FREDDO A035 Manual

1 seater drifter
Hide thumbs

Advertisement

Table of Contents

L'image n'est qu'une référence. Veuillez vous référer à l'objet réel.
Important
Âge : 6ans et plus
Poids maximum de
l'utilisateur: 60kg
Important - Veuillez lire entièrement ces instructions avant l'assemblage ou l'utilisation.
Ces instructions contiennent des informations importantes qui vous aideront à tirer le meilleur
parti de votre produit. produit et à garantir un montage, une utilisation et un entretien sûrs et
corrects. l'entretien.
1 Seater Drifter
Avertissement!
1. Pour un usage familial et domestique uniquement
2. Ne doit pas être utilisé dans la circulation
3. Montage par un adulte requis
A035
ASTM-F963

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the A035 and is the answer not in the manual?

Questions and answers

Related Manuals for FREDDO A035

Summary of Contents for FREDDO A035

  • Page 1 A035 1 Seater Drifter L'image n'est qu'une référence. Veuillez vous référer à l'objet réel. ASTM-F963 Important Avertissement! Âge : 6ans et plus 1. Pour un usage familial et domestique uniquement Poids maximum de 2. Ne doit pas être utilisé dans la circulation l'utilisateur: 60kg 3.

  • Page 2: Table Of Contents

    Table of Contents 1. About Your New Vehicle 2. Safety Information 3. Parts List 4. Parts Diagram 5. Assembly Steps 6. How To Operate Your Vehicle 7. Charging The Vehicle 8.. Troubleshooting Guide 9. Maintaining Your Vehicle 10.Disposal Of Battery About Your New Vehicle Thank you for purchasing our products, we want your child to enjoy this product for years to come.

  • Page 3: Safety Information

    Safety Information WARNING! General safety: • • Where products need assembly they must always be assembled by an adult.As a parent/carer, it is also your responsibility to check the tightness of screws, nuts and bolts before each use and if necessary, adjust and re-tighten.
  • Page 4 Safety Information WARNING! Charging the battery: • • All charging and re-charging must be carried out by an adult. • Do not attempt to use the product while it is being charged. • Charging should be carried out under cover and in a well-ventilated area. •...

  • Page 5: Parts List

    Parts List PART PART PART PART REMARKS REMARKS PICTURE PICTURE NAME NAME (pcs) (pcs) Vehicle Baffle body Baffle Left & Decorative right pair cover Steering Seat wheel Driving Cover wheel Wheel Wheel Wheel Bumper Rear axle Bogie...
  • Page 6 Parts List PART PART PART PART REMARKS REMARKS PICTURE PICTURE NAME NAME (pcs) (pcs) Fixing part Fixing part Training Flag wheel Instruction Charger manual Spanner Spanner Spanner Screw Assembly package M4X12 Screw Install the baffle M4X12 Screw Install the decorative cover. M4X12 Screw Install the seat.

  • Page 8: Assembly Steps

    Assembly Steps 1.Install the training wheel. As showed in the picture, press the training wheel downward to fix it. 2.Install the rear axle and back wheels . As shown in the picture,disconnect the rear axle parts ,put the rear axle through the car body.
  • Page 9 Assembly Steps 3.Install the bogie. As shown in the picture, ,install the bogie to the corresponding place,and fasten with the bolt and nut . Insert the bent end into the hole in the bogie. 4. Install the front wheel . Remove the nut and washer on the front axle.
  • Page 10 Assembly Steps 5.Install the bumper. Remove the bolt and nut on the car body. As showed in the picture,install the bumper to the corresponding place, and fasten with the bolt and nut . 6. Install the baffle . As showed in the picture,install the baffle B to the baffle A, and fasten with the screws. As showed in the picture,install the baffle to the corresponding place, and fasten with the fixing part A and screws.
  • Page 11 Assembly Steps 7.Install the decorative cover. As showed in the picture,install the decorative cover to the corresponding place, and fasten with the fixing part B and screws. The other side is same as above. 8.Connect the power supply. As shown in the picture,the wire connector plug butt.
  • Page 12 Assembly Steps 10. Install the steering wheel. As showed in the picture, press the steering wheel,Adjust the height well and fasten with the nut. Fasten the nut with spanner. As showed in the picture, install the cove. 11. Install the flag. As showed in the picture, press the flag downward to fix it.

  • Page 13: How To Operate Your Vehicle

    How To Operate Your Vehicle Use Operation( Ensure the power switch has been turned on IMPORTANT! Always stop vehicle when changing the speed or direction to avoid damage the gear box and motor. (1)Turn on the power switch first, the sound can be played. (2) Forward Press the "Forward and Reverse switch"...
  • Page 14 How To Operate Your Vehicle Use Operation( Ensure the power switch has been turned on Optional for Sound System A: IMPORTANT! Always stop vehicle when changing the speed or direction to avoid damage the gear box and motor. (1)Turn on the power switch first, the sound can be played. (2) Forward Press the "Forward and Reverse switch"...
  • Page 15 How To Operate Your Vehicle How to use the Sound System & Battery Indicator A ( Optional ) ( 7 ) 1. Storage device slot. 2. Horn. 3.AUX Port 4.Increase volume. 5.Decrease volume 6. Next Song: Switch songs. 7. Last Song: Switch songs. 8.
  • Page 16 How To Operate Your Vehicle Use Operation( Ensure the power switch has been turned on Optional for Sound System B: IMPORTANT! Always stop vehicle when changing the speed or direction to avoid damage the gear box and motor. (1)Turn on the power switch first, the sound can be played. (2) Forward Press the "Forward and Reverse switch"...
  • Page 17 How To Operate Your Vehicle How to use the Sound System & Battery Indicator B ( Optional ) ( 7 )  1. Storage device slot.  2. Storage card slot.  3.AUX Port  4.Decrease volume/Last Song: Switch songs. ...
  • Page 18 Charging Your Vehicle ONLY AN ADULT CAN CHARGE AND RECHARGE THE BATTERY! non-rechargeable batteries are not to be recharged; different type of batteries or new and used batteries are not to be mixed; batteries are to be inserted with the correct polarity; exhausted batteries are to be removed from the toy;...
  • Page 19 Charging Your Vehicle WARNING! • PREVENT FIRE AND ELECTRIC SHOCK: • Do not drop the battery. Permanent damage to the battery could occur or cause serious injury. • Before charging the battery, check for wear or damage to the battery, charger, its supply cord and the connectors.

  • Page 20: Troubleshooting Guide

    Troubleshooting Guide ■PROBLEM: The vehicle does not run PROBLEM CAUSE: The battery may low on power. After each use, or once a month minimum, charge the battery for 8-12 hours. Do not leave the battery on the charger for more than 20 hours. POSSIBLE CAUSE: Thermal fuse has tripped.

  • Page 21: Maintaining Your Vehicle

    Troubleshooting Guide ■PROBLEM: The vehicle does not run very long. POSSIBLE CAUSE: Battery may be undercharged. You may not be charging the battery long enough. After each use, or once a month minimum, charge the battery for 8 to 12 hours. Do not leave the battery on the charger for more than 20 hours. POSSIBLE CAUSE: Battery is old.
  • Page 22 Disposal Of Battery Disposal Of Battery ● Your sealed lead-acid battery must be recycled or disposed of in an environmentally sound manner. ● Do not dispose of your lead-acid battery in a fire. The battery may explode or leak. ● Do not dispose of a lead-acid battery in your regular, household trash. The incineration, land filling or mixing of sealed lead-acid batteries with household trash is prohibited by law.
