Original User's Instructions
1000W 2 in 1 Brush Cutter & Line Trimmer
SKU: 66926
READ BEFORE USE
PLEASE KEEP THESE INSTRUCTIONS FOR FURTHER REFERENCE

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the H9205BL and is the answer not in the manual?

Questions and answers

Summary of Contents for Hawksmoor H9205BL

  • Page 1 Original User’s Instructions 1000W 2 in 1 Brush Cutter & Line Trimmer SKU: 66926 READ BEFORE USE PLEASE KEEP THESE INSTRUCTIONS FOR FURTHER REFERENCE...
  • Page 2 www.coreservice.co.uk Hotline: +44 01904 947568 Email support@coreservice.co.uk...
  • Page 3: Table Of Contents

    CONTENTS ∫ WHAT’S IN THE BOX ---------------------------------------------------------- 3 ∫ SPECIFICATIONS -------------------------------------------------------------- 4 ∫ EXPLANATIONS AND SYMBOLS, CAUTIONS AND WARNINGS ---------- 5 ∫ IMPORTANT SAFETY WARNINGS -------------------------------------------- 7 ∫ PRODUCT DESCRIPTION AND IDENTIFICATIONS ------------------------ 18 ∫ ASSEMBLY AND OPERATING INSTRUCTIONS -----------------------------19 ∫...
  • Page 4: What's In The Box

    WHAT'S IN THE BOX Safety shoulder belt Main unit Brush cutter/grass trimmer shaft Auxiliary handle Spanner Hex key Safety guard Line spool Brush cutter blade If you do not have all these items, please contact: www.coreservice.co.uk Hotline: +44 01904 947568 Email support@coreservice.co.uk www.coreservice.co.uk Hotline: +44 01904 947568...
  • Page 5: Specifications

    SPECIFICATION Technical Data Model H9205BL Rated power input 1000W No load speed 6000 rpm (grass trimmer)/6800 rpm (brush cutter) Cutting diameter 350mm(grass trimmer)/230mm(brush cutter) Nylon line size Dia.: 2mm, Length: 2x3m Line type Twisted Blade type 3 teeth blade (3T blade) Net weight (Approx.)
  • Page 6: Explanations And Symbols, Cautions And Warnings

    EXPLANATIONS AND SYMBOLS, CAUTIONS AND WARNINGS Safety Notes Warning! Read all safety warnings and all instructions. Make yourself familiar with the controls and the proper use of the product. Please keep the instructions safe for later use! Explanation of symbols on the product Warning! Read the instructions for use prior to operating the machine.
  • Page 7 Do not expose the machine to water or operate it in the rain. This unit is not intended for use with a toothed saw type blade. Guaranteed sound power level data (96dB). Keep by-standers well away. They could injured by flung out objects. Do not touch the cutting device until it stops completely.
  • Page 8: Important Safety Warnings

    IMPORTANT SAFETY WARNINGS GENERAL POWER TOOL SAFETY WARNINGS Warning: Please read the following instructions carefully, failure to do so could lead to serious personal injury. When using the electric brush cutter and line trimmer, basic safety precautions, including the following, should always be followed to reduce the risk of fire,electric shock and personal injury.
  • Page 9: Electrical Safety

    Work Area Safety • Keep work area clean and well lit. Cluttered or dark areas invite accidents. • Do not operate power tools in explosive atmospheres, such as in the presence of flammable liquids, gases or dust. Power tools create sparks which may ignite the dust or fumes. •...
  • Page 10 Personal Safety • Stay alert, watch what you are doing and use common sense when operating a power tool. Do not use a power tool while you are tired or under the influence of drugs, alcohol or medication. A moment of inattention while operating power tools may result in serious personal injury.
  • Page 11 • If devices are provided for the connection of dust extraction and collection facilities, ensure these are connected and properly used. Use of dust collection can reduce dust-related hazards. • Do not let familiarity gained from frequent use of tools allow you to become complacent and ignore tool safety principles.
  • Page 12 • Use the power tool, accessories and tool bits etc. in accordance with these instructions, taking into account the working conditions and the work to be performed. Use of the power tool for operations different from those intended could result in a hazardous situation.
  • Page 13 • Never operate the product with damaged guards or without the guards in place. • Keep hands and feet away from the cutting means at all times, and especially when switching on the motor. • Never allow children or people unfamiliar with the instructions to use the product.
  • Page 14: Maintenance And Storage

    Maintenance and storage • Improper maintenance and removal of safety devices leads to hazards causing injuries and damage to property. • When the product is stopped for servicing, inspection or storage, shut off the power source, remove from the mains and make sure all moving parts have come to a stop.
  • Page 15 • Wear ear protection. • Wear foot protection and gloves (on brush cutters). • Keep a distance between the product and bystanders of at least 15 m. • Beware of thrown object. • Take care against injury from any device fitted for trimming the line length.
  • Page 16 decisions as to the period of time a product can be used safely on a daily basis and the choice of tool. Further advice can be found at www.hse.gov.uk The declared vibration emission value should be used as a minimum level and should be used with the current guidance on vibration.
  • Page 17: Residual Risks

    Emergency Familiarise yourself with the use of this product by means of this instruction manual. Memorise the safety directions and follow them to the letter. This will help to prevent risks and hazards. 1. Always be alert when using this product, so that you can recognise and handle risks early.
  • Page 18 • Health defects resulting from vibration emission if the product is being used over long periods of time or not adequately managed and properly maintained. • Injuries and damage to property due to broken accessories or the sudden impact of jects during use. •...
  • Page 19: Product Description And Identifications

