FREDDO A033 Manual

4 seater dune buggy
Hide thumbs

Advertisement

Quick Links

Download this manual
4 Seater Dune Buggy
Picture for reference only. Please refer to real object.
Important
Age: 6Years +
Maximum user
120kg
Important - Please read these instructions fully before assembly or use
These instructions contain important information which will help you to get the
best from your product and ensure safe and correct assembly, use and
maintance.
Special Note： Battery packed in battery case could be taken out from the car
for portable charging.
A033
Warning!
1. For family and domestic use only
2. Not to be used in traffic
3. Adult assembly required
ASTM-F963

Advertisement

loading
Need help?

Need help?

Do you have a question about the A033 and is the answer not in the manual?

Questions and answers

Related Manuals for FREDDO A033

Summary of Contents for FREDDO A033

  • Page 1 A033 4 Seater Dune Buggy ASTM-F963 Picture for reference only. Please refer to real object. Important Warning! Age: 6Years + 1. For family and domestic use only Maximum user 2. Not to be used in traffic 3. Adult assembly required...

  • Page 2: Table Of Contents

    Table of Contents 1. About Your New Vehicle 2. Safety Information 3. Parts List 4. Parts Diagram 5. Assembly Steps 6. How To Operate Your Vehicle 7. Charging The Vehicle 8.. Troubleshooting Guide 9. Maintaining Your Vehicle 10.Disposal Of Battery About Your New Vehicle Thank you for purchasing our products, we want your child to enjoy this product for years to come.

  • Page 3: Safety Information

    Safety Information WARNING! General safety: • • Where products need assembly they must always be assembled by an adult.As a parent/carer, it is also your responsibility to check the tightness of screws, nuts and bolts before each use and if necessary, adjust and re-tighten.
  • Page 4 Safety Information WARNING! Charging the battery: • • All charging and re-charging must be carried out by an adult. • Do not attempt to use the product while it is being charged. • Charging should be carried out under cover and in a well-ventilated area. •...

  • Page 5: Parts List

    Parts List PART PART PART PART REMARKS REMARKS PICTURE PICTURE NAME NAME (pcs) (pcs) Vehicle Windshield body Guide Seat frame Guide Guide right frame frame Left Wheel Rear axle Wheel Steering wheel Placed in the Cover Screw assembly package...
  • Page 6 Parts List PART PART PART PART REMARKS REMARKS PICTURE PICTURE NAME NAME (pcs) (pcs) Instruction Charger manual Spanner PART PART PART PART REMARKS REMARKS PICTURE PICTURE NAME NAME (pcs) (pcs) Support Support column column optional optional Support Support column column optional optional Front...

  • Page 8: Assembly Steps

    Assembly Steps 1.Install the rear axle and gear box. With car body up-side-down, cut plastic ties holding drive motor in place, and remove the gear box. One of the gear boxes rotates 180°, pay attention to the line when rotating. As shown in the picture,disconnect the rear axle parts ,put the rear axle through the car body and gear box,then Install the other gear box.
  • Page 9 Assembly Steps 3.Install the front axle . As shown in the picture, install the front axle to the corresponding place,and fasten with the bearing , washer and nut . 4. Install the front wheel . Remove the nut and washer on the front axle.
  • Page 10 Assembly Steps 5. Install the guide frame . As showed in the picture, install the guide frame B to the corresponding place. As showed in the picture, press the guide frame downward to fix it. 6. Install the steering wheel. As showed in the picture, press the steering wheel,Adjust the height well and fasten with the nut.
  • Page 11 Assembly Steps 7. Install the seat. As shown in the picture, press and hold the button, then install the seat to the corresponding place . 8. Install the windshield bar. As showed in the picture, press the windshield bar downward to fix it.
  • Page 12 Assembly Steps 9.Connect the power supply. As shown in the picture, press and hold the button,then open the hood . As shown in the picture,the wire connector plug butt. Plug the power connector into the terminal on battery. Special note:The battery pack could be taken out for easy charging,by the charger and the charging cable in the accessary kit..

  • Page 13: How To Operate Your Vehicle

    How To Operate Your Vehicle Use Operation( Ensure the power switch has been turned on IMPORTANT! Always stop vehicle when changing the speed or direction to avoid damage the gear box and motor. (1) Insert the key,turn on the power switch first, the sound can be played. (2) Forward Press the "Forward and Reverse switch"...
  • Page 14 How To Operate Your Vehicle How to use the Sound System & Battery Indicator ( 6) 1. Storage device slot. 2. Horn. 3.AUX Port 4.Increase volume. 5.Decrease volume 6. Next Song: Switch songs. 7. Last Song: Switch songs. 8. SCAN Button: you can control the music play and pause. 9.Tell a story 10.Power Display: Shows battery power and charge level.
  • Page 15 Charging Your Vehicle ONLY AN ADULT CAN CHARGE AND RECHARGE THE BATTERY! non-rechargeable batteries are not to be recharged; different type of batteries or new and used batteries are not to be mixed; batteries are to be inserted with the correct polarity; exhausted batteries are to be removed from the toy;...
  • Page 16 Charging Your Vehicle WARNING! • PREVENT FIRE AND ELECTRIC SHOCK: • Do not drop the battery. Permanent damage to the battery could occur or cause serious injury. • Before charging the battery, check for wear or damage to the battery, charger, its supply cord and the connectors.

  • Page 17: Troubleshooting Guide

    Troubleshooting Guide ■PROBLEM: The vehicle does not run PROBLEM CAUSE: The battery may low on power. After each use, or once a month minimum, charge the battery for 8-12 hours. Do not leave the battery on the charger for more than 20 hours. POSSIBLE CAUSE: Thermal fuse has tripped.

  • Page 18: Maintaining Your Vehicle

    Troubleshooting Guide ■PROBLEM: The vehicle does not run very long. POSSIBLE CAUSE: Battery may be undercharged. You may not be charging the battery long enough. After each use, or once a month minimum, charge the battery for 8 to 12 hours. Do not leave the battery on the charger for more than 20 hours. POSSIBLE CAUSE: Battery is old.

  • Page 19: Disposal Of Battery

    Disposal Of Battery Disposal Of Battery ● Your sealed lead-acid battery must be recycled or disposed of in an environmentally sound manner. ● Do not dispose of your lead-acid battery in a fire. The battery may explode or leak. ● Do not dispose of a lead-acid battery in your regular, household trash. The incineration, land filling or mixing of sealed lead-acid batteries with household trash is prohibited by law.
