CTSN Chapter 2 – Hardware Information... -
Page 27: Com 2 (9)
2.3.6 COM 2 (9) Signal Signal DCDN SINN SOUTN DTRN DSRN RTSN CTSN 2.3.7 Audio Jack (Line-out) (10) Signal Signal AUD_GND LOUT_R LOUT_L Chapter 2 – Hardware Information... -
Page 28: Audio Jack (Mic-In) (11)
2.3.8 Audio Jack (Mic-in) (11) Signal Signal AUD_GND MIC_LR_CN MIC_LR_CN 2.3.9 Power Button (7) Signal Signal Power Button Signal Chapter 2 – Hardware Information... -
Page 29: Usb 3.2 Gen 2 (Type-A) (13)
2.3.10 USB 3.2 Gen 2 (Type-A) (13) Signal Signal +5V/2A USB2_D3- USB2_D3+ USB3_RX- USB3_RX+ USB3_TX- USB3_TX+ Chapter 2 – Hardware Information... -
Page 30: Chapter 3 - Software Installation
Chapter 3 Chapter 3 – Software Installation... -
Page 31: Linux Setup
Linux Setup The UP Squared 7100 Edge supports Linux operating systems (see Chapter 1 for specifications). For instructions on how to install a Linux OS onto your UP Squared 7100 Edge, you can find several guides and tutorials in the wiki section of the UP website at https://up-board.org for both ins talling supported distributions as well as porting... -
Page 32: Appendix A - Cables And Connectors
Appendix A Appendix A– Cables and Connectors... -
Page 33: Cables And Connectors
Cables and Connectors This table provides detailed information about the cables and connectors used by the UP Squared 7100 Edge. If you have any questions about the configuration of your system, please contact your AAEON sales representative. Mating Connector Label Function AAEON P/N Vendor Model No.