    PRODUCT DESCRIPTION AND IDENTIFICATIONS 7. Cable strain relief hook 1. Brush cutter blade 8. Lock-off push button 2. Spool 9. Stop pin 3. Safety guard 10. Lower shaft lock nut 4. Auxiliary handle 11. Safety shoulder belt 5. Tubing clip for safety shoulder belt 6.
  • Page 20: Assembly And Operating Instructions

    ASSEMBLY AND OPERATING INSTRUCTIONS NOTE: To reduce the risk of injury, user must read instruction manual. Intended Use This 2 in 1 brush cutter and line trimmer is designated with an electrical machinery. Depending on the attached accessory this product is intended to be used as: 1).
  • Page 21 Insert the lower shaft into the connector, make sure the stop pin (a) on the shaft slots into the hole (b). If the shaft is not able to be fully inserted, slightly rotate the lower shaft or spindle to ensure full alignment before insertion.
  • Page 22 2. Install the auxiliary handle onto shaft. Warning: According to the safety regulation, user should be on the same side of stop lever when operating 3. Tighten the screw. There is a groove on the shaft, and the lower plate should align with the groove on the shaft during installation.
  • Page 23 Installation of the blade guard 1. Loosen the allen bolts form the safety guard using the provided hex key. 2. Mount the safety guard onto the shaft working head and fix the safety guard with 2 allen bolts and tighten the bolts seurely. www.coreservice.co.uk Hotline: +44 01904 947568 Email support@coreservice.co.uk...
  • Page 24 Installation of the brush cutter blade Insert a hex key into the shaft lock hole (located on the side of the working head) to secure the shaft. After unscrewing the safety nut, remove the safety nut, flange cover, locking flange in sequence from the shaft working head.
  • Page 25 Installation of the line spool for grass trimmer. Insert a hex key into the shaft lock hole (located on the side of the working head) to secure the shaft. After unscrewing the safety nut, remove the safety nut, flange cover, locking flange, and backing flange in sequence.
  • Page 26 Change the nylon line 1. Pull out the remaining grass-cutting line: Below the red arrow on the front of the bottom of the line spool, there is a threading hole for the grass-cutting line on each side (as shown in Figure 1). Firmly press on the surface with the red arrow while pulling the grass-cutting line out from the line exit holes on both sides of the line spool if the line can no longer extend automatically.
  • Page 27 OPERATION INSTRUCTIONS 1. Safety shoulder belt The safety should belt helps the operator carry this product. WARNING! Always attach the product to the shoulder strap. Do not carry it just by hand. 1). To remove the shoulder strap from the loop, open the securing clip. 2).
  • Page 28 2. Brush cutter WARNING! To avoid hazards never cut heavier weeds, brush and similar vegetation with a thickness of over 20mm. Avoid contact with stones, wire, glass etc. that may cause injury to the user. Inspect the blade regularly for damage, cracks or breaks. Always replace a damaged blade.
  • Page 29 5). Hold the trimmer head just above the ground at an angle of approximately 30°. 6). Move the product with slow and regular arc from left to right before moving it back to the starting position before trimming the next area. 7).
  • Page 30 9). A line cutter (B9) is integrated with the trimming guard (B8) and this will cut the line to the necessary length. WARNING! The cut line will be thrown out. Danger of injury especially for bystanders. 10). For best results, do not cut wet grass as it may stick to the cutting heads and guard, preventing proper discharge of grass trimmings, and could cause you to slip and fall.
  • Page 31: Care And Cleaning

    CARE AND CLEANING MAINTENANCE WARNING: Use only original spare parts. The use of other parts presents a danger and could lead to accidents or injuries. WARNING: Always wear safety glasses with side shields when using the device. In dusty environments, you should also wear a dust mask.
  • Page 32: Trouble Shooting

    TROUBLE SHOOTING Use this section to help you to try and solve any problems you may have: PROBLEM POSSIBLE CAUSES REMIDIES Trimmer does not Cable plug is not inserted Make sure the cable plug is inserted operate or is inserted incorrectly Motor overheating Grass caught under the Remove caught grass...
  • Page 33: Declaration Of Conformity / Performance

    DECLARATION OF CONFORMITY / PERFORMANCE Product Code 66926 (H9205BL) Product Description Hawksmoor 2in1 Brush Cutter & Line Trimmer 1. Toolstation (company number 04372131) This declaration of conformity is issued under the sole responsibility of Toolstation 2. Object of the declaration...
  • Page 34: Environmental Information

    ENVIRONMENTAL INFORMATION The symbol on the product or its packaging indicates that this product must not be disposed of with your other household waste. Instead, it is your responsibility to dispose of your waste equipment by handing it over to a designated collection point for the recycling of waste electrical and electronic equipment.
  • Page 35: Warranty

    WARRANTY Toolstation products deliver reliable service for normal, household use in domestic settings. All Toolstation products are individually tested before leaving the factory. If you are a consumer and you experience a problem with your Toolstation product, which is found to be defective due to faulty materials or workmanship within the Warranty Period, this Toolstation Warranty will cover repair or - at the discretion of Toolstation –...
  • Page 36 www.coreservice.co.uk Hotline: +44 01904 947568 Email support@coreservice.co.uk...
