ELECTRIC TOY CAR
Assembly & User Instructions - Please keep for future reference
Picture for reference only. Please refer to real object.
Important
Age: 6 Years +
Maximum user
weight: 60KG/132LBS
Important - Please read these instructions fully before assembly or use
These instructions contain important information which will help you to get the
best from your product and ensure safe and correct assembly, use and
maintance.
Warning!
1. For family and domestic use only
2. Not to be used in traffic
3. Your new vehicle requires adult assembly.
4.To reduce the risk of injury, adult supervision is required.
Never use in roadways, near motor vehicles, on or near
steep inclines or steps, swimming pools or other bodies
of water; always wear shoes, and never allow more than
one rider(s).
A8812 24V
ASTM-F963
W8812 002
Advertisement
Table of Contents
Related Manuals for FREDDO A8812
Summary of Contents for FREDDO A8812
- Page 1 CHILDREN'S A8812 24V ELECTRIC TOY CAR Assembly & User Instructions - Please keep for future reference ASTM-F963 Picture for reference only. Please refer to real object. Important Warning! 1. For family and domestic use only 2. Not to be used in traffic Age: 6 Years + 3.
-
Page 2: Table Of Contents
Table of Contents 1. About Your New Vehicle 2. Safety Information 3. Parts List 4. Parts Diagram 5. Assembly Steps 6. How To Operate Your Vehicle 7. Charging The Vehicle 8.. Troubleshooting Guide 9. Maintaining Your Vehicle 10.Disposal Of Battery About Your New Vehicle Thank you for purchasing our products, we want your child to enjoy this product for years to come. -
Page 3: Safety Information
Safety Information WARNING! General safety: • • Where products need assembly they must always be assembled by an adult. As a parent/carer, it is also your responsibility to check the tightness of screws, nuts and bolts before each use and if necessary, adjust and re-tighten. - Page 4 Safety Information WARNING! Charging the battery: • • All charging and re-charging must be carried out by an adult. • Do not attempt to use the product while it is being charged. • Charging should be carried out under cover and in a well-ventilated area. •...
-
Page 5: Parts List
Parts List PART PART PART PART REMARKS REMARKS PICTURE PICTURE NAME NAME (pcs) (pcs) Vehicle Seat body Driving Front wheel wheel Steering Wheel wheel Cover Bogie Rear axle Fixing part... - Page 6 Parts List PART PART PART PART REMARKS REMARKS PICTURE PICTURE NAME NAME (pcs) (pcs) Instruction Charger manual Spanner Spanner Spanner Spanner Screw Assembly package M4X12 Screw Install the seat M4X12 Screw Spare...
-
Page 8: Assembly Steps
Assembly Steps 1.Install the back wheels. As shown in the picture,disconnect the rear axle parts ,put the rear axle through the car body. As shown in the picture, disconnect the rear axle parts. Put the driving wheel through the rear axle and fix it with washer and nut and wheel hub in turn. ... - Page 9 Assembly Steps 2.Install the bogie. As shown in the picture, ,install the bogie to the corresponding place,and fasten with the bolt and nut . Insert the bent end into the hole in the bogie. 3.Install the front wheel. ...
-
Page 10: Install The Steering Wheel
Assembly Steps 4.Install the steering wheel. As showed in the picture, press the steering wheel, Adjust the height well and fasten with the nut. Fasten the nut with spanner.The steer wheel height could be adjusted from here. As showed in the picture, install the cove. 5.Connect the power supply. -
Page 11: Install The Seat
Assembly Steps 6.Install the seat. As shown in the picture, install the seat to the corresponding place, and fasten with the screws and fixing parts. -
Page 12: How To Operate Your Vehicle
How To Operate Your Vehicle Use Operation( Ensure the power switch has been turned on IMPORTANT! Always stop vehicle when changing the speed or direction to avoid damage the gear box and motor. (1)Turn on the power switch first. (2) Forward Press the "Forward and Reverse switch"... -
Page 13: Charging Your Vehicle
Charging Your Vehicle ONLY AN ADULT CAN CHARGE AND RECHARGE THE BATTERY! Non-rechargeable batteries are not to be recharged. Do not mix old and new batteries. Do not mix alkaline standard (carbon-zinc), or rechargeable (nickel-cadmium) batteries. Batteries are to be inserted with the correct polarity. ... - Page 14 Charging Your Vehicle WARNING! • PREVENT FIRE AND ELECTRIC SHOCK: • Do not drop the battery. Permanent damage to the battery could occur or cause serious injury. • Before charging the battery, check for wear or damage to the battery, charger, its supply cord and the connectors.
-
Page 15: Troubleshooting Guide
Troubleshooting Guide ■PROBLEM: The vehicle does not run PROBLEM CAUSE: The battery may low on power. After each use, or once a month minimum, charge the battery for 8-12 hours. Do not leave the battery on the charger for more than 20 hours. POSSIBLE CAUSE: Thermal fuse has tripped. -
Page 16: Maintaining Your Vehicle
Troubleshooting Guide ■PROBLEM: The vehicle does not run very long. POSSIBLE CAUSE: Battery may be undercharged. You may not be charging the battery long enough. After each use, or once a month minimum, charge the battery for 8 to 12 hours. Do not leave the battery on the charger for more than 20 hours. POSSIBLE CAUSE: Battery is old. -
Page 17: Disposal Of Battery
Disposal Of Battery Disposal Of Battery ● Your sealed lead-acid battery must be recycled or disposed of in an environmentally sound manner. ● Do not dispose of your lead-acid battery in a fire. The battery may explode or leak. ● Do not dispose of a lead-acid battery in your regular, household trash. The incineration, land filling or mixing of sealed lead-acid batteries with household trash is prohibited by law.
